- Page 1 MINI PHANTOM BY DRIVE SCOOTER 35001692, 35002692 OWNER’S MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PREFACE AND INTRODUCTION ……..…………………………………… 3 SAFETY NOTICE…………………………………………………………...…. 2.1 Before driving 2.2 While driving 2.3 Labeling 2.4 EMI PARTS INTRODUCTION……………..……………….. ……………………. OPERATION…………………………………………………………………..1 Control panel 4.2 How to operate your scooter 4.3 How to set to freewheel mode DRIVING ON THE ROAD…………………………………………………….. -
Page 3: Preface And Introduction
1 . P R E F A C E A N D I N T R O D U C T I O N lease carefully read this owner’s manual before using the vehicle. Improper use of the vehicle could result in harm, injury or traffic accidents. To ensure that you get the most your scooter, please read this owner’s manual before using. -
Page 4: Safety Notice
2 . S A F E T Y N O T I C E 2.1 BEFORE DRIVING The user needs to be familiar with the usage and operation of this vehicle before driving. Therefore, please follow the recommendation in this safety notice. ■... -
Page 5: While Driving
2 . S A F E T Y N O T I C E 2.2 WHILE DRIVING ■ Do not use your vehicle under the circumstances below. ♦ On surfaces that are muddy, gravelly, bumpy, narrow, snowed over, icy, or canal towpaths not guarded by any fence or hedge. -
Page 6: Labeling
2.3 Labeling Please carefully read all the labeling on the scooter before drive it. For your future reminding, do not remove them. W A R N I N G P l ease hol d t he t i l l er bef ore l ooseni ng t he t i l l er adj ust m ent knob. -
Page 7: Emi
2 . S A F E T Y N O T I C E 2.4 EMI This portion of the content will provide the user with basic information that describes the problems with EMI, known sources of EMI, protective measures either to lessen the possibility or exposure or to minimize the degree of exposure, and suggested action should unexpected or erratic movement occur. - Page 8 has an immunity level of 20 V/m without any accessories. There are a number of sources of relatively intense electromagnetic fields in the everyday environment. Some of these sources are obvious and easy to avoid. Others are not apparent and exposure is unavoidable. However, we believe that by following the warning listed below, your risk to EMI will be minimized.
-
Page 9: Important Information
or turn ON personal communication devices, such as cellular phones, while the powered vehicle is turned ON; 2. Be aware of nearby transmitters, such as radio or TV stations, and try to avoid coming close to them; 3. If unintended movement or brake release occurs, turn the powered vehicle OFF as soon as it is safe;... -
Page 10: Parts Introduction
3 . P A R T S I N T R O D U C T I O N PARTS DESCRIPTION . Control panel 2. Charger Socket 3. Tiller Adjustment Knob 4. Seat 5. Battery Pack 6. Seat Post Knob... -
Page 11: Operation
4 . O P E R A T I O N 4.1 CONTROL PANEL 1. Speed Dial 2. Horn Button 3. Battery Indicator 4. Power Eye 4.2 HOW TO OPERATE YOUR SCOOTER ■ Power switch ♦ To switch the power on, turn the key clockwise in the ignition. -
Page 12: Battery Indicator
4 . O P E R A T I O N Warning When on a gradient NEVER set the vehicle to the freewheel mode. The electromagnetic brakes will not be applied. This may result in injury or damage. ■ Battery indicator The battery indicator on the tiller console uses a color code to indicate the approximate power GREEN... - Page 13 4 . O P E R A T I O N Suggestion 1. You should recharge the batteries after each time the vehicle is used to ensure maximum range. The batteries should be charged up at least once a week even if the scooter is not used.
-
Page 14: How To Set To Freewheel Mode
4 . O P E R A T I O N 4.3 How to set to freewheel mode Warning Never operate the freewheel lever while seated on the scooter or on an incline! OPERATION OF THE FREEWHEEL LEVER Lever Lever Fig 4.1 Fig 4.2 ◆... -
Page 15: Driving On The Road
4 . O P E R A T I O N Warning ♦ Please hold the tiller before loosening the tiller adjustment knob. ♦ Before lifting or driving the scooter make certain the tiller adjustment knob is fully tightened. ♦ Never attempt to adjust the tiller while the scooter is motion. -
Page 16: Battery Charging & Care
Attention 1. The stopping distance will vary with your forward / reverse speed. Therefore please begin braking as early as you can. 2. When parking your scooter, be sure to park on flat ground and then turn the power to “OFF”... - Page 17 the batteries as instructed above. 8. Should range or power problems arise, please charge your scooter for 24 hours continually and then retry the scooter. Attention: Please follow the rules below to avoid accidents while charging. 1. Please use the 24V charger that comes with your scooter only, and recharge the battery to its full capacity every time.
