Digital Satellite Receiver
User Manual
DishTV S7070

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S7070 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dish TV S7070

Summary of Contents for Dish TV S7070

  • Page 1 Digital Satellite Receiver User Manual DishTV S7070...

  • Page 2: Safety Information

    Safety Information CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN The lightning ash with Warning: The exclamation point arrowhead arrow-head symbol, within To reduce the risk of within an equilateral an equilateral triangle, is electric shock, don't open triangle is intended to alert intended to alert the user the cabinet.

  • Page 3: Table Of Contents

    Contents Quick Setup Guide ......... Main Menu .

  • Page 4: Quick Setup Guide

    Quick Setup Guide Step 1 - Connecting you Set Top Box After unpacking your Set Top Box, Connect as shown in the diagram below. Step 2 - Choose your location Once you have the Set Top Box connected, turn the power on. The rst screen that is displayed will ask you to enter you location within New Zealand.
  • Page 5 Step 3 - Tuning in Freeview Channels Having selected your location, the Set Top Box will then commence automatic tuning for the Freeview channels. A screen showing tuning progress will be displayed (see example below) It will tell you that the Set Top Box is automatically tuning in the Freeview channels. Tuning can take a few minutes.

  • Page 6: Main Menu

    Main Menu This menu is the gateway for all other menus. All the settings and tuning menus are selected from this menu. After tuning the box, user can access the main menu by pressing the "MENU" key. Main menu contains several options like •...

  • Page 7: Channel Manager

    Channel Manager You can operate the channel related functions by using this Channel Manager menu, like, • Channel Organiser • New Channel • Edit Channel • Delete All You can navigate between the options by using UP/DOWN keys and select the option by OK key. Channel Organizer All the services of the current mode are listed in this menu.
  • Page 8 The Skip option is used to hide the channel during channel plus and minus operation. For example if STB has a total of 10 services and if you skipped services 3,4 and 5. After this process, if the you presses the channel plus - from the 2nd channel the receiver will switch to the 6th channel automati- cally instead of channel 3, 4 &...
  • Page 9 Channel names can be changed by selecting the rename option by pressing info key, the new name can be given by selecting the letters in the keypad. For example, to select the letter 'R' you have to the key 6 in three times. Blue color key - Used to insert the numbers.

  • Page 10: New Channels

    New Channels Although all new Freeview channels are added automatically, you can add a new channel manually, by specifying the Audio, Video and PCR PIDs of that channel. This is recommended only for advance users. Using the arrow keys on your remote control, rst select your satellite, then the transponder number, frequency, symbol rate and polarization...

  • Page 11: Edit Channels

    After giving all the necessary parameters, add the new channel by pressing the OK key. Edit Channels As all new Freeview channels are automatically added, this section is for advanced users only. Using the Edit Channel option the PID values for existing channels can be edited.
  • Page 12 The Delete all menu is useful to delete all the items in a particular category in a single step. • All TV Services • All Radio Services • All FTA Services • All Scrambled • All Transponders. For every category deletion, you will be asked for con rmation to proceed further.

  • Page 13: Installation Menu

    Installation Menu Although the DishTV S7070 Freeview satellite receiver automatically tunes in the Freeview channels, you may at times wish to add extra channels that are not from Freeview. If you know that your satellite dish system can receive other free channels, the Installation Menu allows you to tune in these channels easily.

  • Page 14: Satellite Setup

    Satellite Setup This is satellite setup entry menu. By pressing OK key, user can enter into satellite setup menu. Here you select the satellite along with LNB No, 22kHz and DiSEqC switch and motor. The Signal quality and strength shown according to the satellite's rst carrier which taken from the database.
  • Page 15 Here you can select the following DiSEqC options, 1. Toneburst 2. DiSEqC 1.0 3. DiSEqC 1.1 4. Motor [DiSEqC 1.2/USALS] If you select DiSEqC type as Motor, RED color key help is displayed in the help banner. By pressing RED key you can get into DiSEqC motor [DiSEqC 1.2/USALS] setup. DiSEqC 1.2 and USALS functionalities are explained in the DiSEqC Motor setup menu.

  • Page 16: Blind Scan

    Blind Scan Blind scan detects all the carriers within the user speci ed start & end frequency range. Blind Scan menu has the following options: • Satellite name • Range of Start & End Frequency • Polarization • Service type. By pressing LEFT or RIGHT arrow key, user can select the satellite from the Satellite list.
  • Page 17 By pressing, LEFT or RIGHT key, you can select the polarization type: • BOTH • Horizontal • Vertical You can lter the service collection based on the below listed service types, • ALL - tune both FTA & Scrambled services. •...
  • Page 18 To perform Transponder Setup, click MENU key, select Transponder Setup option using arrow keys and press OK. The above gure shows Transponder setup option in the main menu. Transponder setup has three types of operations. • Add - Allows the user to add new carrier into the selected satellite with the corresponding frequency, symbol rate and polarization.

