QuickSpecs
Overview
Windows-powered unified storage built on industry standards
You have better things to do than worry about storage. You're juggling multiple management interfaces, security concerns, and
shrinking backup windows -- all while your users demand more and more space. You need a shared storage solution that's powerful
and easy to manage, and you need it now.
HP X1000 Network Storage Systems are the fast and easy way to add Windows-powered shared storage to your small or medium IT
environment. They're versatile unified storage, so you get more for your money since it can be a file server, an iSCSI target for
application/virtual environment storage, or both. You'll spend less time and effort on maintenance and management once you
consolidate to a centralized shared storage system, and industry standards will protect your investment by providing compatibility
with your network and applications. The operating system is pre-installed and comes with HP X1000 Automated Storage Manager,
so you'll be up and running in minutes.
What is an X1000
What is an X1000
What is an X1000
What is an X1000
Network Storage System?
Network Storage System?
Network Storage System?
Network Storage System?
What's New
What's New
What's New
What's New
New X1400 8TB Network Storage System with 4 x 2TB LFF SATA HDDs
New X1500 tower models using a 8 drive LFF chassis
New X1600 24TB Network Storage System with 12 x 2TB LFF SATA HDDs
All X1600 models using the 12 LFF drive chassis have 2 rear drive SFF HDDs pre-configured for the pre-installed OS.
New X1600 models using a 25 drive SFF chassis
New X1800 models using a 16 drive SFF chassis
All X1000 models now include RAID 6 capability for greater reliability
ASM 4.0 - Now even easier to use with simpler startup and configuration for small office, non-IT environments and a new
wizard for setting up NFS file shares in non-Windows AD environments
HP X1000 Network Storage Systems are enhanced Windows-powered shared storage solutions for your
small or medium business, branch office, or workgroup environment. They are built on industry-standard
HP ProLiant servers and come with the Microsoft® Windows Storage Server 2008 operating system pre-
installed. Like many Network Attached Storage (NAS) devices, they connect via Ethernet, offer optimized
file serving for heterogeneous clients, and are designed to install in minutes. They can also connect to
servers or virtual machines to host application storage with the included iSCSI target. Since HP X1000
Network Storage Systems are Windows-based, integration into your Windows environment is easy, your
antivirus and backup applications run right on the box, and management has a familiar look and feel.
So you can add shared storage to your network quickly and get back to what matters most: running your
business.
DA - 13341
North America — Version 16 — June 9, 2011
HP X1000 Network Storage Systems
HP X1000 Network Storage Systems
HP X1000 Network Storage Systems
HP X1000 Network Storage Systems
Page 1
