  • Page 1 User's Manual Digital Satellite Receiver KSC-570...

  • Page 2: General Safety

    General Safety Warning Always follow these instructions to avoid the risk of injury to yourself or damage to your equipment. Unplug the receiver from the AC power outlet before cleaning. Use only a damp cloth for cleaning the exterior of the receiver. Do not use accessories or attachments not recommended by the receiver manufacturer as they may cause problems to the equipment and will void the warranty.
  • Page 3 General Safety Route power supply cord so that are not likely to be walked on or pinched by items placed upon or against them. Pay particular attention to the cords that plugs in the convenience receptacles, and the point where they exit from the unit. Use an outlet that contains surge suppression or ground fault protection.
  • Page 4 DIGITAL SATELLITE RECEIVER OWNER’S MANUAL SIMPLE & SPEEDY OPERATION HANDBOOK Before operation, Please read the entire manual thoroughly and retain it for future reference.
  • Page 5 Channel Search Channel List Edit Channel List Program Guide System Setting Common Interface Utility (Option)

  • Page 6: Table Of Contents

    Contents Remote Control Unit Front Panel ............... . Rear Panel .
  • Page 7 Contents Menu Transparency ..............Change PIN Code .

  • Page 8: Remote Control Unit

    Remote Control Unit DIGITAL SATELLITE RECEIVER...
  • Page 9 Remote Control Unit DIGITAL SATELLITE RECEIVER...

  • Page 10: Front Panel

    Front Panel 1. POWER 2. CH … / † ( Program … / † ) 3. VOL - / + ( Program 4. OK 5. EXIT 6. MENU 7. SEG. DISP. 8. CAM Slots (Depending on model) DIGITAL SATELLITE RECEIVER Switch the receiver power “ON”...

  • Page 11: Rear Panel

    Rear Panel 1. POWER SUPPLY 90 ~ 250V AC, 50/60Hz. 2. S/PDIF Output for connection to a digital amplifier. 3. SCART FOR VCR Connect this port to the VCR via SCART cable. 4. SCART FOR TV Connect this port to the TV via SCART cable. 5.

  • Page 12: Connecting Your Equipment

    Connecting Your Equipment How to connect your STB to various systems There are several ways of connecting the STB to your TV, VCR and/or Hi-Fi SYSTEM. Consult your local supplier for assistance in setting-up your system that is best suited to your requirements. 1.

  • Page 13: Cam (Conditional Access Module) And Smart Card

    Connecting Your Equipment 4. Connect STB to a Digital Audio System If you have a DAC with S/PDIF coaxial cable input, you can connect the STB with it to enjoy higher quality sound. Connect S/PDIF coaxial cable to a digital amplifier. 5.

  • Page 14: Tv With Motorized System (Diseqc 1.2)

    Connecting Your Equipment TV with Terrestrial Antenna 1. Connect one end of RCA/Cinch cable to the RCA/Cinch jack on the back of the STB and the other end to a RCA/Cinch jack on your TV. If your TV doesn’t have a RCA/Cinch jack, connect one end of RF cable to the TV OUT on the back of the STB and the other end to a RF input jack on your TV.
  • Page 15 Connecting Your Equipment Reference 1. DiSEqC 1.0 Connection All our receivers are designed to be DiSEqC 1.0 and DiSEqC 1.2 compatible. This allows multiple antennas to be connected to the STB at the same time. If you have two or more fixed antennas or LNBs then we recommend you use a DiSEqC 1.0 switch. Connect the coaxial cable from the first LNB to the LNB 1 or LNB A input connector of the DiSEqC switch.
  • Page 16 Connecting Your Equipment Front Panel Display Message KEY & DISPLAY Standby Mode System Booting Power Off MICOM Version Boot Loader Version Download Down Load Procedure DIGITAL SATELLITE RECEIVER The message of the 7-segment LED (Light-Emitting Diode) on the STB and keys are explained as below. Current Program Number on TV List Current Program Number on Radio Location TV Mode...

  • Page 17: Basic Operation

    Basic Operation Basic Function 1. Program Information 2. Favorite Banner 3. Now-Information Banner After the television channels have been programmed, you will see the information box each time you change the channels. 1. Every time you change channels you will receive program information for a few seconds.

