Amer.com SS2GD8I User Manual

6-port 10/100/1000+ 2 combo-sfp port l2 managed switch
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SS2GD8I
6-port 10/100/1000 + 2 Combo-SFP Port
L2 Managed Switch
User's Guide
Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SS2GD8I and is the answer not in the manual?

Questions and answers

Related Manuals for Amer.com SS2GD8I

Summary of Contents for Amer.com SS2GD8I

  • Page 1 SS2GD8I 6-port 10/100/1000 + 2 Combo-SFP Port L2 Managed Switch User’s Guide Version 1.0...
  • Page 2 6901 Bryan Dairy Road, Suite 150, Largo, FL 33777 © Amer.com Corp., 1997-2006 All rights reserved. No part of this publication may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from Amer.com, as stipulated by the United States Copyright Act of 1976.

  • Page 3: Table Of Contents

    Table of Contents INTRODUCTION ........................1 ....................1 RODUCT VERVIEW ..................1 EATURES OF THE WITCH ........................1 HECKLIST ........................2 EATURES SS2GD8I D .....................3 IAGRAM 1.5.1 Front Panel ......................3 1.5.2 Rear Panel......................4 ....................4 IBER RANSCEIVERS INSTALLATION........................5 19-I ...............5 NSTALLING WITCH INTO ....................5 ABLE NSTALLATION 2.2.1...
  • Page 4 3.13 STP C ....................43 ONFIGURATION 3.13.1 STP Status ......................43 3.13.2 Configuration....................44 3.13.3 Port........................45 3.14 ..................46 RUNKING ONFIGURATION 3.14.1 Port........................47 3.14.2 Aggregator View....................47 3.14.3 System Priority ....................48 3.15 802.1X C ....................49 ONFIGURATION 3.15.1 State ........................49 3.15.2 Mode .......................49 3.15.3 Security ......................50 3.16 .....................52 LARM...

  • Page 5: Electronic Emission Notices

    Caution Circuit devices are sensitive to static electricity, which can damage their delicate electronics. Dry weather conditions or walking across a carpeted floor may cause you to acquire a static electrical charge. To protect your device, always: • Touch the metal chassis of your computer to ground the static electrical charge before you pick up the circuit device.
  • Page 6 About this user’s manual This user’s manual will show you how to install and connect the switch to your network and also how to configure and monitor the switch through the built-in CLI and web interface through RS-232 serial interface and Ethernet with step-by-step instructions. Many explanations of hardware and software functions are shown as well as examples of the operation for the web-based graphical user interface (GUI) and command-line interface (CLI).

  • Page 7: Introduction

    1 Introduction 1.1 Product Overview The SS2GD8I is a managed switch that meets all IEEE802.3/u/x/z Fast Ethernet and Gigabit specifications. The switch features 6 Gigabit copper ports and 2 Gigabit Combo-SFP ports. The switch can be managed through the RS-232 serial port or through an Ethernet port using either the CLI or Web GUI.

  • Page 8: Features

    Please notify your sales representative immediately if any of the aforementioned items are missing or damaged. 1.4 Features The SS2GD8I switch provides the features listed below for users to perform system network administration and service the network efficiently and securely. Hardware •...

  • Page 9: Ss2Gd8I Diagram

    • Network time synchronization and daylight saving time • 120 event log records in the main memory and displayed on the local console 1.5 SS2GD8I Diagram Figure 1-1: SS2GD8I 1.5.1 Front Panel There are 8 Gigabit Ethernet ports and 2 SFP fiber ports for optional removable transceivers on the front of the switch.

  • Page 10: Rear Panel

    LINK/ACT: Lights up green when connected to a device, flashes when transmitting data. 10/100/1000Mbps: Lights up green when connected at 1000Mbps, amber when connected at 100Mbps, and is off when connected at 10Mbps or not connected. SFP: Lights up green when connected to a device, blinks when transmitting data. 1.5.2 Rear Panel The RS-232 port used for command line management and the power outlet are on the rear of the unit.

  • Page 11: Installation

    2 Installation 2.1 Installing Switch into 19-Inch Rack Figure 2-1: Installing the Switch Caution: Allow proper spacing and air ventilation for the cooling fans on both sides of the switch. To installing the switch into the rack: 1. Wear a grounding device for electrostatic discharge. 2.

  • Page 12: Cabling Requirements

    SFP Transceivers The SFP slots are hot-swappable, meaning that SFP transceivers can be installed or removed while the switch is on. To install a transceiver: 1. Verify that the SFP module is the right type and form factor for the switch. 2.
  • Page 13 The following table lists the types of fiber supported by the switch: IEEE 802.3z Gigabit Multi-mode Fiber Cable and Modal Bandwidth Ethernet 1000SX 850nm Multi-mode 62.5/125μm Multi-mode 50/125μm Modal Bandwidth Distance Modal Bandwidth Distance 160MHz-km 220m 400MHz-km 500m 200MHz-km 275m 500MHz-km 550m 1000Base-...
  • Page 14 Case 2a: Port-based VLAN (See Figure 2-4). Figure 2-4: Port-based VLAN Diagram 1. The same VLAN members cannot be connected to different switches. 2. Each VLAN member cannot access members of other VLANs. 3. The switch manager has to assign different names for each VLAN group on the switch. Case 2b: Port-based VLAN (See Figure 2-5).

