- Page 1 Encoder Firmware V4.06.09 User’s Manual Box Camera Series Hardware Manual D21, D22, E21, E22, E23, E24 www.acti.com...
- Page 2 Hardware Manual 2013/03/29 www.acti.com...
-
Page 3: Table Of Contents
Table of Contents Precautions ............. 4 Introduction ............5 The List of Models ................... 5 Package Contents ..................6 Safety Instructions ................... 7 Physical Description ................. 8 Installation and Access ........... 9 Camera Installation ................. 9 Accessing Camera .................. 11 www.acti.com... -
Page 4: Precautions
Operation of this equipment in a residential area is likely to cause harmful interference in which case the users will be required to correct the interference at their own expense. www.acti.com... -
Page 5: Introduction
5MP Box with D/N, Basic WDR, Vari-focal lens 2MP Box with D/N, Basic WDR, SLLS, Vari-focal lens 3MP Box with D/N, Superior WDR, Vari-focal lens From the installation perspective these models are very similar; therefore you can use one manual for all of them. www.acti.com... -
Page 6: Package Contents
Hardware Manual Package Contents 1. Camera D21, D22, E21, E22, E23, E24 2. Lens Fixed focal lens with Vari-focal lens with manual focus manual focus and fixed iris and DC iris 3. Mounting Block 4. Quick Installation Guide 5. Warranty Policy Mounting block for mounting the camera to a bracket. -
Page 7: Safety Instructions
Safety Check Upon completion of any service or repairs to this video product, ask the service technician to perform safety checks to determine if the video product is in proper operating condition. www.acti.com... -
Page 8: Physical Description
When the Power LED is on, the camera is successfully powered on by PoE and the system is running. It is possible to disable Power LED by URL command if necessary. 4) DC Iris Port When the DC iris lens is used, the cable of the lens has to be connected to this port. www.acti.com... -
Page 9: Installation And Access
Outdoor Installation Outdoor installations require waterproof housing and the heavy duty bracket. The following housing solutions offered by the manufacturer: The outdoor bracket can be mounted onto the wall. www.acti.com... - Page 10 Hardware Manual For pole or corner installations, you may consider following solutions: The housing can be either PMAX-0200, 0201 or PMAX-0202. www.acti.com...
-
Page 11: Accessing Camera
The quickest way to discover the cameras in the network is to use the simplest network search, built in the Windows system – just by pressing the “Network” icon, all the cameras of the local area network will be discovered by Windows thanks to the UPnP function support of our cameras. www.acti.com... - Page 12 The IP Utility can be downloaded for free from http://www.acti.com/IP_Utility With just 1 click, you can launch the IP Utility and there will be an instant report as follows: You can quickly notice the D11 model in the list.
- Page 13 PC has to be configured to match the network segment of the camera. Manually adjust the IP address of the PC: In the following example, based on Windows 7, we will configure the IP address to 192.168.0.99 and set Subnet Mask to 255.255.255.0 by using the steps below: www.acti.com...
- Page 14 In such case, please plug in only one camera at a time, and change its IP address by using the Web browser before plugging in the next one. This way, the Web browser will not be confused about two devices having the same IP address at the same time. www.acti.com...
-
Page 15: Access The Camera
– the user just has to accept the use of such control when prompted so. No other third party utilities are required to be installed in such case. The following examples in this manual are based on Internet Explorer browser in order to cover all functions of the camera. www.acti.com... - Page 16 HTTP port of the camera is 80, which can be omitted from the address for convenience. Before logging in, you need to know the factory default Account and Password of the camera. Account: Admin Password: 123456 For further operations, please refer to the Firmware User Manual. www.acti.com...
