DCT30KC/DLC30 Series Dryers
The dryer must not be stored or installed where it will be exposed to water and/or weather.
WARNING: For your safety the infor-
mation in this manual must be fol-
lowed to minimize the risk of fire or
explosion or to prevent property dam-
age, personal injury or loss of life.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
– WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Clear the room, building or area of all
occupants.
Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
– Installation and service must be performed by
a qualified installer, service agency or the
gas supplier.
Post the following "For Your Safety" caution in a
prominent location:
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapors or liquids in the vicinity of this or any other
appliance.
It is important that you read this Manual and retain it for
future reference. For service or replacement parts,
contact the distributor in your area or the manufacturer.
OPERATOR'S MANUAL
Dexter Laundry, Inc.
2211 W. Grimes
Fairfield, Iowa 52556 USA
for
AVERTISSEMENT. Assurez-vouz de
bien suivre les instructions données
dans cette notice pour réduire au
minimum le risque d'incendie ou
d'explosion ou pour éviter tout
dommage matérial, toute blessure
ou la mort.
Ne pas entreposer ni utiliser d'essence ni d'autres
vapeurs ou liquides inflammables dans le voisinage
de cet appareil ou de tout autre appareil.
– QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE
GAZ:
Ne pas tenter d'allumer d'appareil.
Ne touchez à aucun interrupteur. Ne pas
vous servir des téléphones se trouvant
dans le bâtiment où vous vous trouvez.
Évacuez la pièce, le bâtiment ou la zone.
Appelez immédiatement votre
fournisseour de gaz depuis un voisin.
Suivez les instructions du fournisseur.
Si vous ne pouvez rejoindre le fournisseur
de gaz, appelez le service des incendies.
– L'installation et l'entretien doivent être assurés par
un installateur ou un service d'entretien qualifié ou
par le fournisseur de gaz.
POUR VOTRE SÉCURITÉ
Ne pas enteposer ni utiliser d'essence ni d'autres
vapeurs ou liquides inflammables dans le voisinage
de cet appareil ou de tout autre appareil.
You, the purchaser, must post in a prominent loca-
tion instructions to be followed in the event the user
smells gas. Consult your local gas supplier for
procedure to be followed if the odor of gas is
present.
8514-003-010B
10/09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DCT30KC Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dexter Laundry DCT30KC Series

  • Page 1 Consult your local gas supplier for procedure to be followed if the odor of gas is present. Dexter Laundry, Inc. 2211 W. Grimes Fairfield, Iowa 52556 USA...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE NO. DRYER DIMENSIONS (Figure 1) ................ .3 UNCRATING ......................4 FIELD ASSEMBLY ....................4 DRYER INSTALLATION ..................5 DRYER EXHAUST SYSTEM (Figure 2) ............6, 7 DRYER SHUTDOWN ................... 8 OPERATING INSTRUCTIONS ................8 SERVICING DRYER ................... PREVENTATIVE MAINTENANCE ..............
  • Page 4: Uncrating

    INSTALLATION AND OPERATING INSTRUCTIONS COMMERCIAL DRYER UNCRATING 1. Remove cardboard container and innerpack. 2. Complete the uncrating as described in the procedure listed on the instruction sheet taped to the loading door glass. FIELD ASSEMBLY For secure packaging, the dryer is shipped with the tee, one part of the heat reclaimer, inside the lower service door.
  • Page 5: Dryer Installation

    DRYER INSTALLATION 1. CODE CONFORMITY. All commercial dryer installations must conform with local codes or, in the absence of local codes, with the latest edition of the National Fuel Gas Code ANSI Z223. 1. Canadian installations must comply with current Standard CAN/CGA-B149 (.1 or .2) Installation Code for Gas Burning Appliances or Equipment, and local codes if applicable.
  • Page 6: Dryer Exhaust System (Figure 2)

    3. MAKE-UP AIR. Adequate make-up air (830 CFM) must be supplied to replace air exhausted by dryers on all types of installations. Provide a minimum of one square foot make-up air opening to the outside for each dryer. This is a net requirement of effective area. Screens, grills or louvers, which will restrict the flow of air, must be considered. Consult the supplier to determine the free area equivalent for the grill being used.
  • Page 7 amount of air the blower can exhaust. This does not affect the dryer operation if held within practical limits. For the most efficient operation, it is recommended that no more than 20 feet (6m) of straight 8" diameter pipe be used with two right angle elbows.
  • Page 8: Dryer Shutdown

    7. DRYER IGNITION (SOLID STATE IGNITION). The solid-state ignition system lights the main burner gas by spark. The gas is ignited and burns only when the gas-valve relay (in the electronic controller) calls for heat. The procedure for first-time starting of a dryer is as follows: A.
  • Page 9 Once started, the “timer” cannot be stopped. However, extra coins will be acknowledged by adding time to the display. The dryer may be stopped by opening the loading door, which interrupts the drive motor and gas burners. Close the loading door and push to restart the dryer.
  • Page 10 PROGRAMMING INSTRUCTIONS: (To switch to program mode.) SERVICE 1. Unlock and open the upper service door. DOOR 2. Open the loading door. 3. Push the Program Button found just to the left of the WARM or LOW cycle light. The Button is accessible through a hole in control mounting plate, after removal of bright metal plug.
  • Page 12 Setting the Electronic Coin Acceptor Switches 1) The electronic coin acceptor has switches depending on the coins and country. See Table Table 2, or Table 3 for available values of the left and right coin inputs for the available countries. WARNING: TURN POWER OFF BEFORE AND LEAVE POWER OFF WHEN CHANGING THE SWITCHES OF THE ELECTRONIC COIN ACCEPTOR.
  • Page 13 Table 2 for acceptors with spec 109 Acceptor P/N Country Left Coin Right Coin SWs 1-8 SWs 9-16 Australia 10¢ ↓↓↑↑↑↑↑↓ ↑↓↑↑↑↑↑↓ Australia 20¢ ↑↑↓↓↑↑↑↓ ↑↓↑↑↑↑↑↓ Australia ↑↑↑↑↓↓↑↓ ↑↑↓↑↑↑↑↓ Australia ↑↑↑↑↑↑↓↓ ↓↑↓↑↑↑↑↓ Australia $1 + $2 ↑↑↑↑↓↓↓↓ ↓↑↓↑↑↑↑↓ Australia 10¢ ↓↓↑↑↓↓↑↓...
  • Page 14 Table 3 for acceptors with spec 311 Acceptor P/N Country Left Coin Right Coin SWs 1-8 SWs 9-16 Australia 10¢ ↓↓↑↑↑↑↑↓ ↑↑↓↑↑↑↑↑ Australia 20¢ ↑↑↓↓↑↑↑↓ ↑↑↓↑↑↑↑↑ Australia ↑↑↑↑↓↓↑↓ ↑↑↓↑↑↑↑↑ Australia ↑↑↑↑↑↑↓↓ ↓↑↓↑↑↑↑↑ Australia $1 + $2 ↑↑↑↑↓↓↓↓ ↓↑↓↑↑↑↑↑ Australia 10¢ ↓↓↑↑↓↓↑↓...
  • Page 15: Servicing Dryer

    CHANGING PROGRAM DATA Put dryer in PROGRAM mode as instructed on page 9. The dryer remains in the PROGRAM mode until one of these actions occur: • The switch is actuated again. • The seventeenth step is completed and the START switch is pushed following the seventeenth step. •...
