QuickSpecs
Options
Configuration Steps
Configuration Steps
Configuration Steps
Configuration Steps
For a complete configuration on the HP ProLiant Server Blades, please do the following:
Step 1: Select desired model, configuration and quantity of HP ProLiant server blades
Step 1: Select desired model, configuration and quantity of HP ProLiant server blades
Step 1: Select desired model, configuration and quantity of HP ProLiant server blades
Step 1: Select desired model, configuration and quantity of HP ProLiant server blades
NOTE:
NOTE:
NOTE: For server blade information, please visit:
NOTE:
http://h18004.www1.hp.com/products/blades/components/c-class-bladeservers.html
Step 2: Determine quantity of HP BladeSystem c-Class Server Blade Enclosures to purchase
Step 2: Determine quantity of HP BladeSystem c-Class Server Blade Enclosures to purchase
Step 2: Determine quantity of HP BladeSystem c-Class Server Blade Enclosures to purchase
Step 2: Determine quantity of HP BladeSystem c-Class Server Blade Enclosures to purchase
NOTE: Each HP BladeSystem c-Class Server Blade Enclosure holds 2, 4, 8 or 16 HP ProLiant server blades plus a minimum of two
NOTE:
NOTE:
NOTE:
Interconnects depending on server blade selection.
NOTE:
NOTE: For additional information on HP BladeSystem c-Class Infrastructure please visit:
NOTE:
NOTE:
http://h18004.www1.hp.com/products/blades/components/enclosures/c-class/c7000/index.html
Step 3: Determine number and type of Interconnect Components required for base configuration
Step 3: Determine number and type of Interconnect Components required for base configuration
Step 3: Determine number and type of Interconnect Components required for base configuration
Step 3: Determine number and type of Interconnect Components required for base configuration
NOTE:
NOTE:
NOTE: For additional information on HP BladeSystem c-Class Interconnect Components please visit
NOTE:
http://h18004.www1.hp.com/products/blades/components/c-class-interconnects.html
Service and Support
Service and Support
Service and Support
Service and Support
Offerings
Offerings
Offerings
Offerings
(HP Care Pack Services)
NOTE: Each HP BladeSystem c-Class enclosure requires two Ethernet/Fibre Channel switches OR Virtual
NOTE:
NOTE:
NOTE:
Connect Ethernet/Fibre Channel Module OR two Ethernet/Fibre Channel Pass-Thru Modules for a
redundant Ethernet/Fibre Channel configuration.
Choose a base configuration that meets your Ethernet/Fibre Channel networking needs
Order in quantities of two for a fully redundant configuration
Choose additional options for the base configuration that meet your needs for cabling and
software options
Bays 1 and 2 are reserved for Ethernet Switches or Pass-Thru Modules supporting Server LAN on
Motherboard (LOM) NIC connections to ports on the Ethernet Switch or Pass-Thru Module.
Supported bays for additional Ethernet and/or Fibre Channel Switch Modules include
unpopulated Bays 3/4, 5/6, or 7/ 8
Redundant Switches must be configured adjacent to one another in Bays 1/2, 3/4, 5/6, or 7/ 8.
Step 1 - Base Configurations (Select one)
Step 1 - Base Configurations (Select one)
Step 1 - Base Configurations (Select one)
Step 1 - Base Configurations (Select one)
Switch Modules
Switch Modules
Switch Modules
Switch Modules
DA - 12524
Worldwide — Version 11 — July 14, 2008
HP BladeSystem c-Class Interconnect Components
HP BladeSystem c-Class Interconnect Components
HP BladeSystem c-Class Interconnect Components
HP BladeSystem c-Class Interconnect Components
HP 10Gb Ethernet Blade Switch
HP 1:10Gb Ethernet BL-c Switch for c-Class BladeSystem
Cisco Catalyst 3020 Blade Switch for HP c-Class
BladeSystem
HP GbE2c Ethernet Blade Switch for c-Class BladeSystem
HP GbE2c Layer2/3 Ethernet Blade Switch for c-Class
BladeSystem
HP Brocade 4/12 SAN Switch
Includes: (1) 4Gb SAN Switch; 12 ports enabled for any
combination (internal and external); two (2) short wave
4Gb SFPs; WebTools license; Zoning license; Access
Gateway; full fabric connectivity; documentation
NOTE: #0D1 will appear after this part number on your
NOTE:
NOTE:
NOTE:
sales order when factory integration is indicated
445860-B21
438031-B21
410916-B21
410917-B21
438030-B21
AE370A
Page 17
