QuickSpecs
Standard Features (HP BladeSystem c-Class Interconnect Components)
Models Models Models Models
Switch Modules Switch Modules Switch Modules Switch Modules
HP 10Gb Ethernet Blade Switch
HP 1:10 Gb Ethernet BL-c Switch
Cisco Catalyst Blade Switch 3120X for HP
Cisco Catalyst Blade Switch 3120G for HP
Cisco Catalyst 3020 Blade Switch for HP c-Class BladeSystem
HP GbE2c Ethernet Blade Switch for c-Class BladeSystem
HP GbE2c Layer2/3 Ethernet Blade Switch for c-Class BladeSystem
Brocade 8/12c SAN Switch for HP BladeSystem c-Class, Full Fabric
Brocade 8/24c SAN Switch for HP BladeSystem c-Class, Full Fabric
Brocade 8/24c SAN Switch Power Pack for HP BladeSystem c-Class, Full Fabric
Brocade 8/12c SAN Switch 12-port Upgrade LTU
Brocade 4/12 SAN Switch for HP c-Class BladeSystem, Full Fabric
Brocade 4/24 SAN Switch for HP c-Class BladeSystem, Full Fabric
Brocade 4/24 SAN Switch Power Pack for HP c-Class BladeSystem, Full Fabric
Brocade 4/12 SAN Switch 12-port Upgrade LTU
Cisco MDS 9124e 12-port Fabric Switch for HP c-Class BladeSystem
Cisco MDS 9124e 24-port Fabric Switch for HP c-Class BladeSystem
Cisco MDS 9124e Fabric Switch 12-port Upgrade LTU
Virtual Connect Modules Virtual Connect Modules Virtual Connect Modules Virtual Connect Modules
HP 1/10Gb Virtual Connect Ethernet Module for c-Class BladeSystem
HP 1/10Gb-F Virtual Connect Ethernet Module for c-Class BladeSystem
HP 4Gb Virtual Connect Fibre Channel Module for c-Class BladeSystem
Mezzanines and Adapters Mezzanines and Adapters Mezzanines and Adapters Mezzanines and Adapters
QLogic QMH4062 1GbE iSCSI Adapter for HP c-Class BladeSystem
HP NC512m Dual Port 10GbE Multifunction BL-c Adapter
NOTE: An NC512m network adapter card is required for each server blade connecting to the HP 10Gb Ethernet NOTE: NOTE: NOTE:
BL-c Switch.
NOTE: NOTE: Two NC512m adapters are supported per ProLiant c-Class full height server in type II x8 PCI Express NOTE: NOTE:
mezzanine slots and one adapter per a type II x8 PCI Express mezzanine slot in a half height server. For more
information, see the Mezzanine Slot Compatibility matrix within the HP NC512m Dual Port 10GbE Multifunction
BL-c Adapter QuickSpecs:
NOTE: NOTE: NOTE: The NC512m requires a minimum of 2 GB of server memory per NC512m card and supports a NOTE:
maximum of 32 GB for Windows and 64 GB for Linux.
NOTE: Each port on the NC512m transmits from the server only at 20 Gbps full duplex per port. NOTE: NOTE: NOTE:
HP NC373m PCI Express Dual Port Multifunction Gigabit Server Adapter for c-Class BladeSystem
HP NC364m Quad Port 1GbE BL-c Adapter
HP NC360m Dual Port 1GbE BL-c Adapter
HP NC326m PCI Express Dual Port 1Gb Server Adapter for c-Class BladeSystem
HP NC325m PCI Express Quad Port 1Gb Server Adapter for c-Class BladeSystem
HP 1Gb Ethernet Pass-Thru Module for c-Class BladeSystem
HP 4Gb Fibre Channel Pass-Thru Module for c-Class BladeSystem
QLogic QMH2462 4Gb FC HBA for HP c-Class BladeSystem
Emulex LPe1105-HP 4Gb FC HBA for HP c-Class BladeSystem
http://h18004.www1.hp.com/products/servers/networking/nc512m/index.html
DA - 12524 Worldwide — Version 11 — July 14, 2008
HP BladeSystem c-Class Interconnect Components HP BladeSystem c-Class Interconnect Components HP BladeSystem c-Class Interconnect Components HP BladeSystem c-Class Interconnect Components
Part Number Part Number Part Number Part Number
445860-B21
438031-B21
451439-B21
451438 -B21
410916-B21
410917-B21
438030-B21
AJ820A
AJ821A
AJ822A
T5517A
AE370A
AE372A
AE371A
AE373A
AG641A
AG642A
T5169A
399593-B22
447047-B21
409513-B21
488074-B21
440910-B21
406770-B21
447883-B21
445978-B21
406771-B21
416585-B21
406740-B21
403626-B21
403619-B21
403621-B21
