Kaon KTF-I2001CO User Manual

Dvb-t digital terrestrial receiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

User's Manual

Digital Terrestrial Receiver

English
Please read the entire manual thoroughly and retain it for future reference.
STB_Starman_HDCab_Ter_K7_RCU500S_F660VFD_109292_Eng.indd 1
2008-08-19
7:17:02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KTF-I2001CO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kaon KTF-I2001CO

Summary of Contents for Kaon KTF-I2001CO

  • Page 1: Digital Terrestrial Receiver

    User's Manual Digital Terrestrial Receiver English Please read the entire manual thoroughly and retain it for future reference. STB_Starman_HDCab_Ter_K7_RCU500S_F660VFD_109292_Eng.indd 1 2008-08-19 7:17:02...

  • Page 2: General Safety

    General Safety Cautions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : To reduce the risk of electrical shock, do not remove the cover. No user serviceable parts inside. Refer any servicing to qualified Service personnel. Read this manual carefully before using the product. The cautions described below contain important information about safety, and are categorized into: Danger, Warning and Notice.
  • Page 3 Cautions Warning If the product is mishandled, the user might receive a serious or minor injury. Damage or loss to the user’s property might also result. • The product must not be exposed to water or liquid. If the apparatus is exposed to drips or splashes, it might cause a problem that cannot be repaired. • Do not repair, disassemble or modify this apparatus yourself. It might be seriously damaged, possibly beyond repair. • Turn off the power and unplug the power cord as quickly as possible during electric storms. They might damage the apparatus. • Remove the antenna’s power plug from the outlet as quickly as possible during electric storms, or the apparatus might be damaged.

  • Page 4: Table Of Contents

    Contents General Safety ....................2 1. Functions and Installation ................ 5 1.1 Remote Control Unit ..............5 1.2 Setting Your TV................6 1.3 Front Panel ................11 1.4 Rear Panel ................11 1.5 Smart Card ................12 1.6 Connecting and Installation ..........13 2. Easy Installation ..................15 3.

  • Page 5: Functions And Installation

    1. Functions and Installation 1.1 Remote Control Unit ① SUB-T (Red) To enable or disable subtitle. ② ⑬ To select button in the On Screen Display(OSD). ⑭ NUMERIC BUTTONS ③ ⑮ To select the channel and enter the channel edit and PIN code. ④...