  • Page 15: Configuring The Switch

    Case 3: Tag-based VLANs. The same VLAN members can be at different switches with the same VID (See Figure 2-6). Figure 2-6: Tag-based VLAN Diagram 2.2.2 Configuring the Switch There are three ways to setup and manage the switch. They are via RS-232 console, command line interface (CLI), and web interface.
  • Page 16 4. Select Internet Protocol (TCP/IP), then click Properties. 5. Select to use a static IP address or “Use the following IP address”. 6. Enter the following IP address for the computer: “192.168.1.5” 7. Enter the following subnet mask for the computer: “255.255.255.0” 8.

  • Page 17: Web Interface

    CLI login screen. The switch will display a serial number used to recover the password (See Figure 3-1). Write down the serial number and email it to Amer.com in order to get a temporary password. Use this new password as the Username and Password, and it will allow you to login to the switch temporarily.

  • Page 18: Home Page

    3.1 Home Page After you login, the switch will display the System Information page (figure 3-2). This page shows you some basic information about the switch, including “Model Name”, “System Description”, “Location”, “Contact”, “Device Name”, “System Up Time”, “Current Time”, “BIOS Version”, “Firmware Version”, “Hardware-Mechanical Version”, “Serial Number”, “Host IP Address”, “Host Mac Address”, “Device Port”, “RAM Size”...

  • Page 19: System Information

    Device name: The name of the switch as defined by the user, the default is “SS2GD8I”. System up time: The amount of time that the switch has been operational. This number is reset if the switch is powered off.

  • Page 20: Ip Configuration

    Firmware version: The firmware version on the switch. Hardware-Mechanical version: The hardware and mechanical version of the switch. The number before the hyphen is the hardware version; the one after the hyphen is the mechanical version. Serial number: The serial number as assigned by the manufacturer. Host IP address: The IP address of the switch.

  • Page 21: Time

    Default gateway: Allows you to manually set the IP address for your network gateway, which is typically a router or bridge to the internet or other subnet. All packets which are addressed to a device that is not in the switch’s routing table will be sent to the default gateway. Default: 192.168.1.254 DNS: The Domain Name Server used to serve the translation between IP addresses and domain names.

  • Page 22: Account Configuration

    Fall. Available choices for the time change are from -5 to +5 in one hour increments. Setting this to zero will disable daylight saving time. If the value is non-zero, you have to set the starting/ending date as well; otherwise the daylight saving function will not be activated. 3.1.4 Account Configuration The Account Configuration page under the System menu (Figure 3-6) allows you to manage the users...

  • Page 23: Virtual Stack

    Figure 3-7: Management Policy Page Name: A name for the rule made up of letters and numbers up to 8 characters. VID: If set to “Any”, the rule applies to users from any VLAN, otherwise you can enter a specific VID to limit the rule.

  • Page 24: Port Configuration

    (e.g. 100_SS2GD8I) for a switch with an IP address 192.168.0.100 and name “SS2GD8I”. Otherwise it will show ” ---- “ if there is no switch active there. Once the devices have successfully joined the group, then they will only be manageable through the Master device, and will be unable to be managed via telnet/console/web individually.

  • Page 25: Port Configuration

    Figure 3-9: Port Status Page Port No: The port number, ranging from 1-8. Both ports 7 and 8 are optional modules. Media: Shows the media type of the port. Ports 1-6 are twisted pair (TP) or copper, while ports 7 and 8 could be twisted pair or fiber.

  • Page 26: Simple Counter

    Figure 3-10: Port Configuration Page State: Either “Enable” or “Disable” the port, allowing traffic to pass through it or not. Default: Enable. Mode: Sets the speed and duplex of the port. If the connection is 1Gbps, the speed is always 1000Mbps and the duplex is full only.

  • Page 27: Detail Counter

    Figure 3-11: Simple Counter Page Tx Byte: Total transmitted bytes. Rx Byte: Total received bytes. Tx Packet: Total number of packets transmitted. Rx Packet: Total number of packets received. Tx Collision: Number of collisions experienced while transmitting. Rx Error Packet: Number of bad packets received. 3.2.4 Detail Counter The Detail Counter Page (Figure 3-12) displays the detailed traffic information for the switch.
  • Page 28 Figure 3-12: Detail Counter Page Rx Packets: The number of the packet received. RX Octets: Total received bytes. Rx High Priority Packets: Number of received packets classified as high priority. Rx Low Priority Packets: Number of received packets classified as low priority. Rx Broadcast: The number of the received broadcast packets.

  • Page 29: Mirror

    Rx 64 Bytes: Number of 64-byte frames in both good and bad packets received. Rx 65-127 Bytes: Number of 65 - 126-byte frames in both good and bad packets received. Rx 128-255 Bytes: Number of 127 - 255-byte frames in both good and bad packets received. Rx 256-511 Bytes: Number of 256 - 511-byte frames in both good and bad packets received.

  • Page 30: Bandwidth Management

    Figure 3-13: Port Mirroring Page Mode: Used to “Enable” or “Disable” port mirroring. Default is Disable. Monitoring Port: Set the port that will be monitoring the other ports. Default is Port 1. Monitored Port: Set the port(s) to be monitored. Place an X beside the number of the port(s) to monitor. The Monitoring port should not be selected as a Monitored port.

