Stelpro CH series User Manual

Kick space heater

www.stelpro.com

User's guide

''CH'' series

Kick space heater

This unit complies with

the CSA and UL standards

WARNING

Before installing and operating this product, the user and/or installer must read, understand and follow these instructions and keep them

handy for future reference. If these instructions are not followed, the warranty will be considered null and void and the manufacturer deems

no further responsibility for this product.

This product must be installed by a qualified person and connected by a certified electrician, according to the electrical and building

codes effective in your region.

The following instructions must be adhered to in order to avoid personal injuries or property damages, serious injuries and potentially fatal

electric shocks.

Protect the heating unit with the appropriate circuit breaker or fuse, in accordance with the nameplate.

Make sure the line voltage (volt) is consistent with that indicated on the unit's nameplate.

This unit must be grounded.

Switch off the power at the circuit breaker/fuse before installing, repairing and cleaning the unit.

For further information or to consult this guide online, please visit our Web site.

INSCH1012

Table of Contents

Need help?

Do you have a question about the CH series and is the answer not in the manual?

Page 1 User’s guide ‘‘CH’’ series Kick space heater Replacement component list included This unit complies with the CSA and UL standards WARNING WARNING WARNING WARNING Before installing and operating this product, the user and/or installer must read, understand and follow these instructions and keep them handy for future reference.
Page 2 If needed, refer to a specialist (industrial and commercial buildings) who will be able to calculate these heat losses and optimize the required capacity or consult the “Online heating calculation” section of the Stelpro Design Web site (residential buildings).
Page 3: Specifications
SPECIFICATIONS 1/2” IMPORTANT: KICK SPACE HEATER / CH SERIES [13 mm] PUT SHIM BEFORE VOLTS 120, 208, 240 V (required to install INSTALLING THE WATTS 500 to 1000 W trim frame) DEVICE WEIGHT 13 lb / 5.9 kg 1/2” [13 mm] WIDTH 22 5/8”...
Page 4: Limited Warranty
The warranty is limited to the repair or the replacement of the unit or the refund of its purchase price, at the discretion of Stelpro. Any parts replaced or repaired within the warranty period with the written authorization of Stelpro will be warranted for the remainder of the original war- ranty period.
