  • Page 1 User's Manual Digital Combo Receiver KTSC-S660HD...

  • Page 2: General Safety

    General Safety Warning Always follow these instructions to avoid the risk of injury to yourself or damage to your equipment. Unplug the receiver from the AC power outlet before cleaning. Use only a damp cloth for cleaning the exterior of the receiver. Do not use accessories or attachments not recommended by the receiver manufacturer as they may cause problems to the equipment and will void the warranty.
  • Page 3 General Safety Digital Combo Receiver Owner's Manual OPERATION HANDBOOK Before operation, Please read the entire manual thoroughly Channel Search and retain it for future reference. Channel List Edit Channel List Program Guide System Setting Common Interface (Option) Utility (Option) DIGITAL COMBO RECEIVER...

  • Page 4: Table Of Contents

    Contents Remote Control Unit ............6 Front Panel .
  • Page 5 Contents Menu Lock ................37 S/PDIF Output .

  • Page 6: Remote Control Unit

    Remote Control Unit STAND BY TUNER(Only COMBO) NUMERIC BUTTON Multichannel Button TEXT TV/STB YELLOW BUTTON/TIMER GREEN BUTTON INFO(BLUE BUTTON) SUBTITLE(RED BUTTON) LEFT/RIGHT MENU EXIT UP/DOWN CH UP/DOWN VOL UP/DOWN GUIDE PAUSE MUTE A.L/R A.LANG TV/RADIO FAV. SLEEP OPTION V.FORMAT RECALL P.SIZE ZOOM Note 1 When inserting batteries, make sure that the polarity (+/-) is correct.
  • Page 7 Remote Control Unit STAND BY To switch between operation and stand by mode. TUNER To switch between Terrestrial and Satellite mode. (Only COMBO) NUMERIC BUTTONS To select the channel and enter the channel edit and PIN code. MULTICHANNEL BUTTON Multi video pop-up window will appear. TV/STB To switch between TV and STB receive mode.

  • Page 8: Front Panel

    Front Panel Note! : The design of the Front Panel may be changed without any notice in advance. 1. POWER(STAND BY) Switch the receiver power "ON" or "OFF". 2. OK Select a program, a highlighted line or parameter value. 3. CH �� ��� �� ����������� CH �� ��� ���� ��...
  • Page 9 Front Panel VFD Information 1. Indicates MP3 mode. 2. Indicates Terrestrial or Satellite mode. (TS lights when the terrestrial channel is on / TS lights off with the satellite channels) 3. Indicates when the tv channel is on. 4. Indicates when the radio channel is on. 5.

  • Page 10: Rear Panel

    Rear Panel Note! : The design of the Rear Panel may be changed without any notice in advance. TERRESTRIAL 1. ANTENNA To connect to a digital terrestrial antenna input. 2. RF LOOP OUT Used to connect a RF signal from the Receiver to either the RF input jack on your television or to the Receiver (RF Loop In).

  • Page 11: Connecting Your Equipment

    Connecting Your Equipment How to connect your STB to various systems There are several ways of connecting the STB to your TV, VCR and/or Hi-Fi SYSTEM. Consult your local supplier for assistance in setting-up your system that is best suited to your requirements. 1.
  • Page 12 Connecting Your Equipment 4. Connect STB to a VCR set Connect your SCART jack from the VCR to the back of the receiver. Alternatively you can use A/V, TV out (UHF) or S-Video jacks. 5. Connect STB to a Hi-Fi System Connect a RCA stereo cable from the AUDIO L/R jacks, S/PDIF on your STB to the LINE, AUX, SPARE or EXTRA input jacks on your Hi-Fi System.
  • Page 13 Connecting Your Equipment TV with Trerrestrial Antenna 1. Connect one end of RCA/Cinch cable to the RCA/ Cinch jack on the back of the STB and the other end to a RCA/Cinch jack on your TV. If your TV doesn’t have a RCA/Cinch jack, connect one end of RF cable to the TV OUT on the back of the STB and the other end to a RF input jack on your TV.
  • Page 14 Connecting Your Equipment Reference 1. DiSEqC 1.0 Connection All our receivers are designed to be DiSEqC 1.0 and DiSEqC 1.2 compatible. This allows multiple antennas to be connected to the STB at the same time. If you have two or more fixed antennas or LNBs then we recommend you use a DiSEqC 1.0 switch. Connect the coaxial cable from the first LNB to the LNB 1 or LNB A input connector of the DiSEqC switch.

  • Page 15: Basic Operation

    Basic Operation Basic Function 1. Program Information After the television channels have been programmed, you will see the information box each time you change the channels. 1. Every time you change channels you will receive program information for a few seconds. (In the "Banner Time" menu you can select how long this information will be shown.) 2.

