24-Port 10/100Mbps Dual-Speed Switch User’s Guide Version 1.0 P/N: ATM020423SR24 Rev.A This User's Guide contains important information regarding the installation of your switch. Please read it completely before beginning installation. For future reference, record the serial number of your network switch in the space below: SERIAL number The serial number is located on the bottom of the switch.
Page 2
Amer.com, as stipulated by the United States Copyright Act of 1976. Amer.com reserves the right to make changes to this document and the products which it describes without notice. Amer.com shall not be liable for technical or editorial errors or omissions made herein;...
Page 3
• Consult the dealer or an experienced radio/TV technician for help. Shielded interface cables must be used in order to comply with emission limits. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. For more information please contact the Federal Communication Commission.
BOUT UIDE Congratulations on your purchase of the 24-port 10/100Mbps Auto-negotiation Fast Ethernet Switch. This device integrates 100Mbps Fast Ethernet and 10Mbps Ethernet network capabilities in a highly flexible package. Purpose This guide discusses how to install your 24-port 10/100Mbps Fast Ethernet Switch.
NTRODUCTION This chapter describes the features of the Switch and some background information about Ethernet/Fast Ethernet switching technology. Fast Ethernet Technology The growing importance of LANs and the increasing complexity of desktop computing applications are fueling the need for high performance networks. A number of high-speed LAN technologies have been proposed to provide greater bandwidth and improve client/server response times.
Switching Technology Another approach to pushing beyond the limits of Ethernet technology is the development of switching technology. A switch bridges Ethernet packets at the MAC address level of the Ethernet protocol transmitting among connected Ethernet or Fast Ethernet LAN segments. Switching is a cost-effective way of increasing the total network capacity available to users on a local area network.
Features The Switch is designed for easy installation and high performance in an environment where traffic on the network and the number of users increase continuously. The Switch with its rack size is specifically designed for middle to large workgroups. The Switch provides immediate access to a rapidly growing network through a wide range of user-reliable functions.
Page 9
Supports Auto-MDI/MDI-X for each port Wire speed reception and transmission Store-and-Forward switching method Integrated address Look-Up Engine, supports 8K absolute MAC addresses Supports 2.5Mbytes RAM for data buffering Front-panel diagnostic LEDs Broadcast storm protection IEEE 802.3x flow control for full-duplex Back pressure flow control for half-duplex Standard 19”...
NPACKING AND NSTALLATION This chapter provides unpacking and setup information for the Switch. Unpacking Open the shipping carton of the Switch and carefully unpack its contents. The carton should contain the following items: The 24-port 10/100Mbps Fast Ethernet Switch One AC power cord, suitable for your area’s electrical power connections Four rubber feet to be used for shock cushioning Screws and two mounting brackets...
Rack Mounting The switch can be mounted in an EIA standard-size, 19-inch rack, which can be placed in a wiring closet with other equipment. Attach the mounting brackets at the switch’s front panel (one on each side), and secure them with the provided screws.
DENTIFYING XTERNAL OMPONENTS This section identifies all the major external components of the switch. Front Panel The figure below shows the front panels of the switch. 10/100Mbps Dual Speed Switch 11 12 13 14 15 16 17 18 19 20 21 22 23 24 LINK Power 100Mbps...
Twisted-Pair Ports These ports support the automatic MDI/MDIX crossover detection function which provides true ‘plug and play’ capability without the need of confusing crossover cables or crossover ports. With the Auto-MDI function, you simply plug-in the network cable to the unit directly with no need to care if the end node is a NIC (Network Interface Card) or switches and hubs.
Amer.com Warranty Policy Limited Lifetime Warranty In the event of a defect in quality or workmanship, Amer.com will repair or replace any hardware product sold by Amer.com with new or reconditioned parts free of charge in North America for a limited lifetime period unless otherwise specified on the sales invoice from the date of original purchase.
Page 17
Any future upgrades, including (but not limited to) hardware and software are not covered by this limited warranty. If a hardware problem with this product develops during the warranty period, you may contact the Amer.com Service Center Telephone...