  • Page 18: Volume Control/Mute

    Basic Operation Basic Function DIGITAL SATELLITE RECEIVER 4. Next-Information Banner 1. During “Channel Banner” is appearing, when you press YELLOW Button, you can get “Next-Information Banner” 2. Using “Next-Information Banner”, you can get a simple EPG of “Next-Information”. 5. Channel-Information Banner 1.
  • Page 19 Basic Operation Basic Function 7. Teletext / Subtitle 8. Timer 1. Press the RED button, popup window will be displayed on the screen. 2. Select the off, then subtitle function is off. 3. Select the Subtitle, then you can see the Subtitle language. 4.
  • Page 20 Basic Operation Basic Function DIGITAL SATELLITE RECEIVER 9. Simple Channel List 1. When you press OK( ) button during receiving service stream, you can get “Channel List” view. 2. Using UP/DOWN( ) buttons in “Channel List” view, you can choose another channel.

  • Page 21: Menu Guide

    Menu Guide Easy Installation 1. Automatic Installation by “Easy Installation” 2. System Connection 3. Power On 4. Power Off Before you can view the television or radio program, you must perform the installation procedure first. Therefore you will see only “Easy Installation Menu” at first when you plug in your system.
  • Page 22 Menu Guide Easy Installation DIGITAL SATELLITE RECEIVER Language The first option is “Language Select” to select the desired language of the Menu, Audio, or Subtitle. Place the cursor on the sub menu by pressing the keys and press the OK( ) button to change language.

  • Page 23: Main Menu

    Menu Guide Main Menu Press the MENU button on the remote control unit. You will see the “Main Menu” on the screen. 1. You can move into the desired submenu using UP/DOWN( 2. You should enter the PIN code in order to move into the corresponding submenu in case of “Edit Channel List or “System Setting”.

  • Page 24: Channel Search

    Menu Guide Channel Search DIGITAL SATELLITE RECEIVER Channel Search / Installation (None, DiSEqC Switch) 1. Satellite : Select the satellite list you want using UP/DOWN( buttons on the satellite list. - Edit, Add, or Delete ♦ Press YELLOW button to edit, add, or delete satellite list. Pop Up menu will appear.
  • Page 25 Menu Guide Channel Search - Scan Press the RED button on the TP list. Pop up window will be displayed on the screen. ♦ Frequency : Input a proper Frequency using NUMERIC buttons. ♦ Symbol Rate : Input a proper Symbol Rate using NUMERIC buttons. ♦...
  • Page 26 Menu Guide Channel Search DIGITAL SATELLITE RECEIVER 3. C/KU Switch : You can select C/KU band by selection of switch type. 4. LNB Freq. : Select the proper LNB frequency referring to your LNB using OK( ) and UP/DOWN( 5. C-LNB Freq. : When selecting the C/KU Switch is selected as “None”, the C-LNB Freq will be dimmed automatically.

  • Page 27: Channel Search / Installation (Diseqc 1,2)

    Menu Guide Channel Search Channel Search / Installation (DiSEqC 1,2) 1. Satellite : Select the satellite list you want using UP/DOWN( buttons on the satellite list. - Edit, Add, or Delete ♦ Press YELLOW button to edit, add, or delete satellite list. Pop Up menu will appear.
  • Page 28 Menu Guide Channel Search DIGITAL SATELLITE RECEIVER - Scan Press the RED button on the TP list. Pop up window will be displayed on the screen. ♦ Frequency : Input a proper Frequency using NUMERIC buttons. ♦ Symbol Rate : Input a proper Symbol Rate using NUMERIC buttons.
  • Page 29 Menu Guide Channel Search 6. 22KHz : Depending on the user’s antenna switch box or LNB. You can supply either 22KHz by setting “ON” or not by setting ”OFF”. When selecting the U-LNB 1 and U-LNB 2, the 22KHz will be dimmed. 7.

  • Page 30: Channel Search / Installation (Usals)

    Menu Guide Channel Search DIGITAL SATELLITE RECEIVER Channel Search / Installation (USALS) 1. Satellite : Select the satellite list you want using UP/DOWN( buttons on the satellite list. - Edit, Add, or Delete ♦ Press YELLOW button to edit, add, or delete satellite list. Pop Up menu will appear.
  • Page 31 Menu Guide Channel Search - Scan Press the RED button on the TP list. Pop up window will be displayed on the screen. ♦ Frequency : Input a proper Frequency using NUMERIC buttons. ♦ Symbol Rate : Input a proper Symbol Rate using NUMERIC buttons. ♦...
  • Page 32 Menu Guide Channel Search DIGITAL SATELLITE RECEIVER 7. 0V/12V : Depending on the user’s antenna switch box. You can choose either 0V/12V. 8. Tone Burst : Depending on the user’s antenna switch box. (“off”, “SAT A” or “SAT B”) 9. Longitude : Press the NUMERIC buttons and enter the Longitude.