  • Page 6: Setting Your Tv

    1.2 Setting Your TV 1.2.1 Using the THREE DIGIT CODE 1. Turn the TV on before setting the remote control. MENU EXIT 2. Press with button on the remote control for 2 seconds to convert to Setting Mode. • It will convert to the Setting Mode after the lamp is on. Note : Setting mode will be exited if no input is made for more than 20 seconds.
  • Page 7 Manufacturer Input Code (3digit) List Manufacturer Input Code (3digit) List A.R. SYSTEMS 049 152 CGE 002 090 093 094 107 139 142 163 168 346 ACCENT 049 152 348 369 407 413 421 480 ACEC 112 CIHAN 217 ACURA 195 CIMLINE 123 134 195 ADMIRAL 065 076 163 171 190 307 324 369 466 481 CITY 195 ADYSON 379 CLARIVOX 049 125 163 AGASHI 076 379 CLATRONIC 045 049 076 113 123 152 195 225 379 407 AGEF 324 413 421 AIKO 049 076 102 141 152 172 195 225 379 CMS HIGHTEC...
  • Page 8 Manufacturer Input Code (3digit) List Manufacturer Input Code (3digit) List FORMENTI 049 090 107 113 139 307 324 379 407 467 INTERVISION 045 049 055 076 107 123 152 225 232 378 469 480 481 379 380 413 421 FORMENTI-PHOENIX 050 104 113 307 FORTRESS 190 324 IRRADIO 049 066 090 123 152 195 407 413 FRABA 049 152 421 ISUKAI 049 123 152 378 FRIAC 045 049 152 195 ITC 379 480 FRONTECH 066 076 139 195 307 379 413 466 470 477 ITS 049 076 123 152 225 378 379 FUJITSU 042 045 071 102 107 195 236 379 ITT 042 090 107 134 139 150 157 162 171 172 FUJITSU GENERAL 195 379 193 197 198 209 307 375 428 466 469 470 FUNAI 042 076 094...
  • Page 9 Manufacturer Input Code (3digit) List Manufacturer Input Code (3digit) List MEMPHIS 102 125 195 213 PERDIO 049 102 107 113 152 467 MERCURY 049 152 195 PERFEKT 049 152 METZ 049 065 067 070 092 247 324 412 420 454 PERSHIN 425 PHILCO 002 016 049 065 090 093 094 104 107 126 MICROMAXX 049 152 195 142 152 163 168 324 346 348 369 407 413 MICROSTAR 440 441 443 444 421 480 481 MINERVA 080 090 232 247 249 407 454 PHILEX 471 MINOKA 049 152 426 470 PHILHARMONIC 379 MITSUBISHI 013 018 049 065 105 131 152 157 190 247 PHILIPS 008 049 050 065 079 089 112 152 157 160 324 454...
  • Page 10 Manufacturer Input Code (3digit) List Manufacturer Input Code (3digit) List SCHNEIDER 008 040 049 050 065 069 079 104 107 112 TELEVISO 425 123 139 152 156 160 168 172 182 195 225 TEMCO 094 243 307 379 382 413 414 417 457 468 470 TEMPEST 049 152 195 SCOTT 042 TENNESSEE 049 152 SEARS 042 TENSAI 020 050 055 094 113 123 152 195 225 226 SEG 018 045 049 050 076 107 152 172 195 232 379 413 450 467 379 413 407 457 480 TESMET SEI 004 045 049 094 107 139 152 236 324 357 TETUNG 046 469 470 481 TEVION 049 152 195 SEI SINUDYNE 446 TEXET...

  • Page 11: Front Panel

    1.3 Front Panel STAND BY(POWER) MENU Switch the receiver power "ON" or "OFF". To see main menu. VOL ◄/► EXIT To turn the volume Up/Down or select a Exit from parameter and cancel selected function. sub-menu item. CH ▲/ ( Program To display the current state, such as channel, ▼...

  • Page 12: Smart Card

    1.5 Smart Card Caution Please do not plug in the main power supply cord until you have finished all of the connections! Although some TV and radio channels are free to view, you must subscribe to most TV and radio/music channels and a Conditional Access component is required. If you want to enjoy watching scrambled broadcasting channels, you need to purchase a smart card from a service provider’s sales department. However, broadcasting channels from multiple service providers call for multiple Smart cards.

  • Page 13: Connecting And Installation

    1.6 Connecting and Installation 1.6.1 How to connect the receiver to various other systems There are several ways of connecting the receiver to your TV, VCR and/or Hi-Fi SYSTEM. Consult your local supplier for assistance in setting-up your system that is best suited to your requirements. 1.6.2 To Connect Terrestrial • Connect one end of the antenna cable to the ANT IN on the back of the receiver and the other end to a terrestrial antenna connection or the jack for the public antenna on the wall.
  • Page 14 1.6 Connecting and Installation 1.6.5 Connect the receiver to a Hi-Fi System • Connect a RCA stereo cable from the AUDIO L/R jacks, S/PDIF on the receiver to the LINE, AUX, SPARE • Digital Amp or EXTRA input jacks on your Hi-Fi System. 1.6.6 Connect the receiver to a Digital Audio System • If you have a soundsystem with S/PDIF coaxial input, you can connect the receiver with it to enjoy higher quality sound. Connect the S/PDIF coaxial cable to a digital amplifier.

  • Page 15: Easy Installation

    2. Easy Installation 2.1 Menu Application MENU Press the button on the remote control unit. You will see the “Main Menu” on the screen. • You can move into the desired submenu using the UP/DOWN/LEFT/RIGHT buttons. • You should enter the PIN code in order to move into the corresponding submenu in case of the Installation, the Edit Channel List or the System Setting. • Press the OK button to confirm your selection. • Press the MENU button to return to previous menu. Or press the EXIT button to quit the Menu system completely.

