  • Page 1 DESSIN TECHNIQUE / TECHNICAL DRAWING complies APPARE IL with CSA 17/11/2011 DATE: / UNIT: standards DESSINATEUR MIS À JOUR A. DESMARAIS AD_19/12/2013 / DRAFTER: UPDATED: For further information or to consult this guide online, please visit our website at www.stelpro.com INSCBH0318...
  • Page 2 If an option must be added, make sure it has been approved by Stelpro. This way, it will ensure that it has been tested in accordance with our safety rules and that an appropriate installation has been planned into the unit.
  • Page 3: Technical Drawings

    TECHNICAL DRAWINGS MODELS LENGTHS: 24"/36"/48" 6 7/8" 1 1/8" 175mm 29mm 5" ONLY ON 126mm CBH36"/48" 1 3/16" 10" 29mm 254mm 7/8" 22mm 26" 660mm 7/8" 22mm 1 15/16" 49mm 1 1/8" 5" 29mm FRONT 126mm 6 7/8" ONLY ON 175mm CBH36"/48"...
  • Page 4: Installation

    Stelpro recommands 8’ from the floor for units of 6000 W and less and 12’ for units of 8000 W and more. Units with BT and BF air inlets and outlets must be installed at least 8’...
  • Page 5 OPTIONS The CBH can be installed on a wall or a ceiling, surface mounted, recessed or semi-recessed with a 4-piece frame. 24 in. units 24 1/2" [623 mm] 36 in. units 36 1/2" 27 1/2" [927 mm] 3" [699 mm] [76 mm] 48 in.
  • Page 6: Electrical Wiring

    ELECTRICAL WIRING This unit should be installed by a certified electrician. Cut off power supply at circuit breaker. Make the electrical connections and the ground according to the standards of Electric Code(s) in place in your region. If you are not familiar with thoses codes, you must contact a qualified electrician.
  • Page 7 REF # PART # DESCRIPTION REF # PART # DESCRIPTION REF # PART # DESCRIPTION ELF-CBH0663 ELEMENT (KIT) 6KW 600V 3PH ELF-CBH1063 ELEMENT (KIT) 10KW 600V 3PH ELF-CBH1853 ELEMENT (KIT) 18KW 480V 3PH ELF-CBH0671 ELEMENT (KIT) 6KW 277V 1PH ELF-CBH1071 ELEMENT (KIT) 10KW 277V 1PH ELF-CBH1863 ELEMENT (KIT) 18KW 600V 3PH...
  • Page 8: Troubleshooting

    Stelpro reserves the right to examine or to ask one of its representatives to examine the product itself or any part of it before honoring the warranty. Stelpro reserves the right to replace the entire unit, refund its purchase price or repair a defective part.