  • Page 31: Qos (Quality Of Service) Configuration

    Port Number: The port that is currently being configured. Can be set to ports 1 through 8. All Traffic for Ingress Rate Limiting(Policing): Sets the limit of Ingress (incoming) bandwidth for all traffic. Incoming traffic will be discarded if the rate exceeds the value set under Data Rate. Pause frames are also generated if flow control is enabled.
  • Page 32 Per Port Priority For Per Port Priority (Figure 3-16), you can select which priority to assign each of the 8 ports on the switch. Figure 3-16: Per Port Priority VLAN TAG Priority For VLAN Tag Priority (Figure 3-17), you can set the mapping of VLAN tags to the two priority levels in the switch.
  • Page 33 Quality of Service ToS Configiruation Quality of Service ToS Configuration (Figure 3-18) works similarly to VLAN Tag Priority, except that the ToS field (bits 5-7) of the packet is used instead of the QOS field in the VLAN tag. The mapping works in the same way, mapping high or low priority to the value of the ToS field.
  • Page 34 Description of options: Down prioritize web browsing, e-mail, FTP and news sets traffic on ports 80, 280, 443, 25, 110, 20, 21, 69, 119, and 2009 to low priority. Prioritize IP Telephony (VoIP) sets traffic on ports 1718, 1719, and 1720 to high priority. Prioritize iSCSI sets traffic on ports 3225, 3260, and 3420 to high priority.

  • Page 35: Snmp Configuration

    IP DiffServ Classification IP DiffServ Classification (Figure 3-21) works by prioritizing traffic based on the 8-bit Service Type field in each packet as defined by the IETF for differentiated services. Under the differentiated services interpretation, the first six bits comprise a codepoint, which is sometimes abbreviated DSCP, and the last two bits are left unused.

  • Page 36: Igmp Snooping

    Figure 3-22: SNMP Configuration Page SNMP: Used to Enable or Disable SNMP. The default is Enable. Get/Set/Trap Community: The community name is used as password for authentication. The switch will only communicate with the SNMP manager if the community strings are the same. Community name is user-definable with a maximum length of 15 characters and is case sensitive.

  • Page 37: Maximum Packet Length

    IGMP Snooping, multicast packet forwarding is effectively the same as broadcast packet forwarding. A switch that supports IGMP Snooping with query, report and leave functions based on a type of packet exchanged between the IP Multicast Router/Switch and IP Multicast Host can update the information in the Multicast table when a member (port) joins or leaves an IP Multicast Destination Address.

  • Page 38: Dhcp Boot

    Figure 3-24: Maximum Packet Length Page 3.9 DHCP Boot The DHCP Boot page (Figure 3-25) allows the user to configure the boot up and DHCP request delay for the switch. Enabling DHCP Broadcast Suppression will cause the switch to delay booting up for between 1 and 30 seconds to avoid overloading the DHCP server with requests in the event of a building-wide power failure.

  • Page 39: Tag-Based Group

    Tag-based: Tag-based VLANs are identified by its VLAN ID or VID. Instead of filtering by port, all packets coming into and out of the switch are filtered based on the VLAN ID in the packet, and are grouped accordingly. The switch supports 802.1Q tag-based VLANs. Each tag-based VLAN must be assigned a unique VLAN name and VLAN ID.

  • Page 40: Port-Based Group

    Figure 3-28: Tag-based Group Page To edit a group, select the group and click the “Edit” button at the bottom of the page. To add a new group, click “Add” at the bottom of the page. Enter the VLAN name as well as the VID, configure the SYM-VLAN and choose the member ports by checking the check boxes beside the desired port numbers, then click the “Apply”...

  • Page 41: Tag Rule

    Figure 3-30: Port-based Group Page To edit a group, select the group and click the “Edit” button at the bottom of the page. To add a new group, click “Add” at the bottom of the page. Enter a VLAN name and choose the member ports by checking the check boxes beside the desired port numbers, then click the “Apply”...

  • Page 42: Mac Table

    Figure 3-32: VLAN Tag Rule Page Port No: Port number. PVID: The PVID range is between 1-4094. Before you set a number x as PVID, you have to create a Tag- based VLAN with VID x. For example, if port x receives an untagged packet, the switch will apply the PVID (assume as VID y) of port x to tag this packet, the packet then will be forwarded as a tagged packet with VID y.

  • Page 43: Information

    3.11.1 Information The Information page (Figure 3-33) displays the current MAC address table in the switch including static and dynamic MAC entries. Figure 3-33: MAC Table Information Page Port: Select the port you would like to filter by. Search: Search by a specific MAC address or VID. MAC: Display the MAC address of the entry you selected from the search results.

  • Page 44: Maintenance Page

    3.11.2 Maintenance Page The Maintenance page (Figure 3-34) allows the user to set the aging time for dynamic MAC address entries, and flush all dynamic MAC address entries. Figure 3-34: MAC Table Maintenance Page Aging Time: An idle MAC address that has exceeded the MAC address aging time will be removed from the MAC address table.

  • Page 45: Static Filter

    VID: VLAN identifier. This only applies if tagged VLANs are enabled. Valid range is from 1-4094. Alias: Alias name for the MAC address. 3.11.4 Static Filter The Static Filter page (Figure 3-36) allows the user deny packet forwarding to specific MAC addresses. The static filter table contains a MAC address and VID.

  • Page 46: Gvrp Configuration

    Figure 3-37: MAC Alias Page MAC: A six-byte long Ethernet hardware address and expressed in hex and separated by hyphens. Alias: Alias name for the MAC address. Note: If there are too many MAC addresses in the table, it is recommended that you input the MAC address and alias name manually.
  • Page 47 Figure 3-38: GVRP Configuration Page GVRP State: Allows you to enable or disable GVRP. Join Time: The Join Time in centiseconds (one hundredths of a second). Valid time range is between 20- 100, default is 20. Leave Time: The Leave Time in centiseconds. Valid time range is between 60-300, default is 60. Leave All Time: A time period for announcements that all registered devices are going to be de- registered.

  • Page 48: Counter

    3.12.2 Counter The Counter page (Figure 3-39) displays the GVRP packets sent and received by the switch. Figure 3-39: GVRP Counter Page Total GVRP Packets: Total GVRP BPDU packets sent or received by the switch. Invalid GVRP Packets: Number of invalid GARP BPDU received by the switch. LeaveAll Message Packets: Number of GARP BPDU with a Leave All message sent or received by the switch.