  • Page 16: Basic Function

    Basic Operation Basic Function 4. Channel-Information Banner 1. During "Channel Banner" is appearing, when you press INFO(BLUE) button, you can get "Channel-Information Banner". 2. Using "Channel-Information Banner", you can get a detailed channel listing information. 5. Volume Control/Mute 1. To control audio volume, press VOL ▲ or ▼ buttons. 2.
  • Page 17 Basic Operation Basic Function 7. Timer The user can reserve a desired program at a desired time by using the Timer function. 1. Once, Daily, Weekly Reservation. ♦ Use the ▲, ▼, ◄, or ► buttons in the Timer Setting screen to select the date and time.
  • Page 18 Basic Operation Basic Function 9. Soundtrack 1. When you want to change the Audio Language of current channel, press the A.LANG button on the remote control. The on-screen menu is displayed on the left side of the screen. 2. Use ▲ or ▼ buttons to choose the audio you want. 3.

  • Page 19: Menu Guide

    Menu Guide Easy Installation Before you can view the television or radio program, you must perform the installation procedure first. Therefore you will see only "Easy Installation Menu" at first when you plug in your system. The Easy Installation gives you the convenience of selecting various languages, adjusting the time and channel search.
  • Page 20 Menu Guide Easy Installation Language The first option is "Language Select" to select the desired language of the Menu, Audio, or Subtitle. Place the cursor on the sub menu by pressing the keys and press the OK button to change language. The Language of Menu, Audio, or Subtitle will be changed to the selected language.

  • Page 21: Main Menu

    Menu Guide Main Menu Press the MENU button on the remote control unit. You will see the "Main Menu" on the screen. 1. You can move into the desired submenu using ▲ or ▼ buttons. 2. You should enter the PIN code in order to move into the corresponding submenu in case of "Edit Channel List"...

  • Page 22: Channel Search

    Menu Guide Channel Search - Satellite Search Select channel search in main menu. At the POP Up window, select DiSEqC MODE. DiSEqC : None, Switch , MOTOR (DiSEqC 1,2), USALS 1. Satellite : Select the satellite list you want using buttons ▲...
  • Page 23 Menu Guide Channel Search - Scan Press the RED button on the TP list. Pop up window will be displayed on the screen. Input a proper Frequency using NUMERIC buttons. ♦ Frequency : Input a proper Symbol Rate using NUMERIC buttons. ♦...
  • Page 24 Menu Guide Channel Search 3. C/KU Switch : You can select C/KU band by selection of switch type. 4. Position (MOTOR (DiSEqC 1,2)) : After selecting a satellite, please select position number. To change value, press OK button. The position list will be displayed. 5.
  • Page 25 Menu Guide Channel Search 14. Longitude (USALS) : Press the NUMERIC buttons and enter the Longitude. When the OK button is pressed. It can be toggled East/West. : Press the NUMERIC button and enter the Latitude. 15. Latitude (USALS) When the OK is pressed, it can be toggled North/South. 16.

  • Page 26: Terrestrial Search

    Menu Guide Channel Search - Terrestrial Search In this menu,You can set terrestrial channel automatically. - Automatic Search for all MUX 1. Press the SUB-T(RED) button to start searching. 2. At the pop up window, select all channel or FTA channel search. 3.
  • Page 27 Menu Guide Channel Search - Manual Search Manual search is more convenient to search a specific MUX. This menu searches also all channels broadcasted over a specific MUX using its detected information. 1. Press the ▲ or ▼ buttons to select the MUX No. you want to find, and then press OK button to add or remove from the search list.

  • Page 28: Channel List

    Menu Guide Channel List This menu helps you to easily select the channel that you want to watch. You can see the channel list when you had searched before. To use this menu, you should set channel group you want in the Edit Channel List menu. 1.

  • Page 29: Edit Channel List

    Menu Guide Edit Channel List From these menus, You can edit favorite lists, lock, skip, delete, or move channel. 1. Select "Edit Channel List" in the main menu with ▲ or ▼ buttons and press OK button. 2. At the request window, Input PIN code. If you have not entered your own PIN code, then the PIN code 0000 applies, which was set at the factory.
  • Page 30 Menu Guide Edit Channel List 1. Favorite 1 ~ 8 (option) 1. You can edit favorite TV and Radio list. This enables you to create the 8 favorite TV and Radio lists. 2. Select the channel you want to edit favorite list and press OK button. Note To rename the Favorite channel, press INFO(BLUE) button.

