- Page 1 Comfort Digisystem User Manual SecureStream Technology Receiver DE10 English...
-
Page 2: Table Of Contents
User Manual Table of Contents Page Introduction of the Comfort Digisystem Presenting the Receiver DE10 Functions of the Receiver DE10 Getting Started First Time Use Settings Pair More Functions Radio Range and Channels Attached Accessories Other Original Accessories Trouble Shooting... -
Page 3: Introduction Of The Comfort Digisystem
Presenting the Receiver DE10 The Receiver DE10 is a small, flexible receiver which is attached directly to the ear, usable with or without all-in-the-ear – hearing aids. The re- ceiver can be used on both right and left ear. -
Page 4: Functions Of The Receiver De10
Functions - Receiver DE10 Adjustable earloop Pairing button Volume button + Volume button - On / Off Function indicator Loudspeaker Charging socket Receiver DE10... -
Page 5: Getting Started
Getting started Charging The Receiver DE10 is chargeable. Charge the DE10 at least 2 hours before you use it for the first time. An empty battery is fully charged within 2 hours. During charging, the function indicator shows red. When the function in- dicator shows green, the unit is fully charged and switches to automatic float charging. -
Page 6: First Time Use
The earloop should not be bent. The illustration shows the ideal setting of the DE10 at the ear At delivery, the DE10 is ready to use at the right ear, but by turning around the earloop it can be used at the left ear. - Page 7 (+ and -) at the long side of the unit. Switch off the DE10 by pressing the On/Off-button for around 2 seconds until the indicator’s red light switches off. The necklace can be used as shown in the following illustration...
-
Page 8: Settings
Settings As the DE10 does not have a display/menu, the unit’s functions are con- trolled by means of the pairing button. The current function is shown by the function indicator. In addition to the pairing functions (see section Pairing), three other functions can be activated. - Page 9 Press the pairing button and shortly after the volume [+] button. Keep both buttons pressed for about 10 seconds until the function indicator flashes red 5 times. Now the volume can be raised as much as you want. Factory reset deactivates max volume Receiver DE10...
-
Page 10: Pair
Pair Receiver DE10 must be paired using the pairing button, see section Pairing (via pairing button) Pairing To use a receiver and transmitter together, they must be paired. All transmitters and receivers are default paired at the factory and will work together. - Page 11 Units with both transmitters and receivers built in Comfort Digisystem units with both transmitters and receivers built-in can be paired separately. When opening the pairing menu, choose the concerning unit (transmit- ter/receiver). In units with both transmitters and receivers, the pairing button controls the transmitter.
-
Page 12: More Functions
Function indicator (LED) The function indicator shows the unit’s status depending on its setting. When the DE10 starts, the function indicator shows which channel is selected (1-10) by flashing green 1-10 times. During charging the indicator shows red. When the charging is completed, the indicator shows green. -
Page 13: Radio Range And Channels
30 meters. However, this may vary, depending on the particular environment you are in. Like all radio sys- tems, Comfort Digisystem communicates on specific channels. If you use two transmitters on the same or neighboring channels, there may be interferences. -
Page 14: Attached Accessories
The car charger is designed for cars with a 12 Volt (-) earthed electrical system. The charger has short-circuit and automatic overload protection. Disconnect the charger from the socket after use. Charger unit For other accessories, please visit our website www.comfortaudio.com Receiver DE10... -
Page 15: Trouble Shooting
There may also be electronic equipment nearby causing interference. Change channel. No sound Check that the transmitter and receiver are set to the same channel. Loud hissing noise Check that the units are paired. Receiver DE10... -
Page 16: Service And Warranty
Defects caused by careless handling or intervention inside the product or its accessories are not covered by the warranty. It is recommended that the batteries included with Comfort Digisystem are charged little and often. They are designed to reach 90 % capacity mid-way through charging. -
Page 17: Important Safety Instructions
Iiquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture does not operate normally or has been dropped. Receiver DE10... - Page 18 25) Do not leave the product unloaded for too long, the battery could get damaged. 26) Do not keep the product connected to the charger if it is not used for a longer period. Receiver DE10...
- Page 19 Subject to change Receiver DE10...
- Page 20 Manufactured by: Comfort Audio AB Box 154, SE-301 05 Halmstad, Sweden Tel. +46 35 260 16 00 Fax +46 35 260 16 50 info comfortaudio.com www.comfortaudio.com...