  • Page 49: Stp Configuration

    3.13 STP Configuration The Spanning Tree Protocol (STP) is a standardized method (IEEE 802.1D) for avoiding loops in switched networks. When STP is enabled, the switch ensures that only one path is active between any two nodes on the network at a time. It is recommended that you enable STP on all switches to ensure a single active path on the network.

  • Page 50: Configuration

    Bridge Priority: The lower the bridge priority, the higher the priority it has. Usually, the bridge with the highest bridge priority is the root. If you want to have the SS2GD8I as the root bridge, you should set this value lower than that of the other bridges in the LAN. Valid values are from 0-61440. The default is 32768.

  • Page 51: Port

    seconds. Default is 20 seconds. Forward Delay: Set the root bridge forward delay time. This figure is set by the root bridge only. The forward delay time is defined as the time spent from Listening state moving to Learning state and also from Learning state moving to Forwarding state of a port in a bridge.

  • Page 52: Trunking Configuration

    a device that knows nothing about STP or RSTP. Usually, the connected device is an end station. Edge Ports will immediately transit to forwarding state and skip the listening and learning state because the edge ports cannot create bridging loops in the network. This will expedite the convergence. When the link on the edge port toggles, the STP topology remains unchanged.

  • Page 53: Port

    3.14.1 Port The Trunk Port Setting/Status page (Figure 3-44) is used to configure the trunk setting of each port in the switch. Figure 3-44: Trunk Port Setting/Status Page Method: Determines the method a port uses to aggregate with other ports. “None” means the port does is not aggregated with any other port.

  • Page 54: System Priority

    Figure 3-45: Aggregator View Page Aggregator: Shows the aggregator ID (from 1 to 8) of each port, which is the same as the port number. Method: Shows the method a port is using to aggregate with other ports. Member Ports: Shows all of the member ports of an aggregator port. Ready Ports: Shows only the ready member ports within an aggregator port.

  • Page 55: Configuration

    802.1X control, they must input their account name for authentication and wait for authorization first. The SS2GD8I only supports multi-host 802.1X authentication. In this mode, the devices connected to a port can only gain access to the network through this port after it has been authorized.

  • Page 56: Security

    Figure 3-49: 802.1X Mode Setting Page Port Number: Port number to configure. 802.1X Mode: 802.1X operation mode. Can either be “Disable” and “Multi-host” mode. In disable mode, no authentication is performed. In multi-hose mode, all supplicants must be authorized before connecting to the network.
  • Page 57 allows you to configure 802.1X details for the port (Figure 3-51). Figure 3-51: Parameter Setting Page Port: Port number being modified. Port Control: Used to set the operation mode for authorization. There are three modes supported, ForceUnauthorized, ForceAuthorized, Auto. ForceUnauthorized means the controlled port is always in the unauthorized state.

  • Page 58: Alarm Configuration

    3.16 Alarm Configuration 3.16.1 Events The Trap Events Configuration page (Figure 3-52) allows the user to select which events will be sent to the network administrator using which alert type. The switch supports 24 different trap events. The trap information can be sent out in three ways, email, mobile phone SMS (short message system) and SNMP traps.

  • Page 59: Email/Sms

    3.16.2 Email/SMS The Email/SMS Configuration page (figure 3-53) allows the user to configure the email and SMS settings for the switch to use to contact the network administrator. An email address and/or a mobile phone number has to be set in order for traps to be sent to users using those methods. The switch supports up to 6 email addresses and 6 mobile phone numbers.

  • Page 60: Configuration

    Password: The password for your ISP. Mobile Phone 1-6: The mobile phone numbers to send the alarm messages to. 3.17 Configuration The switch saves up to three version of the configuration file. The first is the factory default settings, the switch can be restored to these settings should any problems arise during configuration.

  • Page 61: Diagnostics

    Figure 3-55: Configure File Path Page Export File Path: The name and path to use when saving the file. Export Start: Export the switch’s startup configuration stored in flash to the local computer. Export User-Conf: Export the switch’s user configuration stored in flash to the local computer. Import File Path: The name and path to use when retrieving the file.

  • Page 62: Loopback

    3.18.2 Loopback The Loopback Test page (Figure 3-59) provides two different loopback tests. One is an Internal Loopback Test and the other is an External Loopback Test. The former test will not send test signals outside the switch. The test signal only tests the signals within the switch. The latter test sends the test signal to the device connected to the other end.

  • Page 63: Tftp Server

    3.19 TFTP Server The TFTP Server page (Figure 3-59) allows the user to set the TFTP server for the switch to use to send and receive files from a local computer on the network. Enter the IP address of the server and click “Apply”...

  • Page 64: Firmware Upgrade

    3.21 Firmware Upgrade The Firmware Upgrade page (Figure 3-61) allows you to update the firmware on the switch with new firmware that is provided by the manufacturer. Software upgrades typically improve the performance or increase the feature set of the switch. The switch requires a TFTP client running on a computer on the network for firmware upgrades.

  • Page 65: Logout

    3.23 Logout The Logout page (Figure 3-63) allows the user to log out of the web interface. Figure 3-63: Logout Page...

  • Page 66: Cli Interface

    Username: admin Password: admin After you login successfully, you will see a prompt “SS2GD8I#” if you are the first person to login and you have administrator rights, otherwise the prompt may appear as “SS2GD8I$“. The former means you have administrator rights and have full access to the switch. The latter means you only have guest rights and are only allowed to view the system without changing any settings.