  • Page 31: Program Guide

    Menu Guide Edit Channel List 5. Move 1. You can change the position of the channel you want on the TV/Radio/ All channel lists. 2. Select the channel you want to move to desired channel and press the OK button. 3.
  • Page 32 Menu Guide Program Guide 1. Now/Next Program Guide Shows the information of Present/Following program on different channels. To watch the programs you go through the display window : 1. Select a program with buttons, you can get the list at right-side view. ▲...

  • Page 33: System Setting

    Menu Guide System Setting You will be asked to enter your PIN code before you can enter this menu. The PIN code preset to 0000 from the factory. The code can be changed from the "Change PIN Code" menu. Refer to page 36. If you want to customize the system to suit you better, you can specify some settings from the submenus in the "System Setting"...

  • Page 34: Subtitle Language

    Menu Guide System Setting 3. Subtitle Language In this menu You can change default language for subtitle when changing services. 1. Use the buttons to move to language you want and ▲ ▼ then press OK button. You can choose the language from a selection of English, Spanish, Finnish, Norwegian, Swedish, German, French, and etc..

  • Page 35: Banner Time

    Menu Guide System Setting 5. Banner Time When you switch channels, an information banner will be shown for a few seconds. You can select for how long the banner will be shown. 1. Select the banner time you want and then press OK button. 2.

  • Page 36: Change Pin Code

    Menu Guide System Setting 8. Change PIN Code From here you can change the PIN code from the standard 0000. DO NOT FORGET IT! Without it, you are not able to access to any of the functions where the code is required. You can change password for Parental Lock and Receiver Lock simultaneously.

  • Page 37: Menu Lock

    Menu Guide System Setting 11. Menu Lock If you select "On", you will have to enter the PIN code every time when you enter the Channel Search Menu and Channel List Menu. 12. S/PDIF Output You can hear digital audio of the Dolby 5.1 channel using S/PDIF Output. 1.

  • Page 38: S/W Upgrade Via Usb

    Menu Guide System Setting 14. S/W Upgrade via USB 15. Factory Reset Use this option only if you have to start the complete installation procedure from scratch. If you continue from here, all your previous settings and all channels will be cleared ! The default data will be loaded.

  • Page 39: Common Interface

    Menu Guide Common Interface The menus are provided by the CA module and its smart card. Your receiver is equipped with two slots of Common Interface(CI), accepting both Type 1 and Type 2 PCMCIA modules(see diagram below.). Plug in the appropriate CI module together with a valid smart card. You will then have access to the respective scrambled and Pay-Per-View services.

  • Page 40: Utility

    Menu Guide Utility 1. Demonstration Select "Demonstration" in the Utility menu with buttons and press ▲ ▼ OK button, you can see the Automatic Operation Function. Press the EXIT button to quit the Automatic Operation Function completely. 2. Calendar 1. Select "Calendar" in the Utility menu with buttons and press OK ▲...

  • Page 41: Troubleshooting

    Troubleshooting Solution Problem Power cord plug in correctly. No display LED on the front panel. No power supply Ensure that the STB is switched on. No Picture Check connection and correct. Check channel and video output and correct Check the signal level, if this is low then try adjusting the Poor picture quality alignment of your dish.

  • Page 42: Technical Specifications

    Technical Specifications Tuner Demodulation QPSK & 8PSK FEC Code Rate DVB-S (QPSK) : 1/2, 3/5, 3/4, 4/5, 5/6, 8/9, 9/10 DVB-S (8PSK) : 2/3, 3/4, 3/5, 5/6, 8/9, 9/10 Input Connector Satellite F type female (75 Ohm) Frequency Range 950 MHz - 2150 MHz Symbol Rate 2 - 45 Mbaud Guard Interval Modes...

  • Page 43: Power Supply

    Technical Specifications A/V & Data Input/Output RS-232C Digital A/V Output Transfer rate 115Kbps, 9 PIN D-Sub Type Digital A/V Output HDMI(1.0, 1.1)Digital A/V Output System Resources Flash Memory 8Mbytes SDRAM 128Mbytes, 256Mbytes (Option) Main CPU MPEG Chip ST7100 Power Supply Input Voltage 90-260V~ 50/60Hz Power Consumption...

  • Page 44: Menu Map

    Menu Map Main Menu Menu Language Installtion Audio Language Channel List Subtitle Language Edit Channel List Screen Type Program Guide System Setting Banner Time Local Time Menu Transparency Change PIN Code Parental Lock Receiver Lock Menu Lock SPDIF Output Auto Power S/W Upgrade via USB Factory Reset Common Interface...
  • Page 45 Memo DIGITAL COMBO RECEIVER...
  • Page 46 Memo DIGITAL COMBO RECEIVER...
