- Page 1 Set-Top Box & Remote KSTB2100 KAONMEDIA User Installation Guide Rev.100221...
- Page 2 TABLE OF CONTENTS WHAT’S IN THE BOX? SET-TOP BOX AT A GLANCE BUTTON FUNCTIONALITY SELF-INSTALL PHYSICAL PLACEMENT GUIDELINES SELF-INSTALL CONNECTION GUIDELINES INITIAL BOX POWER ON NETWORK SETUP SERVICE VALIDATION TROUBLESHOOTING APPENDIX A : TV Codes for Remote Pairing APPENDIX B : Audio System Codes for Remote Pairing Google, Android, YouTube, Android TV and other marks are trademarks of Google LLC This item incorporates copy protection technology that is protected by U.S.
- Page 3 <FCC User manual Statements> This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)this device may not cause harmful interference, and (2)this device must accept any interference received, including interference that cause undesired operation. FCC Part 15.105 statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
- Page 4 WHAT’S IN THE BOX? KSTB2100 HDMI Cable Power Adapter Set-Top Box (STB) Kaon Voice AA Batteries RCA Analog Composite Classic RCU Breakout Cable (Optional)
- Page 5 SET-TOP BOX AT A GLANCE Perspective View Power Button Status Indicator LED Used to power the Kaon STB Indicates power status of STB (Red = Off, Green = On). On or Off. Infrared (IR) Sensor Used to communicate with the...
- Page 6 Rear View AV Out 12V/1.5A In SD Analog A/V output, used DC Power port, used to connect to connect to older-style TVs via the power adapter. that do not support HDMI connections. Ask your installer for an RCA composite breakout cable if one was not included.
- Page 7 BUTTON FUNCTIONALITY TV ON Google Assistant TV/STB ON Volume Up Fast Backward Mute Play/Pause Volume Down Fast Forward CH UP TV Guide Last Channel Watched Live TV CH Down Menu Up/Down/Left/Right Device Input Return Remote Set Home Number Pad...
- Page 8 The IR sensor is in center of the front face plate. Remote Operating in RF4CE Mode With the remote operating in RF mode, the KSTB2100 may be placed out of sight. This may include behind a wall-mounted TV or in a TV cabinet.
- Page 9 SELF-INSTALL CONNECTION GUIDELINES HDMI Cable Connection The USB port cannot be used to connect an external USB drive to support local DVR capability. What You Need • An HD or Ultra High Definition (UHD) TV that can support 720p, 1080p or 4K UHD. •...
- Page 10 Analog Composite Breakout Cable Connection Connect the analog composite cable as shown below. This connection scheme should only be used if the TV does not have a working HDMI port. Connect the Analog Composite to the TV Ports and Select the Output to TV corresponding AV Source on the TV Input thru WiFi or...
- Page 11 Network Connection You must connect your new STB to an internet connection through either a WiFi wireless connection or a wired Ethernet connection. Wired Network Connection If your home router is near the STB location, a CAT-5/5e/6 Ethernet cable may be used for internet connectivity. Plug one end of the CAT-5/5e/6 cable into the STB RJ45 port.
- Page 12 WiFi Network Connection Connect Automatically Using WPS Navigate to the main menu by pressing the following key sequences: Home → Settings → Network → WiFi → Select to enable. Once WiFi has been enabled, using the remote scroll down and select “Connect via WPS”. Once selected press the WPS button on your home router.
- Page 13 INITIAL BOX POWER ON The following screens describe the remote key sequences required to setup the KSTB2100. When powered up and fully booted, the box will start on this screen. Select Skip and press OK to continue. The following screen will be displayed.
- Page 14 Once logged in, the following Terms of Service screen will be displayed. Select Accept and press OK to continue. Select Yes on the Location screen and press OK to continue.
- Page 15 On the Help Improve screen, select Yes and press OK to continue. On the Choose a Name screen, select the appropriate name for the unit and press OK to continue.
- Page 16 The following Get Started screen will display the login where your Cable Provider App will be located. This app cannot be unselected. Select Continue and press OK to get to the next screen. On the Welcome screen, arrow right five times to get to the next screen.
