- Page 1 QU-4M v1.3 HDMI 1 to 4 Distribution Amplifier with System Reset OPERATION MANUAL...
- Page 2 Table of Contents Introduction Features Operation Controls and Functions Front Panel Diagram Rear Panel Diagram Connection Diagram Specifications...
- Page 3 1. Introduction The Quantum HDMI v1.3 Distribution Amplifier Series is the most advanced solution to HDMI signal distribution. Each product in this series is compatible to HDMI v1.3 specifications, a cutting-age technology which defines the support to transfer Deep Color (10-bit and 12-bit) video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio, with a high bandwidth up to 225MHz (6.75Gbps).
-
Page 4: Operation Controls And Functions
3. Operation Controls and Functions 3.1 Front Panel 1. HDMI Output 1: Connect each of the output ports to the HDMI display. 2. Sync LED: The LED will illuminate when the HDMI source signal is connected to the input port. 3. -
Page 5: Rear Panel
3.2 Rear Panel HDMI HDMI HDMI OUTPUT OUTPUT OUTPUT 1. EDID Control Switch: Default setting is TV (downstream). In this mode the QU- 4M will search all output ports (starting at output 1) for the highest video/ audio settings connected to each of the outputs. The detection priority of the matrix is v1.3 HDMI, v1.2 HDMI, DVI. - Page 6 4. Connection Diagram 6. Specifications Input Port 1 x HDMI Output Port 4 x HDMI Weight 550g Power Supply 5V DC/2.6A (US/EU standards, CE/FCC/UL Certified) Dimensions 102(W) x 141(D) x 38(H) Chassis Colour Black Chassis Material Aliminium Operating Temperature Operating from 0°C ~ 40°C Page 4...
- Page 7 Notes:...
- Page 8 www.cypeurope.com...