  • Page 67: Cli Global Commands

    Description: Returns you to the root menu. When you enter this command, you will be returned to the root menu regardless of which submenu you are in. If you use this command while in the root menu, you will remain in the root menu. Arguments: None. Example: SS2GD8I# alarm SS2GD8I(alarm)# events SS2GD8I(alarm-events)# end SS2GD8I# exit Syntax: exit Description: Brings you up one menu level.
  • Page 68 Syntax: help Description: Shows a list of available commands. Some commands are a combination of two or more words. Arguments: None. Example: SS2GD8I# ip SS2GD8I(ip)# help Commands available: ------------<< Local commands >>------------ set ip Set ip,subnet mask and gateway...
  • Page 69 Arguments: [#] (optional): the number of history records to show, range from 1-256. Example 1: SS2GD8I(ip)# history Command history: 0. trunk 1. exit 2. SS2GD8I# trunk 3. SS2GD8I(trunk)# exit 4. SS2GD8I# 5. ? 6. trunk 7. exit 8. alarm 9.
  • Page 70 CLI prompt. After restoring to defaults, all of the changes in the system will be erased, and the unit will be reset to factory defaults after being rebooted. Arguments: None. Example: SS2GD8I# restore default Restoring ... Restore Default Configuration Successfully Press any key to reboot system.

