SD7fx1 8-Port 10/100
Switch with Fiber Port
User's Guide
Version 1.0
P/N: ATSD7fx1 -0107 Rev.A
This User's Guide contains important information
regarding the installation of your switch. Please read
it completely before beginning installation.
For future reference, record the serial number
of your network switch in the space below:
SERIAL number
The serial number is located on the bottom of the switch.
Advertisement
Table of Contents
Related Manuals for Amer.com SD7fx1
Summary of Contents for Amer.com SD7fx1
- Page 1 SD7fx1 8-Port 10/100 Switch with Fiber Port User’s Guide Version 1.0 P/N: ATSD7fx1 -0107 Rev.A This User's Guide contains important information regarding the installation of your switch. Please read it completely before beginning installation. For future reference, record the serial number...
- Page 2 Amer.com, as stipulated by the United States Copyright Act of 1976. Amer.com reserves the right to make changes to this document and the products which it describes without notice. Amer.com shall not be liable for technical or editorial errors or omissions made herein; nor for incidental or consequential damages resulting from the furnishing, performance, or use of this material.
- Page 3 more o f the following measures: ? ?Reorient or relocate the receiving antenna. ? ?Increase the separation between the equipment and receiver. ? ?Connect the equipment into an outlet on a circuit different from that to which the receiver is connected to. ? ?Consult the dealer or an experienced radio/TV technician for help.
-
Page 4: Table Of Contents
ABLE OF ONTENTS ABOUT THIS GUIDE ............. 1 ..............1 URPOSE ............1 ERMS SAGE ’ ......1 VERVIEW OF THIS UIDE INTRODUCTION............2 ......... 2 THERNET ECHNOLOGY ......... 3 WITCHING ECHNOLOGY ..............4 EATURES UNPACKING AND SETUP ..........6 .............. -
Page 6: About This Guide
BOUT UIDE Congratulations on your purchase of the 8 -Port 10/100Mbps NWay Ethernet Switch. This device integrates 100Mbps Fast Ethernet and 10Mbps Ethernet network capabilities in a highly flexible desktop package. Purpose This manual discusses how to install your 8-Port 10/100Mbps NWay Ethernet Switch. -
Page 7: Introduction
NTRODUCTION This chapter describes the features of the Switch and some background information about Ethernet/Fast Ethernet switching technology. Fast Ethernet Technology The growing importance of LANs and the increasing complexity of desktop computing applications are fueling the need for high performance networks. A number of high -speed LAN technologies have been proposed to provide greater bandwidth and improve client/server response times. -
Page 8: Switching Technology
Switching Technology Another approach to pushing beyond the limits of Ethernet technology is the development of switching technology. A switch bridges Ethernet packets at the MAC address level of the Ethernet protocol transmitting among connected Ethernet or Fast Ethernet LAN segments. Switching is a cost-effective way of increasing the total network capacity available to users on a local area network. -
Page 9: Features
characterized by higher latencies. Routers have also been used to segment local area networks, but the cost of a router, and the setup and maintenance required, make routers relatively impractical. Today switches are an ideal solution to most kinds of local area network congestion problems. Features The Switch was designed for easy installation and high performance in an environment where traffic on the network... - Page 10 the transmit and receive nodes to guarantee against all possible packet loss. The Switch is a managed 10/100 Fast Ethernet Switch that offers solutions in accelerating small Ethernet workgroup bandwidth. Other key features are: ?? Supports one 100BASE -FX multimode fiber port for long distance connection, up to 2km in full-duplex mode.
-
Page 11: Unpacking And Setup
NPACKING AND ETUP This chapter provides unpacking and setup information for the Switches. Unpacking Open the shipping cartons of the Switch and carefully unpack its contents. The carton should contain the following items: One 8-Port 10/100Mbps NWay Ethernet Switch One external power adapter This User’s Guide If any item is found missing or damaged, please contact your supplier for replacement. -
Page 12: Identifying External Components
D E N TIFYING XTERNAL OMPONENTS This section identifies all the major external components of the Switch. Both the front and rear panels are shown followed by a description of each panel feature. The indicator panel is described in detail in the next chapter. Front Panel The figure below shows the front panel of the switch. -
Page 13: Rear Panel
Rear Panel Duplex mode selection switch for fiber port 1 - FX 5VDC/2.4A 10/100Mbps NWay Ethernet MDI-X RJ-45 Ports 100BASE-FX Fiber Port DC Power Jack DC Power Jack: Power is supplied through an external AC power adapter. Since the switch does not include a power switch, plugging its power adapter into a power outlet will immediately power it on. -
Page 14: Technical Specifications
ECHNICAL PECIFICATIONS General Standards IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE -TX Fast Ethernet ANSI/IEEE Std. 802.3 NWay Auto-negotiation Protocol CSMA/CD Data Ethernet: 10Mbps , 20Mbps (half duplex) (full-duplex) Transfer Fast Ethernet: 100Mbps , 200Mbps (half duplex) (full- duplex) Rate Topology Star Network... - Page 15 Physical and Environmental DC inputs 5VDC/2.4A Power 12 watts. (max.) Consumption Operating: 0 ? ~ 50? C, Storage: -10? ~ 70? C Temperature Humidity Operating: 10% ~ 90%, Storage: 5% ~ 90% Dimensions 171 x 98 x 29 mm (W x H x D) EMI: FCC Class B, CE Mark B, VCCI-B Performance...
- Page 16 Amer.com Warranty Policy Limited Lifetime Warranty In the event of a defect in quality or workmanship, Amer.com will repair or replace any hardware product sold by Amer.com with new or reconditioned parts free of charge in North America for a limited lifetime period unless otherwise specified on the sales invoice from the date of original purchase.
- Page 17 Limits and Expectations There are no express warranties except as listed above. Network products by Amer.com shall not be liable for incidental or consequential damages resulting from the use of this product. Any future upgrades, including (but not limited to) hardware and software are not covered by this limited warranty. If a hardware pro blem with this product develops during the warranty period, you may contact the Amer.com Service Center at:...
