- Page 1 NIVERSAL EATER NSTALLATION NSTRUCTIONS CONTENTS Parts List .............. Parts Diagram............Helpful Hints............3 Installation............Operation and Troubleshooting Guide....Warranty Information..........Form #4708, Rev. A, 06-04-03...
-
Page 2: Parts List
PARTS LIST KIT# CONTROLLER ELEMENT SWITCH HARNESS SACK PTS 250-1550 250-2225 250-2226 250-2227 250-2228 250-2229 Item B,C,D PARTS DIAGRAM Heater Element ‘A’ Control Module ‘F’ Controller Harness ‘B’ Sack Parts ‘G’ Extension Harness ‘C’ Scotch Lock Cable Ties Ring Terminal Fused Harness ‘D’... - Page 3 HELPFUL HINTS 1. B EFORE TARTING NSTALLATION a. Automotive electrical experience is beneficial for this installation b. Familiarize yourself with the installation instructions and seat heater system components, prior to installing the system. 2. A HEFT ADIO a. If vehicle is equipped with an , the radio code HEFT ADIO...
- Page 4 INSTALLATION SEAT HEATER ELEMENT Remove seat back cover and cushion cover to expose seat foam. A. Seat cover attachment types: * J-Clips: Insert panel puller into channel (in the seam on bottom edge of seat back) and pull the other side of the seam over the channel to release.
- Page 5 INSTALLATION Mount Element ‘A’ On Back Rest Cushion: F IGURE ON PAGE A. Repeat Steps 2B and 2C. B. Remove the protective layer from the double sided tape on the heater element and center side to side on the seat cushion keeping the heater element away from any plastic or metal objects.
-
Page 6: Final Assembly
INSTALLATION FINAL ASSEMBLY 1. Connect the wires from the seat heating element (lower & back rest) to the controller harness ‘B’ under the seat. Check that the element in the seat back is connected to the harness ‘B’ lead that is labeled BACK. 2. -
Page 7: Troubleshooting
OPERATION AND TROUBLESHOOTING TROUBLESHOOTING ! WARNING ! Using a Test Light may cause damage to the vehicle. It is recommended to use a Volt/Ohm meter for all electrical testing. A: NO HEAT POSSIBLE CAUSES SOLUTION STEP 1 No ACC. *Check all connections, vehicle ACC fuse, in line 10 amp fuse, fix or replace if needed. - Page 8 36 MONTH/36,000 MILE LIMITED WARRANTY Rostra Precision Controls, Inc. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven to have defective material or workmanship within 36 months or 36,000 miles of the original purchase, such defect(s) will be repaired or replaced (at the Company’s option) without charge for the parts.