- Page 18 • These batteries are maintenance free and there is no need to inspect the battery liquid or refill with water. • You are required to recharge the batteries on a regular basis. Even if the scooter is stood idle, you should charge the batteries at least once a week. WARNING Do not open the battery sealed cap at any time.
-
Page 19: Battery
■ Batteries (Inside the Pack) 1. The MINI PHANTOM is powered by two sealed lead-acid deep-cycle batteries. 2. The batteries supplied with the scooter are 12 V 12ah batteries. 3. Size: 5.94 “× 3.89 “ x 3.74 “(Width x Height x Thickness) (151mm×99mm×95mm) Warning 1. -
Page 20: Replacing Batteries
Suggestion – How to maximize your batteries efficiency and service life 1. Fully recharge your new battery before its first time use. 2. Be sure to charge the battery fully every time. The battery life will be seriously shortened or decayed if the battery is repeatedly used without being fully charged. 3. -
Page 21: Inspection And Maintenance
Warning 1. The wiring system and charger are well situated in the battery pack while being assembled in plant. Do not attempt to re-locate the wiring system by yourself. The improper layout of wiring system may result in the wires pinched by battery box, which might result in the electronic system failure. -
Page 22: Regular Checking Record
REGULAR CHECKING RECORD To make sure your scooter is correctly serviced, take it to your dealer for regular maintenance checks. This should be at six months intervals after an initial inspection after one month. Your dealer may charge a fee for this. The checking record is shown below. YEAR YEAR Service Dates... -
Page 23: Storage
Suggestion Ask for help from your dealer to inspect or replace the fuse, since the tiller shroud has to be removed first before you can replace the fuse. ■ Tires The condition of the tires depends on how you drive and use your scooter. ♦... -
Page 24: Disassembly
♦ For your safety, always ask for help if required. You will need two people when moving or lifting the scooter whole. If you are on your own, please disassembly the scooter before lifting. Refer to the section below. 7.6 DISASSEMBLING THE SCOOTER The scooter can be disassembled in to three pieces, the seat (weight 15 lbs.), the frame (weight 44.75 lbs.), and battery pack (weight 21 lbs.), without any tools. -
Page 25: Troubleshooting
4. Replace the seat and rotate it until it locks into its correct position. Warning After assembling the MINI PHANTOM BY DRIVE, make absolutely certain the tiller adjustment knob is fully tightened. 8 . T R O U B L E S H O O T I N G ■... -
Page 26: Specification
9 . S P E C I F I C A T I O N S P E C I F I C A T I O N S Model MINI PHANTOM BY DRIVE Dimension (L x W x H mm) 960x535x890 mm (L x W x H inch) 37.8 “x 21.1”... -
Page 27: Warranty
Weight(Kg),W/I battery 36.9 kg / 81.2lb W/O battery 27.2kg / 59.8 lb Battery 12V 12 Ah x 2 Charger 24V 2A Front Tire 200 x 50 solid tire Rear Tire 200 x 70 solid tire Driving System Direct rear wheels (with differential gear) Brake System Electromagnetic brake Control Method... - Page 28 Limited Warranty is an expression of our confidence in the materials and workmanship of our products and our assurance to the consumer of years of dependable service. In the event of a defect covered by this warranty, we will, at our option, repair or replace the device. This warranty does not cover device failure due to owner misuse or negligence, or normal wear and tear.
- Page 29 TELEPHONE EMAIL Warranty Registration Please type or print. Serial # _______________________________________ Date Purchased ____/____/____ Owner Name ____________________________________________________________ Address _________________________________________________________________...
- Page 30 City ____________________________________ State ________ Zip ________ Additional Required Owner Information Please indicate your understanding of your scooter by completing the following information. ________ I have read and fully understand _______ Owner’s Manual, especially sections on operating instructions, safety guidelines, maintenance and battery instructions. _______ Scooter Warranty Battery Instructions –...
- Page 31 Date of Birth Year Month Address 口 MINI PHANTOM BY DRIVE Model Scooter VIN: Motor Serial No: Key # Date of Purchase Year Month Purchaser Signature 10.1 VIN (VEHICLE INDIFICATION NUMBER) To ensure the correct after sales service and warranty...
- Page 32 Drive Medical 99 Seaview Blvd Port Washington, NY 11050 516.998.4600 (Phone) 516.998.4601 (Fax) 877.224.0946 (Toll Free) 877.390.6628 (Toll Free) www.drivemedical.com...