  • Page 71: Local Commands Of Cli

    <port range>: which ports are affected, can be a single port (e.g. “1”) or a range of ports (e.g. “5-7”), range from 1-8. <times>: maximum number of tries, range from 1-10, default is 2. Example: SS2GD8I(802.1X)# set max-request 2 2...
  • Page 72 <port range>: which ports are affected, can be a single port (e.g. “1”) or a range of ports (e.g. “5-7”), range from 1-8. <mode>: 0 or 1 (off or on). Example: SS2GD8I(802.1X)# set mode 2 1 set port-control Syntax: set port-control <port-range> <authorized> Description: Set the 802.1X status of each port.
  • Page 73 <port range>: which ports are affected, can be a single port (e.g. “1”) or a range of ports (e.g. “5-7”), range from 1-8. <ebl>: 0 or 1 (disable or enable re-authentication). Example: SS2GD8I(802.1X)# set reAuthEnabled 2 1 set reAuthMax Syntax: set reAuthMax <port-range> <max> Description: The number of re-authentication attempts that are permitted before the port becomes Unauthorized.
  • Page 74 <port-number>: the service port (authorization port) of the Radius Server, from 1-65535, default is 1812 <secret-key>: the value of the secret-key which has to have a length between 1 and 31 characters Example: SS2GD8I(802.1X)# set state 192.168.1.115 1812 WinRadius set suppTimeout Syntax: set suppTimeout <port-range> <sec>...
  • Page 75 <port range>: which ports are affected, can be a single port (e.g. “1”) or a range of ports (e.g. “5-7”), range from 1-8. <sec>: timer, range from 1-65535, default is 30. Example: SS2GD8I(802.1X)# set txPeriod 2 30 show mode Syntax: show mode Description: Displays the mode of each port.
  • Page 76 Syntax: show parameter Description: Displays the parameter settings of each port. Arguments: None Example: SS2GD8I(802.1X)# show parameter port 1) port control : Auto reAuthMax txPeriod : 30 Quiet Period : 60 reAuthEnabled : ON reAuthPeriod : 3600 max. Request...
  • Page 77 Syntax: show security Description: Displays the authentication status of each port. Arguments: None Example: SS2GD8I(802.1X)# show security Port Mode Status ====== ============ ============== Disable Multi-host Unauthorized Disable Disable Disable Disable show state Syntax: show state Description: Shows the Radius server configuration...
  • Page 78 Syntax: del <name> Description: Deletes an existing user account. Arguments: <name>: existing user account name. Example: SS2GD8I(account)# del aaaaa Account aaaaa deleted modify Syntax: modify <name> Description: Changes the username and password of an existing account. Arguments: <name>: existing user account name.
  • Page 79 Description: Sets up an email address. Arguments: <#>: email address number, range from 1 to 6. <mail address>: email address Example: SS2GD8I(alarm-email)# set mail-address 1 abc@mail.abc.com set server Syntax: set server <ip> Description: Sets the IP address of the email server. Arguments: <ip>: email server IP address or domain name...
  • Page 80 Description: Sets the account and password of the email server. After you enter the user name, you will be prompted for the password. Arguments: <username>: email server account and password Example: SS2GD8I(alarm-email)# set user admin show Syntax: show Description: Displays the e-mail alerts configuration. Arguments: None.
  • Page 81 <range>: which events to delete, can be a single event (e.g. “1”) or a range of events (e.g. “5-7”), range from 1-24. Example: SS2GD8I(alarm-events)# del email 1-3 del sms Syntax: del sms <range> Description: Disables events from being sent out via SMS.
  • Page 82 <range>: which events to delete, can be a single event (e.g. “1”) or a range of events (e.g. “5-7”), range from 1-24. Example: SS2GD8I(alarm-events)# set email 1-3 set sms Syntax: set sms <range> Description: Enables events to be sent out via SMS.
  • Page 83 Syntax: show Description: Displays the configuration of alarm events. Arguments: None. Example: SS2GD8I(alarm-events)# show Events Email SMS Trap ----------------------------------------- Cold Start Warm Start Link Down Link Up Authentication Failure User Login User Logout STP Topology Changed STP Disabled 10 STP Enabled...
  • Page 84 Description: Removes the configuration of an SMS server including user account and password. Arguments: None. Example: SS2GD8I(alarm-sms)# del server-user set phone-number Syntax: set phone-number <#> <phone-number> Description: Adds an SMS phone number. Arguments: <#>: SMS slot number, range from 1 to 6 <phone-number>: phone number Example: SS2GD8I(alarm-sms)# set phone-number 1 8181234567...
  • Page 85 Description: Sets the IP address of the SMS server. Arguments: <ip>: SMS server IP address or domain name Example: SS2GD8I(alarm-sms)# set server 192.168.1.7 set user Syntax: set user <username> Description: Sets the user account and password of the SMS server.
  • Page 86 <port range>: which ports to change, can be a single port (e.g. “1”) or a range of ports (e.g. “5-7”), range from 1-8. Example: SS2GD8I(bandwidth)# disable egress-rate 1-8 disable ingress-rate Syntax: disable ingress-rate <port range> Description: Cancels the ingress-rate setting of a port.
  • Page 87 <port range>: which ports to change, can be a single port (e.g. “1”) or a range of ports (e.g. “5-7”), range from 1-8. <data rate>: the egress-rate limit in Mbps, range from 0-1000 Example: SS2GD8I(bandwidth)# enable egress-rate 1-8 200 enable ingress-rate Syntax: enable ingress-rate <range> <data rate> Description: Sets the ingress-rate of a port.
  • Page 88 Description: Sets the path and filename that settings will be exported to (relative to the root directory of the TFTP server). Arguments: <file path>: path and file name Example: SS2GD8I(config-file)# set export-path log/21511.txt export start Syntax: export start Description: Exports startup settings to the file defined using set export-path. Arguments: None.
  • Page 89 Description: Sets the path and filename that settings will be imported from (relative to the root directory of the TFTP server). Arguments: <file path>: path and filename Example: SS2GD8I(config-file)# set import-path log/21511.txt import start Syntax: import start Description: Imports startup settings from the file defined using set import-path. Arguments: None.
  • Page 90 Description: Sets the delay time for DHCP Boot. Arguments: <sec>: delay in seconds, range from 0-30, a value of 0 will disable dhcp-boot delay. Example: SS2GD8I(dhcp-boot)# set dhcp-boot 30 show Syntax: show Description: Displays the status of DHCP Boot. Arguments: None.
