Watlow DIN-A-MITE Style A User Manual

DIN-A-MITE
Solid-State Power Controller
User's Manual
1241 Bundy Boulevard, Winona, Minnesota USA 55987
Phone: +1 (507) 454-5300, Fax: +1 (507) 452-4507 http://www.watlow.com
Please consult this user manual when you place your new
DIN-A-MITE in service. It contains all the necessary
information to mount and wire the product into the
application. This manual also contains all the user-
pertinent specifications and semiconductor fusing
recommendations. Please refer to national and local
electrical code safety guidelines whenever you install
electrical equipment.
This DIN-A-MITE product is capable of switching up to
18 A single phase at 600V (ac), depending on the model
selected at 50 C. (See the output rating curve in the
°
specifications section.) The DIN-A-MITE is electrically
touch-safe, and includes DIN (Deutsche Industrial Norm)
rail or standard back panel mounting. UL
UL ® , and CE-approved (see Declaration of Conformity
[filter required]).
0600-0025-0001 Rev K
September 2013
®
Style A
C US
LISTED
® 508-listed, C-
The DIN-A-MITE is warranted to be free of defects in material
and workmanship for 36 months after delivery to the first
purchaser for use, providing that the units have not been
misapplied. Since Watlow has no control over their use, and
sometimes misuse, we cannot guarantee against failure. Watlow's
obligations hereunder, at Watlow's option, are limited to
replacement, repair, or refund of purchase price, and parts which
upon examination prove to be defective within the warranty
period specified. This warranty does not apply to damage
resulting from transportation, alteration, misuse, abuse, or
improper fusing.
• Call Customer Service: (507) 454-5300, or fax: (507) 452-4507,
for a Return Material Authorization (RMA) number before
returning any item for repair.
• Make sure the RMA number is on the outside of the carton, and
on all paperwork returned. Ship on a freight prepaid basis.
• A restocking charge of 20% of the net price applies for all
returned stock controls and accessories in like new condition
and within 120 days after shipment. Non-stock and modified
stock items are not returnable.
• If the unit is unrepairable, it will be returned to you with a
letter of explanation. Repair costs will not exceed 50% of the
original cost.
Technical Assistance
If you encounter a problem with your Watlow controller, review
your configuration information to verify that your selections are
consistent with your application: inputs; outputs; alarms; limits;
etc. If the problem persists after checking the configuration of the
controller, you can get technical assistance from your local Watlow
representative, or in the U.S., dial +1 (507) 494-5656. For
technical support, ask for for an Applications Engineer.
Please have the following information available when calling:
• Complete model number
• All configuration information
• User's Manual
The DIN-A-MITE Style A User's Manual is copyrighted by
Watlow, Inc., © September 2013, with all rights reserved.
Warranty
Returns
