Instruction manual for installation and use
BPT-SP
Wireless thermostat
for the control of radiant panels
Wireless control unit
Two-way radio communication at 433.92 MHz
A convenient solution for the heating of a room
Predictive system
(guarantees the set temperature at the required time)
k montáži a použití
Energy cost savings during holidays
Powered by 2x1.5 V type AA alkaline batteries
Version 11.01
1
Advertisement
Table of Contents
Related Manuals for Fenix BPT-SP
Summary of Contents for Fenix BPT-SP
- Page 1 N251/R02 (08.03.11) Instruction manual for installation and use BPT-SP Wireless thermostat for the control of radiant panels Wireless control unit Two-way radio communication at 433.92 MHz A convenient solution for the heating of a room Predictive system (guarantees the set temperature at the required time) k montáži a použití...
-
Page 2: System Functions
BPT-SP switches the elements on one after the other (after approximately 1s), which prevents a current surge in the network! -
Page 3: Examples Of Use
BPT-SP control unit! For correct communication to occur amongst all elements of a system with a BPT-SP control unit, the learning of the code must take place – the ACTIVATION of each element added to the system! 433.92 MHz,... - Page 4 DESCRIPTION OF BPT-SP PLACEMENT AND CHANGING OF BATTERIES - open the battery case and remove the protective strip; this will make the BPT-SP device functional - adhere to the correct polarity which is shown in the space for batteries when changing...
- Page 5 DESCRIPTION OF THE BPT-SP CONTROL ELEMENTS Changes to the clock (in the PROG mode) setting of date and time (in the holiday mode toggling between elements (in the ACTIV and INFO modes) movement during the setting of a constant 12 – digit phone number (in the...
- Page 6 DESCRIPTION OF THE BPT-SP DISPLAY line 1 –current day indicator line 2 –‘switching on’ indicator ‘check-up needed’ symbol symbol for the setting of the current date and time, see page 7 ‘communication taking place’ indicator symbol for the setting of the current date and time indication of ongoing communication line 3 –...
- Page 7 DESCRIPTION OF BPT-SP FUNCTIONS AND THEIR SETTING Make sure that you have thoroughly read the introductory part of the instruction manual with the description of the appliance, placement of batteries, button functions and display (LCD) symbols! The next part focuses on an explanation of the basic modes and on the setting of important parameters for the correct function of the whole system.
- Page 8 For programmes 1 and 2, odd and even weeks can also be set which will change automatically according to your requirements (page 8). Programming the BPT-SP thermostat directly – select the PROG mode by pressing the F button and +/- T buttons,...
- Page 9 All you need to do is programme when you wish to have the required temperature. BPT-SP will find the heat constants of the room within two days and then it will switch on the heating in advance accordingly.
- Page 10 Type of heating Minimum time of The minimum time of operation of the operation of the boiler during hysteresis is set in minutes. source Selection is to be made according electric heating to the type of the heating system used gas boiler (see the table) oil boiler...
-
Page 11: Entering A Phone Number
- Two diodes will flash simultaneously on the switching element and the element is thus ACTIVATED! If Err appears on the BPT-SP display, it is necessary to check the connection and repeat the procedure! – you can add another element using the +/-H buttons, and... -
Page 12: Other Functions
Always set the DATE and HOUR of your return from the holiday when you require the BPT-SP to return to the set programme (in AUTO or MANU)! - select the AUTO or MANU mode... - Page 13 This function is possible in the AUTO mode; you can set a different temperature than the one set in the programme simply by pressing the buttons. BPT-SP will maintain this temperature until a further +/- T change given by the programme.
- Page 14 Enter the PIN code of the SIM card which is inserted in the GST1 module. Set it using the +/- T buttons and confirm it with the i button. You can toggle among the numbers using the +/- H buttons Thanks to this function, you don’t need to remember the PIN code of the phone card which is inserted into the module which you connect to the central unit.
- Page 15 RETURN MESSAGES ARE SENT WITHIN 3 MINUTES! Note: If the min./max. temperature in the room is exceeded (the set CONST1 AND 2, see the BPT-SP instructions manual, p. 9), a “WARNING” text message is sent automatically in the Info form.
-
Page 16: Technical Parameters
The PZT (advance start-up of heating) function will provide you with a required temperature at a required time. BPT-SP will determine the heat constants of the room within two days and then will automatically switch on the heating the necessary amount of time in advance. The time of advance start-up is automatically limited to 2 hours. - Page 17 ES DECLARATION OF CONFORMITY We, Fenix Trading s.r.o, hereby declare that the product BPT-SP is in accordance with the basic requirements and other relevant provisions of directive 1999/5/ES. Issued: 22.04.2008 If in-warranty or post-warranty service is required, send the unit to the manufacturer’s address.
