Summary of Contents for Comfort audio Comfort Digisystem DH10
- Page 1 Comfort Digisystem User Manual Receiver DH10 English...
-
Page 2: Table Of Contents
User manual Table of contents Page Introduction to the Comfort Digisystem Functions of the Receiver DH10 Getting started First time use Menu and settings More functions Radio range and channels Attached accessories Other original accessories Trouble shooting Service and warranty... -
Page 3: Introduction To The Comfort Digisystem
The products are easy to use, whether you use a hearing aid or not. Before using the product, please read this User manual carefully. With the Receiver DH10 receiver, the signal is received digitally, resulting in an excellent clear sound. -
Page 4: Functions Of The Receiver Dh10
Functions of the Receiver DH10 Socket for neckloop Function indicator Volume button + Volume button - Charging socket On / Off Menu control Pairing button Socket for headphones/earphones Display indicating Display indicating connected active neckloop headphones/earphones Receiver DH10... -
Page 5: Getting Started
Getting started Charging The Receiver DH10 is chargeable. Charge the DH10 at least two hours be- fore you use it for the first time. An empty battery is fully charged within two hours. During charging, the function indicator shows red and a lightning bolt appears through the battery symbol in the display. -
Page 6: First Time Use
Press in the contacts to the end. Check that the neck loop is connected firmly. When putting on/taking off the receiver connected to the neck loop, be careful that the contacts do not break off. Receiver DH10... - Page 7 Adjust the volume with the volume buttons. If you listen with a neckloop and a hearing aid, set the hearing aid to the T or MT position. Other functions are explained later in this manual. With neckloop With neckloop and earphones Receiver DH10...
-
Page 8: Menu And Settings
On the following pages the Channel content will be presented as Pair well as how to change the Sound settings. Balance Max volume Fix volume Settings PIN-code Charge Language Name Button sound Func. indicator Factory Reset Key lock About Receiver DH10... - Page 9 Comfort Digisystem unit with a display. Pairing (via pairing button) To pair units without a display, see section for more information. Pairing information or a new code key can be received by several activated units. Receiver DH10...
- Page 10 Sound Balance If you use the Receiver DH10 with head- or earphones, you can adjust the balance for the right end left ear with the menu control (scroll up or down). Press the menu control to return to the menu.
- Page 11 Here you can select the menu language. Name Here the text to be displayed is selected. Choose symbols with the menu control. Select to save and to close without saving. To move the cursor during editing, use the symbols > and <. Receiver DH10...
- Page 12 Key lock Here you can activate the key lock and thereby lock all buttons. Once the key lock has been activated, Unlock keys? appears in the display. Select Yes to unlock. About Here you find software information. Receiver DH10...
-
Page 13: More Functions
Once the unit has been set to receive pairing information, the indicator flashes green quickly. When receiving pairing information, the indicator shows green for three seconds. When sending pairing information, the indicator flashes red five times. If the radio signal is weak, the indicator flashes red. Receiver DH10... -
Page 14: Radio Range And Channels
In addition to channels 1-3, under Extended there are several channels in bands A-F, which require a licence in most European countries: 768 - 790 MHz B 854 - 863 MHz 790 - 800 MHz D 800 - 820 MHz 820 - 854 MHz 865 - 872 MHz Receiver DH10... -
Page 15: Attached Accessories
Charging stand Charging stand to connect to the charger supplied. Desk stand Desk stand for the Receiver DH10. Short neckloop A shorter neckloop for the Receiver DH10 is also available. Headphones/earphones For other accessories, please visit our website, www.comfortaudio.com Receiver DH10... -
Page 16: Trouble Shooting
The unit will not start during charging Disconnect the charger. Choose Settings - Charge - Auto power off in the menu. When using with a hearing aid, make sure that it works both in the T and the MT position. Receiver DH10... -
Page 17: Service And Warranty
Under normal use, battery lifetime is up to five years. Contact your point of purchase once it is time to change the battery. You are always welcome to contact us at Comfort Audio if you have any questions. Technical Data Type of receiver: SST –... -
Page 18: Important Safety Instructions
9) Protect the power cord from being walked on or pinched particularly at plugs convenience receptacles. and the point where they exit from the apparatus. 10) Only use attachments/accessories specified by Comfort Audio AB. 11) Unplug this apparatus during Iightning storms or when unused for long periods of time. - Page 19 19) Never charge product in closed, unaired spaces such as handbags, cases or other closed storage bags. 20) Only use batteries and power supply specified by Comfort Audio AB. 21) You must not change the battery yourself; please contact your point of purchase.
- Page 20 Manufactured by: Comfort Audio AB Box154, SE-301 05 Halmstad, Sweden Tel. +46 (0)35 260 16 00 Fax +46 (0)35 260 16 50 info comfortaudio.com www.comfortaudio.com...