- Page 17 Select Done and press OK to continue. When it is finished processing, the Login screen will be displayed.
- Page 18 An example login screen is shown. This will be unique for each subscriber. Credentials may be entered using the remote or via a USB keyboard (recommended)
- Page 19 NETWORK SETUP Wi-Fi Requirements Navigate to the main menu by pressing the following key sequences: Home → Settings → Network → WiFi → Select to enable. Once WiFi has been enabled, using the remote scroll down and select “Connect via WPS”. Once selected press the WPS button on your home router.
- Page 20 SERVICE VALIDATION RCU/STB Operation Once STB has been installed and credentials have been entered, the user should confirm that remote works as expected with STB. The user should check the following buttons for correct operation. • Volume up/down • Channel up/down •...
- Page 21 TROUBLESHOOTING TROUBLESHOOTING Observation Things to Check Remediation Relocate router and STB closer WiFi signal strength in STB in proximity with each other Network connection menu. if possible, such that signal is strong or very strong. Ideal for consistent video: Connecting the STB to home Strong WiFi signal router with a CAT-5/5e/ Very Strong WiFi signal...
- Page 22 APPENDIX A APPENDIX A TV Codes for Remote Pairing TV Codes for Remote Pairing - Top 10 US TV Brands - - Top 10 US TV Brands - TV Maker/ Brand Code Number 10305 10265 10001 10012 10051 10092 10011 10118 10124 10132...
- Page 23 Brand List TV Brand List TV TV Maker/ Brand Code Number 10368 A MARK 10103 10132 10388 ACTION 10370 ADMIRAL 10436 10431 ADVENT 10135 10339 ADVENTURA 10372 AFTRON 10373 AIKO 10374 AIWA(R-44A) 10082 10183 AKAI 10148 10317 10318 10348 10352 10542 10439 10476...
- Page 24 Brand List TV Brand List TV TV Maker/ Brand Code Number BLU:SENS 10476 10455 10499 BOLVA 10282 BRADFORD 10380 BRILLIAN 10398 BROCKWOOD 10011 10315 BROKSONIC 10143 10166 10174 10431 BUSH 10399 BYD:SIGN 10400 CANDLE 10001 10002 10003 10011 10439 10372 10543 CANON 10402...
- Page 25 Brand List TV Brand List SOUNDBAR Soundbar Maker/ Brand Code Number AMAZON 20414 APEX 20425 AUVIO 20403 BOHM 20423 BOSE 20440 DENON 20428 EMATIC 20412 GOODMANS 20438 HAIER 20433 HARMAN KARDON 20205 INSIGNIA 20431 JAMO 20435 20432 20430 KLIPSCH 20421 LG(GOLDSTAR) 20069 MAXWELL...
- Page 26 Brand List TV Brand List TV TV Maker/ Brand Code Number EMPREX 10425 ENVISION 10439 10358 10330 ENVIXION 10001 EPSON 10364 ERAE 10442 10317 10318 10311 FISHER 10013 10058 10393 FUJITSU 10149 10228 10333 10334 10376 FUNAI 10033 10045 10380 10311 10376 10452...
- Page 27 Brand List TV Brand List TV TV Maker/ Brand Code Number HITACHI 10017 10011 10015 10016 10001 10018 10029 10043 10072 10132 10144 HITACHI 10147 10203 10204 10206 10207 10208 10210 10211 10368 10452 10543 10357 HUMAX 10143 HYPERION 10011 HYUNDAI 10460 10461...
- Page 28 Brand List TV Brand List TV TV Maker/ Brand Code Number LOEWE 10481 LOGIK 10069 LUCE 10358 10483 LUXMAN 10011 10543 10013 10021 10053 10034 10145 10148 10413 10415 10393 10303 10315 MAGNASONIC 10001 10011 10348 10060 10061 10062 10064 10065 10001 10003...