  • Page 33: Channel List

    Menu Guide Channel List This menu helps you to easily select the channel that you want to watch. You can see the channel list when you had searched before. To use this menu, you should set channel group you want in the Edit Channel List menu. 1.

  • Page 34: Edit Channel List

    Menu Guide Edit Channel List DIGITAL SATELLITE RECEIVER From these menus, You can create favorite lists, lock, skip, delete, or move channel. 1. Select “Edit Channel List” in the main menu with UP/DOWN( and press OK( ) button. 2. At the request window, Input PIN code.
  • Page 35 Menu Guide Edit Channel List 1. Favorite 1 ~ 8 (Option) 2. Lock 3. Delete 1. You can edit favorite TV and Radio list. This enables you to create the 8 favorite TV and Radio lists. 2. Select the channel you want to edit favorite list and press OK( Note: To rename the Favorite channel, press INFO(BLUE) button.
  • Page 36 Menu Guide Edit Channel List DIGITAL SATELLITE RECEIVER 4. Skip 1. You can skip TV or Radio channel from the current list. 2. Select the channel you want to skip and press OK( 3. To recover the skipped channel, press the OK( 5.

  • Page 37: Program Guide

    Menu Guide Program Guide 1. Now/Next Program Guide 2. Weekly Program Guide 3. EPG Information The program guide supplies information such as program listings and ending times for all available programs. 1. Select “Program Guide” in the main menu with UP/DOWN( press OK( ) button.

  • Page 38: System Setting

    Menu Guide System Setting DIGITAL SATELLITE RECEIVER You will be asked to enter your PIN code before you can enter this menu. The PIN code preset to 0000 from the factory. The code can be changed from the “Change PIN Code” menu. Refer to page 37.

  • Page 39: Audio Language

    Menu Guide System Setting 2. Audio Language 3. Subtitle Language 4. SCART Output (option) In this menu You can change default language for audio when changing services. 1. Use the UP/DOWN( ) buttons to move to language you want and then press OK( ) button.

  • Page 40: Screen Type

    Menu Guide System Setting DIGITAL SATELLITE RECEIVER 5. Screen Type If you have a TV set with the 4:3 picture format and the transmission is in 16:9, you can select 4:3 letterbox, 4:3 full screen and 16:9 full screen. 1. Select the aspect ratio of TV which is connected to STB and then press OK( ) button.

  • Page 41: Rf Channel (Option)

    Menu Guide System Setting 8. RF Channel (option) 9. Local Time 10. Menu Transparency Select this alternative if you have to change the RF channel. Select an UHF Channel you want with UP/DOWN( The RF Channel ranges from 21 to 69. You can set your local time according to your location.

  • Page 42: Change Pin Code

    Menu Guide System Setting DIGITAL SATELLITE RECEIVER 11. Change PIN Code From here you can change the PIN code from the standard 0000. DO NOT FORGET IT! Without it, you are not able to access to any of the functions where the code is required. You can change password for Parental Lock and Receiver Lock simultaneously.

  • Page 43: Receiver Lock

    Menu Guide System Setting 13. Receiver Lock 14. M 15. S/PDIF Output (option) If you select “On”, you will have to enter the PIN code every time you start the receiver from standby. Lock If you select “On”, you will have to enter the PIN code every time when you enter the Channel Search Menu and Channel List Menu You can hear digital audio of the Dolby 5.1 channel using S/PDIF...

  • Page 44: Auto Power (Option)

    Menu Guide System Setting DIGITAL SATELLITE RECEIVER 16. Auto Power (option) 1. If the Auto Power is set to On and power is off, the Set turns on automatically and turns into the channel mode which you were watching before power break- down.

  • Page 45: Common Interface

    Menu Guide Common Interface The menus are provided by the CA module and its smart card. Your receiver is equipped with two slots of Common Interface(CI), accepting both Type 1 and Type 2 PCMCIA modules(see diagram below.). Plug in the appropriate CI module together with a valid smart card. You will then have access to the respective scrambled and Pay-Per-View services.

