HANDBOOK
OVEN DESIGN CHEF
UPDATED JULY 2005
DESIGN CHEF
DC72MXS
5600117
DC72MXS 5600117
LIST SPARE PARTS
ESPLODED VIEW
WIRING DIAGRAM
CLOSE-UP VIEW
7 COOKING MODES
END COOKING KNOB 120'
DISMOUNTING THE OVEN DOOR
AFTER SALE SERVICE LABEL SERIAL NUMBER
INSTALLATION
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the DESIGN CHEF DC72MXS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Franke DESIGN CHEF DC72MXS

  • Page 1 HANDBOOK OVEN DESIGN CHEF UPDATED JULY 2005 DESIGN CHEF DC72MXS 5600117 DC72MXS 5600117 LIST SPARE PARTS ESPLODED VIEW WIRING DIAGRAM CLOSE-UP VIEW 7 COOKING MODES END COOKING KNOB 120’ DISMOUNTING THE OVEN DOOR AFTER SALE SERVICE LABEL SERIAL NUMBER INSTALLATION...
  • Page 2: Position Description

    DC72MXS 5600117 3 GLASSES DOOR / Energy class A Voltage 230v-50 hz Inner dimensions of the oven : Total power: 2875 kw width mm440 depth mm 415 height mm 312 HEATING ELEMENT Inner volume of the oven: POWER: litres TOP W 1000...
  • Page 3 CODE POSITION DESCRIPTION SPARE PARTS 1992205 ASSEMBLY FAN MOTOR 1992010 GRILL+TOP ELEMENT 2250+556 W 230 V 1992011 CIRCULAR FAN ELEMENT 2000W 1992012 FAN DIFFUSER 1992013 INTERNAL OVEN CHIMNEY 1992014 OVEN LOW HEATING ELEMENT 1250 W 230V 1992015 LOWER PANEL 1992099 OV EN CUBE LAMP SIDE 1992021...
  • Page 4 CODE POSITION DESCRIPTION SPARE PARTS 1992204 DOOR ASSEMBLY DC72MXS 1992202 ASSEMBLY SURROUND OVEN DESIGN CHEF DC72MXS 1992144 TELESCOPIC ARMS LEFT 1992145 TELESCOPIC ARMS RIGHT 1992146 INSERT GRID LEFT (2 INSERT) 1992147 INSERT GRID RIGHT (2 INSERT) 1992017 SUPPORT WIRE RACKS SIDE...
  • Page 6: Close-Up View

    All repairs should be carried out by specialised authorised staff. Contact your nearest after-sales service centre and request the use of original spare parts only. Your Franke oven is coated with a special enamel layer, which is easy to clean. Another good habit to get into is to clean it often and to avoid reheating caked on grease spots and food residue from previous uses.
  • Page 7 Cooling fan In order to cool down the door, control panel and sides of the appliance, this Franke oven is fitted with a cooling fan which turns on automatically when the oven is hot. When the fan is on, a normal flow of air can be heard exiting between the oven door and the control panel.
  • Page 8: Cooking Modes

    With this mode, you can also cook various dishes at the same time, as long as their respective cooking temperatures are the same. This is the most delicate of the ventilated modes available in this Franke oven, and is ideal for baking cakes and pastries in general, as it allows you to cook on three different rack heights simultaneously.
  • Page 9 In this case, the quick browning of the surface via infrared rays keeps the inside of the meat soft and tender; the grill mode can also be used to toast up to 9 slices of bread very quickly. Your Franke oven is perfectly safe, and has been designed for grilling food with the oven door completely shut.
  • Page 10 End Cooking Timer Knob The end cooking timer is a practical device that turns the oven off automatically at a set time, ranging from one to 120 minutes. To use the end cooking timer, the ringer must be wound up by turning knob (C) almost one full turn clockwise;...
  • Page 11 DC72MXS...
  • Page 12 Dismounting the oven door To facilitate your task in cleaning the oven, the door can be dismounted at the hinges as follows: - The hinges (A) are fitted with two mobile U-bolts (B). Raise the U-bolt (B) to release the hinge from its seat. - Then lift the door upwards and pull it out;...
  • Page 13 A: PRODUCT CODE 5600110 B : SN SERIAL NUMBER : I = ITALY F= OVEN 03=PRODUCTION 2003 L=month of production 0000001= OVEN NUMBER C: OVEN MODEL CM72MXS...
  • Page 14: Assembly Instructions

    Assembly instructions Measure the width of the back panel (S) of the cabinet, which should usually be 16,18 or 20 mm. 16 mm back panel: place 2 tabs (T) indicating the number 16 on each fastening bracket (F). 18mm back panel: place 2 tabs (T) indicating the number 18 on each fastening bracket (F).