- Page 29 Brand List TV Brand List TV TV Maker/ Brand Code Number 10543 10405 10344 10439 10315 NETTV 10486 NIKEI 10045 NIKKO 10439 10374 10001 10315 NIKO 10493 NOBLEX 10494 NORCENT 10493 10373 10330 10495 NORWOOD MICRO 10362 10498 10374 NUVISION 10502 OLEVIA 10011...
- Page 30 Brand List TV Brand List TV TV Maker/ Brand Code Number PUNEET 10425 PVISION 10442 QUASAR 10038 10057 10243 10308 10485 RADIO SHACK 10025 10045 10048 10011 10118 10132 10001 10235 10001 10004 10006 10011 10029 10030 10057 10083 10133 10145 10161 10171...
- Page 31 Brand List TV Brand List TV TV Maker/ Brand Code Number SIGNET 10519 10478 10520 SIM2 MULTIMEDIA 10430 SIMPSON 10001 SKYWORTH 10522 SODIFF 10595 SOLARISM 10523 SOLE 10358 10483 10301 10479 10354 10043 10075 10117 10130 10067 10170 10238 10247 10309 10409 10452...
- Page 32 Brand List TV Brand List TV TV Maker/ Brand Code Number TECHNOL ACE 10376 TECHVIEW 10539 10541 TECHWOOD 10011 10388 10543 TELEMAGIC 10402 10001 10002 10003 10011 10030 10033 10036 10045 10069 10074 10092 TEKNIKA 10094 10132 10415 10380 10374 10315 10543 10376...
- Page 33 Brand List TV Brand List TV TV Maker/ Brand Code Number WAYCON 10303 WHITE WESTING HOUSE 10091 10319 10320 10327 10328 10329 10067 10431 10409 10136 WINBOOK 10362 WOOYOUNG 10307 WYSE 10330 XIAOMI 10588 XOCECO 10552 YAMAHA 10001 10011 10439 10315 YORK 10011...
- Page 34 APPENDIX B Audio System Codes for Remote Pairing APPENDIX B Brand List AUDIO Audio System Codes for Remote Pairing Brand List AUDIO Audio Maker/ Brand Code Number ADCOM 20088 20098 20218 20147 20233 AIWA 20141 20022 20110 20142 20182 20025 AKAI 20128 AMAZON...
- Page 35 Brand List AUDIO Brand List AUDIO Audio Maker/ Brand Code Number 20033 20015 20211 20212 20213 20214 20215 20222 20012 20206 20231 KENWOOD 20230 20134 20246 KLIPSCH 20421 20437 LEXICON 20125 20156 20158 20159 LG(GOLDSTAR) 20069 20077 20018 20192 LOTTE 20191 20193 LUXMAM...
- Page 36 Brand List AUDIO Brand List AUDIO Audio Maker/ Brand Code Number PROSCAN 20409 PYLE 20426 20447 20448 QUAD 20408 QUASAR 20014 20094 20062 20106 20120 20138 20056 20123 REALISTIC 20011 20030 20084 20002 20026 20101 REFLEXION 20419 RICHSOUND RESEARCH(RSR) 20405 ROTEL 20089 20080...
- Page 37 Brand List AUDIO Brand List AUDIO Audio Maker/ Brand Code Number ZANTEK 20174 ZVOX 20401...
- Page 38 Brand List SOUNDBAR Brand List SOUNDBAR Soundbar Maker/ Brand Code Number AMAZON 20414 APEX 20425 AUVIO 20403 BOHM 20423 BOSE 20440 DENON 20428 EMATIC 20412 GOODMANS 20438 HAIER 20433 HARMAN KARDON 20205 INSIGNIA 20431 JAMO 20435 20432 20430 KLIPSCH 20421 LG(GOLDSTAR) 20069 MAXWELL...
- Page 39 Brand List SOUNDBAR Brand List SOUNDBAR Soundbar Maker/ Brand Code Number SENTRY 20407 SONOS 20449 SONY 20446 TAOTRONICS 20416 TOSHIBA 20422 VELODYNE 20404 VIZIO 20451 VOGELS 20411 YAMAHA 20427 ZVOX 20401...
