# Setup Name
64 HP: Playback Mode
65 HP: Warning Bell Level
66 HP: Rec/Stop Bell
67 Tone: Level
68 Tone: Frequency
69 Tone: Mode
70 Drive: Speed Tests
CF: Space
71
72 CF: (Erase)
73 CF: Repair
74 CF: Empty Trash
75 EXHDD: Space
76 EXHDD: (Erase)
77 EXHDD: Repair
78 EXHDD: Empty Trash
79 Balance Cal
80 Power: Ext Low Batt Volt
Setup Description
Selects the audio source sent to headphones
upon playback.
Set the output level of the multi-function warn-
ing bell.
Alerts the user with one beep at the start of
recording and two beeps when the recording
is stopped
Set the output level of the reference tone
Allows the user to set the frequency of the
reference tone oscillator
Select the destination of the reference tone or
to disables it completely
Performs a speed test on the CompactFlash
media installed and external drives. Data
transfer speed is measured in KB/s.
Shows the drive file system, total size, and
space remaining on connected CompactFlash
medium.
Formats installed CompactFlash medium
Caution, while various PC utilities are able to
recover files from re-formatted drives, once
formatted, old audio data is not accessible by
the 702T.
Runs a utility that will repair minor errors in
the directory structure of the CompactFlash.
Allows user to delete files previously sent to
the trash as well as false takes.
Shows the drive file system, total size, and
space remaining on connected Compact Flash
medium.
Formats attached FireWire storage volume
Caution, while various PC utilities are able to
recover files from re-formatted drives, once
formatted, old audio data is not accessible by
the 702T.
Runs a utility that will repair minor errors in
the directory structure of the external FireWire
storage volume.
Allows user to delete files previously sent to
the trash as well as false takes.
Calibrates the center position of the input 2
pot when used as the balance control for MS
recording.
Sets the warning voltage of the low battery
alert with an external power source. Internal
battery warning threshold is factory set.
702T User Guide and Technical Information
Setup Options
• No change
• Same as options listed above
off, −60 to –12 dBFS in 1 dB steps
• Disabled
• Enabled
−40 to 0 dBFS in 1 dB steps
100–10,000 Hz in 100 Hz steps
• disabled
• to record tracks only
• to outputs only
• to record tracks and outputs
Caution: Drive test will disable processing and mute
outputs for duration of test. Outputs will not return
until test is exited.
• Empty Trash
• Empty False Takes
• Empty both
• Empty Trash
• Empty False Takes
• Empty both
Place balance control to center and press to select.
10.0–18.0 VDC, 0.1 V steps