  • Page 16: Basic Operation

    2.2 Easy Installation 2.2.2 Local Time/GMT Select the time setting type. Press the LEFT/RIGHT buttons to select local language. LEFT/RIGHT Auto or Manual. Press the buttons to select Press the LEFT/RIGHT buttons to select GMT time of each region and setting up the default time.
  • Page 17 3. Basic Operation 3.1 Basic Function Usage 3.1.3 Subtitle • Press the RED button and the popup window will be displayed on the screen. • Selecting “Subtitles(language)”, enables you to see the desired subtitles. • Selecting “Off” will turn the subtitle function off. 3.1.4 Teletext • If a broadcast supports teletext, you can watch teletext. • If you press the TEXT button, teletext will appear on the screen. 3.1.5 Simple Channel List • When you press the OK button during receiving service stream, List” view.

  • Page 18: Main Menu Guide

    4. Main Menu Guide 4.1 Channel List This menu helps you to easily select the channel that you want to watch. You can see the channel list you installed earlier. To use this menu, you should set channel group you want in the Edit Channel List menu.

  • Page 19: Program Guide

    4.3 Program Guide Select “Program Guide” in the main menu with the UP/DOWN buttons and press the button. In the viewing program, when you press the GUIDE button, you can get this view. Note • The Program Guide information might not be supported by the service providers. 4.3.1 Grid EPG Program Guide •...

  • Page 20: Network

    4.4 System Setting 4.4.1 Manu Language / Audio Language / Subtitle Language You can change default language for menus, audio, and subtitle when changing services. 4.4.2 Network In this menu, you can set network. Use the UP/DOWN buttons to move to network you want and then press the button.
  • Page 21 4.4 System Setting 4.4.9 Menu Transparency The menu transparency is variable between 20% and 100%. To set menu transparency, press the UP/DOWN buttons. The transparency will be applied on the screen. 4.4.10 Change PIN Code From here you can change the PIN code from the standard 0000. DO NOT FORGET IT! Without it, you are not able to access to any of the functions where the code is required. You can change password for Parental Lock and Receiver Lock simultaneously. • Input the current PIN code using the NUMERIC buttons on the remote control.
  • Page 22 4.4 System Setting 4.4.15 Auto Power • If the Auto Power is set to On and power is off, the Set turns on automatically and turns into the channel mode which you were watching before power breakdown. • If the Auto Power is set to Off and power is off, the Set turns into the standby mode. 4.4.16 Factory Reset UP/DOWN Press the buttons on the Setup list to select Factory Reset. Use this option only if you have to start the complete installation procedure from scratch.

  • Page 23: Ca System

    4.5 CA System Your receiver is equipped with 1 slot of smart card. Plug in the appropriate a valid smart card. You will then have access to the respective scrambled and Pay-Per- View services provided. Insert the smart card into the slot. The smart card determines the programs that can be de-scrambled.

  • Page 24: Technical Specifications

    6. Technical Specifications Tuner & Channel RF input connector DIN type Female DIN type, IEC 60169-2 male connector 75 Ohm Frequency range VHF: 170~230MHz, UHF: 470~862MHz Input signal level -78.5dBm~-10dBm Channel bandwidth 8MHz, 7MHz De-modulation standard COFDM MPEG TS A/V DECODING Transport stream MPEG-4/H.264 HP@L4.0 1920X1080 interface@50Hz MPEG Profile/level MPEG-2 MP@HL, MPEG-4/AVC MP@L4 Input bit rate Max. 81.0 Mbit/Sec. Video aspect ratio 4:3, 16:9, Letter Box Video formats 576i, 576p, 720p, 1080i Video outputs...
  • Page 25 K7_GB_109292 STB_Starman_HDCab_Ter_K7_RCU500S_F660VFD_109292_Eng.indd 25 2008-08-19 7:17:17...