  • Page 91 Syntax: ping <ip> Description: Tests if the switch is able to ping a specific IP address or domain. Arguments: <ip>: IP address or domain name (e.g. 192.168.0.100 or www.yahoo.com) Example: SS2GD8I(diag)# ping 192.168.1.115 Gateway : 192.168.1.253 192.168.1.115 is alive.
  • Page 92 Description: To set up the image file that will be upgraded. Arguments: <file path>: upgrade file path (relative to the root directory of the TFTP server). Example: SS2GD8I(firmware)# set upgrade-path gs2108c_SS2GD8I_v2.03.img show Syntax: show Description: Displays information for the TFTP server and upgrade path.
  • Page 93 Syntax: enable Description: Enables GVRP. Arguments: None. Example: SS2GD8I(gvrp)# enable...
  • Page 94 <group number>: the VID of the GVRP group number to select, range from 1-4094 Example: SS2GD8I(gvrp)# show group GVRP group information Current Dynamic Group Number: 1 Member Port ---- -------------------------------------------------- SS2GD8I(gvrp)# group 2 SS2GD8I(gvrp-group-2)# set applicant 1-6 non-participant SS2GD8I(gvrp-group-2)# show GVRP group VID: 2 Port Applicant Registrar ---- --------------- ---------...
  • Page 95 <port range>: which ports to change, can be a single port (e.g. “1”) or a range of ports (e.g. “5-7”), range from 1-8. <type>: applicant type, can be “normal” or “non-participant” Example: SS2GD8I(gvrp)# set applicant 1-8 non-participant set registrar Syntax: set registrar <port range> <type> Description: Sets the default registrar mode for each port.
  • Page 96 <join>: join timer, range from 20 to 100. <leave>: leave timer, range from 60 to 300. Leave Time must equal to or greater than double the Join Time. <leaveall>: leaveall timer, range from 1000 to 5000. Example: SS2GD8I(gvrp)# set timer 2-8 25 80 2000...
  • Page 97 Syntax: show counter <port> Description: Display the counter number of a port. Arguments: <port>: port number, range from 1 to 8. Example: SS2GD8I(gvrp)# show counter 2 GVRP Counter port: 2 Counter Name Received Transmitted -------------------- -------- ----------- Total GVRP Packets...
  • Page 98 > igmp set igmp_snooping Syntax: set igmp_snooping <status> Description: Set the mode for IGMP Snooping. Arguments: <status>: IGMP snooping status, can be one of the following: 0 for disabled, 1 for active, or 2 for passive. Example: SS2GD8I(igmp)# set igmp-snooping 2...
  • Page 99 <dns>: set DHCP by using manual or auto mode, can be “manual” or “auto”. Example: SS2GD8I(ip)# enable dhcp manual set dns Syntax: set dns <ip> Description: Sets the IP address of DNS server. Arguments: <ip>: IP address of DNS server. Example: SS2GD8I (ip)# set dns 168.95.1.1...
  • Page 100 <ip>: IP address. <mask>: subnet mask. <gateway>: default gateway. Example: SS2GD8I(ip)# set ip 192.168.1.2 255.255.255.0 192.168.1.253 show Syntax: show Description: Displays the system’s DHCP function state, IP address, subnet mask, default gateway, DNS mode, DNS server IP address and current IP address.
  • Page 101 Syntax: enable auto-upload Description: Enables auto-upload of the log. Arguments: None. Example: SS2GD8I(log)# enable auto-upload show Syntax: show Description: Shows a list of trap log events. Up to 120 log records are saved by the switch. Arguments: None.
  • Page 102 <mac>: MAC address, format: 01-02-03-04-05-06, '?' can be used as a wildcard <vid>: VLAN ID, range from 1 to 4094; '?' as a wildcard, or 0 as untagged Example: SS2GD8I(mac-table-information)# search 1-8 ??-??-??-??-??-?? ? MAC Table List Alias MAC Address...
  • Page 103 Description: Sets the aging time of MAC addresses that are learned dynamically. Arguments: <#>: age-timer in seconds, range from 10 to 65535, or 0 to disable aging Example: SS2GD8I(mac-table-maintain)# set aging 300 set flush Syntax: set flush Description: Deletes all MAC addresses that are learned dynamically.
  • Page 104 <vid>: VLAN ID, range from 0-4094. VID must be 0 if VLAN mode is not tag-based. [alias] (optional): MAC alias name, maximum 15 characters Example: SS2GD8I(mac-table-static-mac)# add 00-02-03-04-05-06 3 0 aaa Syntax: del <mac> <vid> Description: Deletes a static MAC address entry.
  • Page 105 <type> (optional): Access type for user, can be “h” for HTTP, “s” for SNMP, “t” for Telnet, or “any”, or a combination of two of the three, separated by a comma, default is “any”. action <action>: a(ccept) or d(eny). Example: SS2GD8I(management-add)# set name Mary vid 20 ip 192.168.1.1-192.168.1.90 port 2-5,8 type h,s action a SS2GD8I(management-add)# show #: 1...
  • Page 106 “any”. action <action>: a(ccept) or d(eny). Example: SS2GD8I(management)# edit 1 SS2GD8I(management-edit-1)# set name Tom vid 2 ip 192.168.1.30- 192.168.1.80 port 1-2 type s action d SS2GD8I(management-edit-1)# show #: 1...
  • Page 107 <port range>: which ports to change, can be a single port (e.g. “1”) or a range of ports (e.g. “5-7”), range from 1-8. <length (bytes)>: maximum packet length, can be 1518, 1532, or 9208. Example: SS2GD8I(max-pkt-len)# set len 1-8 9208 show Syntax: show Description: Shows the current maximum packet length setting.
  • Page 108 <port range>: which ports to change, can be a single port (e.g. “1”) or a range of ports (e.g. “5-7”), range from 1-8. Example: SS2GD8I(mirror)# set monitored-port 3-5,8 set monitoring-port Syntax: set monitoring-port <#> Description: Sets the port that will receive the mirrored packets. Administrators can view the packets that the monitored port(s) receives via this port.
  • Page 109 <port range>: which ports to change, can be a single port (e.g. “1”) or a range of ports (e.g. “5-7”), range from 1-8. Example: SS2GD8I (port)# disable flow-control 6 disable state Syntax: disable state <port range> Description: Disables a port(s).
  • Page 110 100half - set speed/duplex 100M Half 100full - set speed/duplex 100M Full 1Gfull - set speed/duplex 1G Full Example: SS2GD8I(port)# set speed-duplex 5 auto show conf Syntax: show conf Description: Displays each port’s state, speed-duplex and flow control. Arguments: None.
  • Page 111 Syntax: show sfp <port> Description: Displays information on the SFP module. Arguments: <port>: SFP port, can be 7 or 8 Example: SS2GD8I (port)# show sfp 7 Port 7 SFP information -------------------------------------------------------------- Connector Type : SFP - LC Fiber Type...
  • Page 112 <default>: default class (all other TCP/UDP ports), can be 1 (high) or 0 (low). <match>: special TCP/UDP class, can be 1 (high) or 0 (low). Example: SS2GD8I(qos)# set advance-layer4 5 2 80 1 0 set default Syntax: set default <class>...
  • Page 113 1-8. <tag-range>: tag priority level, can be a single level (e.g. “1”) or a range of levels (e.g. “5-7”), range from 0-7. <class>: class of service, can be 1 (high) or 0 (low). Example: SS2GD8I(qos)# set pri-tag 1-7 1-2 1...