  • Page 46: Utility (Option)

    Menu Guide Utility (option) DIGITAL SATELLITE RECEIVER 1. Game 1. Select “Game” in the Utility menu with UP/DOWN( press LEFT/RIGHT( / ) button. 2. Select the game you want to play and press OK( and then you can play the game. Tetris Hexa Puzzle...
  • Page 47 Menu Guide Utility (option) 4. Zoom 5. Calculator Select “Zoom” in the Utility menu with UP/DOWN( press OK( ) button, the white frame will appear. ♦ Select the size and position of video you want to expanded with RED/GREEN, LEFT/ RIGHT buttons and press OK( you can see the expanded video.

  • Page 48: Pvr Guide

    PVR Guide Basic Function DIGITAL SATELLITE RECEIVER (Option Function) 1. Recording 1. Pressing the RECORDING( begin recording. 2. Pressing the STOP( ) button will stop recording. 2. Record Menu 1. When the RECORDING( ) button is pressed again during recording, the Record Menu will appear in the center of the screen.

  • Page 49: File List

    PVR Guide (Option Function) Basic Function 3. File List This displays the list of files that the user has saved onto the HDD. Saved files can be selected and displayed, or selected and deleted from this menu. 1. Pressing the FILE LIST( ) button will display the FILE LIST on the screen.

  • Page 50: Fast-Forward & Rewind

    PVR Guide Basic Function DIGITAL SATELLITE RECEIVER (Option Function) 4. Fast-forward & Rewind The Fast-Forward and Rewind functions enable the user to view the front, back or any desired part of the file. 1. To view forward parts press the FF( parts press the REW( ) button on the remote control.

  • Page 51: Slow-Motion

    PVR Guide (Option Function) Basic Function 6. Slow-Motion 7. Time-Shift The Slow-Motion function can be used to PLAY at a slower speed. 1. Pressing the SLOW MOTION( ) button will play the screen at a slower speed. 2. When the button is pressed again, the screen will play at an even slower speed.

  • Page 52: Instant-Replaying

    PVR Guide Basic Function DIGITAL SATELLITE RECEIVER (Option Function) 8. Instant-Replaying This function enables replaying previous parts of the current channel. 1. Pressing the QUICK REPLAY( 10 seconds before, on the current channel. Every time the QUICK REPLAY( seconds before the current time. 2.

  • Page 53: Delayed Recording

    PVR Guide (Option Function) Basic Function 9. Delayed Recording 10. Format HDD The user can record a desired program at a desired time by using the Delayed Recording function. 1. Once, Daily, Weekly Recording. ♦ Use the UP/DOWN( ), LEFT/RIGHT( screen to select the date and time.

  • Page 54: Troubleshooting

    Troubleshooting Problem No display LED on the front panel. No power supply No Picture Poor picture quality No Sound Remote Control does not operate Service is not running or scrambled. You have forgotten your secret PIN code. DIGITAL SATELLITE RECEIVER Solution Power cord plug in correctly.

  • Page 55: Technical Specifications

    Technical Specifications Tuner FEC Modes Rate Input Connector Frequency Range Symbol Rate Demodulation RF Modulator PLL type TV Standard RF Connector Frequency Range MPEG TS A/V Decoder Video Resolution Input Bit Rate Transport Stream Audio Decoding Audio Mode 1/2, 2/3, 3/4, 5/6, 7/8 F type female (75 Ohm) 950MHz ~ 2150MHz 2 ~ 45 Mbaud...
  • Page 56 Technical Specifications A/V & Data Input/Output Video Audio RS-232C System Resources Flash Memory SDRAM Main CPU MPEG Chip Power Supply Input Voltage Power Consumption Protection Type Physical Specification Size(W × H × D) Net Weight Operating Temperature Storage Temperature Option Function Common Interface Embedded CAS SW Upload...

  • Page 57: Menu Map

    Menu Map Main Menu Channel Search Channel List Edit Channel List Program Guide System Setting Common Interface Utility (Option) Menu Language Audio Language Subtitle Language SCART Output Screen Type Banner Time RF Mode RF Channel Local Time Menu Transparency Change PIN Code Parental Lock Receiver Lock Menu Lock...