  • Page 114 1-8. <tos-range>: ToS precedence field, can be a single number (e.g. “1”) or a range of numbers (e.g. “5-7”), range from 0-7. <class>: class of service, can be 1 (high) or 0 (low). Example: SS2GD8I(qos)# set tos 1-5 0-3 0...
  • Page 115 Syntax: show Description: Displays the information of the active QoS mode. Arguments: None. Example: SS2GD8I (qos)# show IP Diffserv Classification Default Class:high DiffServ Class DiffServ Class DiffServ Class DiffServ Class -------- ----- -------- ----- -------- ----- -------- ----- high...
  • Page 116 Arguments: <#>: trap number, range from 1-6. <ip>: IP address or domain name. <port>: trap port, range from 1-65535. <community>:trap community name. Example: SS2GD8I(snmp)# set get-community public SS2GD8I(snmp)# set set-community private SS2GD8I(snmp)# set trap 1 192.168.1.1 162 public...
  • Page 117 Description: Forces the port to transmit RST BPDUs. Arguments: <port range>: which ports to change, can be a single port (e.g. “1”) or a range of ports (e.g. “5-7”), range from 1-8. Example: SS2GD8I(stp)# Mcheck 1-8 disable Syntax: disable Description: Disables STP. Possible values: None.
  • Page 118 <edge_port>: admin edge port, can be “yes” or “no”. <admin p2p>: admin point to point, can be “auto”, “|true”, or “false”. Example: SS2GD8I(stp)# set port 1-8 0 128 yes auto set version Syntax: set version <ver> Description: Set the STP version.
  • Page 119 Syntax: show config Description: Displays the STP configuration. Arguments: None Example: SS2GD8I(stp)# show config STP State Configuration Spanning Tree Protocol : Enabled Bridge Priority (0-61440) : 61440 Hello Time (1-10 sec) Max. Age (6-40 sec) : 20 Forward Delay (4-30 sec)
  • Page 120 Syntax: set contact <contact> Description: Sets the contact description for the switch. Arguments: <contact>: a string of up to 40 characters. Example: SS2GD8I(system)# set contact networkadmin set device-name Syntax: set device-name <device-name> Description: Sets the device name description for the switch. Arguments: <device-name>: a string of up to 40 characters.
  • Page 121 Syntax: set location <location string> Description: Sets the location description for the switch. Arguments: <location>: a string of up to 40 characters. Example: SS2GD8I(system)# set location HQ show Syntax: show Description: Displays the basic information for the switch. Arguments: None...
  • Page 122 <hr>: daylight saving hour differential, range: -5 to +5 <MM/DD/HH>: daylight saving start month (01-12), day (01-31), and hour (00-23) <mm/dd/hh>: daylight saving end month (01-12), day (01-31), and hour (00-23) Example: SS2GD8I(time)# set daylightsaving 3 10/12/01 11/12/01 Save Successfully set manual Syntax: set manual <YYYY/MM/DD> <hh:mm:ss>...
  • Page 123 Description: Sets the current time via an NTP server. Arguments: <ip>: IP address or domain name of NTP server. <timezone>: time zone (GMT), range from -12 to +13 Example: SS2GD8I(time)# set ntp clock.via.net -5 Synchronizing...(1) Synchronization success show Syntax: show Description: Shows the time settings.
  • Page 124 <group>: range from 1-8. <active LACP>: can be “active” to set the LACP to active mode or “passive” to set the LACP to passive mode Example: SS2GD8I(trunk)# set trunk 1-4 lacp 1 active show aggtr-view Syntax: show aggtr-view Description: Displays the aggregator list.
  • Page 125 Syntax: show lacp-detail <aggtr> Description: Displays detailed information for the LACP trunk group. Arguments: <aggtr>: aggregator, range from 1 to 8 Example: SS2GD8I(trunk)# show lacp-detail 2 Aggregator 2 Information: Actor Partner --------------------------------- ----------------------------- System Priority MAC Address System Priority...
  • Page 126 Syntax: del port-group <name> Description: Deletes a port-based VLAN group. Arguments: <name>: the VLAN group to delete. Example: SS2GD8I(vlan)# del port-group VLAN-2 del tag-group Syntax: del tag-group <vid> Description: Delete a tag-based VLAN group. Arguments: <vid>: the VLAN group to delete, range from 1 to 4094...
  • Page 127 <port range>: which ports to change, can be a single port (e.g. “1”) or a range of ports (e.g. “5-7”), range from 1-8. Possible values: <range>: 1 to 8 Example: SS2GD8I(vlan)# disable drop-untag 5-8 disable sym-vlan Syntax: disable sym-vlan <port range> Description: Disables dropping of frames from non-member port(s).
  • Page 128 1-8. <role>: can be “access” to not tag frames, “trunk” to tag all frames, or “hybrid” to tag all frames except a specific VID. [vid] (optional): untag-VID for hybrid port, range from 1-4094. Example: SS2GD8I(vlan)# set port-role 5 hybrid 6...
  • Page 129 <range>: VLAN group members, can be a single number (e.g. “1”) or a range of numbers (e.g. “5-7”), range from 1-8. <#>: Can be 1 for symmetric VLAN or 0 for asymmetric VLAN. Example: SS2GD8I(vlan)# set tag-group 2 VLAN-2 2-5,6,8 0 show group Syntax: show group Description: Displays the VLAN mode and groups.
  • Page 130 Syntax: show pvid Description: Displays pvid and ingress/egress rules. Arguments: None. Example: SS2GD8I(vlan)# show pvid Port PVID Rule1 Rule2 Port Rule Untag Vid ------ ------ --------- --------- ----------- ----------- Disable Disable Access Disable Disable Access Disable Disable Access...
  • Page 131 Syntax: set gid <gid> Description: Sets the group ID. Arguments: <gid>:Group ID Example: SS2GD8I(vs)# set gid group1 set role Syntax: set role <role> Description: Sets the role. Arguments: <role>: can be “master” to act as master or “slave” to act as slave.

  • Page 132: Troubleshooting

    5 Troubleshooting 5.1 Resolving Connection Problems Possible causes a connection problem where the Link LED does not light up even though the cable is connect are: • The attached device is not powered on. • The cable may not be the correct type or is defective. •...

  • Page 133: Appendix A: Technical Specifications

    Appendix A: Technical Specifications Features • 6 (10/100/1000Mbps) Gigabit Ethernet ports that are compliant with IEEE802.3, 802.3u, 802.3z and 802.3ab. • 2 Gigabit Combo-SFP copper/fiber ports dual media ports automatically detect which cable is connected. • Non-blocking store-and-forward shared-memory switch. •...
  • Page 134 • Transmission Mode: 10/100Mbps supports full or half duplex, 1000Mbps supports full duplex only • Transmission Speed: 10/100/1000Mbps for Copper, 1000Mbps for Fiber • Full Forwarding/Filtering Packet Rate: PPS (packets per second) Forwarding Rate Speed 1,488,000 PPS 1000 Mbps 148,800 PPS 100 Mbps 14,880 PPS 10 Mbps...