  • Page 19: Diseqc Motor Setup

    DiSEqC Motor Setup Through this menu, you can select DiSEqC1.2 or USALS option by toggle the LEFT or RIGHT key. Through this menu, user can perform the DiSEqC 1.2 and USALS Motor related operation. When you change & save the motor settings from DiSEqC 1.2 to USALS or vice versa, STB asks con rmation from user to set that selected motor settings.
  • Page 20 Set the Dish moving type as INSTALLER. Press Left/Right key in Drive East/West option to move the motor. Now motor will be move fast [Continuous movement]. Motor movement will be stop when you press the LEFT/RIGHT key again. GoTo X option is used to move the motor to speci ed Dish position. To perform this option, select Dish moving type as GoTo X and enter the Dish position by pressing numeric keys.
  • Page 21 By pressing OK key, Advanced setup will be invoked. Through this setup you can perform the below listed Motor related settings : • DiSEqC 1.2 Enable/Disable • Enable /Disable limit • Drive East/West • Set EAST/WEST limit • Recalculate Position •...
  • Page 22 You can drive the motor to East/West direction by pressing the Left/Right key. You can set the East or West limit of the motor through this option. Select the "Set East limit" or "Set West limit" option and press OK key to set the East/West limit of the motor. The Recalculate position option will replace the logical positions set by the user.
  • Page 23 The motor position can be reset to its reference position [0°] by using the Reset Position option. Con rmation message will be displayed after pressing OK key. If you select the YES option, "Dish is Moving" message will be displayed. By pressing Left/Right key, Transponder list will be opened to select the transponder.
  • Page 24 You can change the transponder symbol rate value by pressing numeric keys. You can change the polarization of the transponder by pressing Left/Right key. Press OK key, to save the changed settings. Saving con rma- tion banner will be displayed. By selecting YES option changed values will be stored.
  • Page 25 By pressing OK key, USALS setup will be invoked. USALS is used to position the dish automatically without stress. By giving the input of satellite angle, your latitude & longitude angle, motor will be positioned automatically to the selected satellite. You can select the satellite from the satellite list by pressing the LEFT/RIGHT key.
  • Page 26 You can enter the longitude and latitude angle by pressing numeric keys. Also by pressing Left/Right key, you can choose the East/West or North/South direction. You can change the transponder frequency by pressing numeric keys. You can change the transponder symbol rate value by pressing numeric keys.

  • Page 27: Factory Default

    Press OK key, to save the changed settings. Saving con rmation banner will be displayed. By selecting YES option changed values will be stored. After saving the changes, motor will be positioned automatically to the selected satellite. Factory Default Factory Default option aids to restore the Factory setting.

  • Page 28: User Settings

    User Settings The User Settings Menu will allow you to reset all the System Settings (Language, OSD, Time etc) back to the factory defaults without changing any Channel settings. Page 28...

  • Page 29: System Setup Menu

    System Setup Menu System Setup menu consists of system related options like, • Language Setup • OSD Setup • TV Setup • Time Setup • Password setup • Wakeup Timer User can navigate between the options by using UP/DOWN keys and select the option by OK key. The Language option, on toggling shows the various languages supported and on pressing OK key the particular language will be selected.
  • Page 30 The Time Setup menu aids to perform operations like Manual/Auto time setting, GMT o set setting & Summer Time setting. The Timer mode can be either Manual or Auto. In case of Auto the time is collected from the satellite signal. In case of auto, you can set the GMT o set and Summer time.
  • Page 31 Wakeup timer is used to wakeup a service according to the user speci ed date and time. The below listed timer mode are supported 1. Once - Only once the timer will wake up. 2. Daily - As per the user speci ed duration the timer will wake up daily. 3.

  • Page 32: Accessories Menu

    Accessories Menu Accessories Menu has the following options, 1. S/W upgrade, 2. Version, 3. Signal Monitoring. Press the menu key in the remote and select the Setup option. Select the “Software Upgrade” option as shown. Press OK Key on the remote button to start.
  • Page 33 The Signal Level menu helps to check the availability of signal strength & signal quality with options to set several parameters. In the above menu, Signal strength and quality is shown for Default carrier 4000-28000 H. You can select the satellite from the satellite list by pressing LEFT or RIGHT arrow key.
  • Page 34 After doing the factory reset option, this country setup dialog will be invoked. Here you can select the city for installing the carriers. If you select the city, then the con rmation dialog is displayed. Select the YES option and the installation will be started and collect the selected city carriers only.
  • Page 35 This S/W supports EPG (Electronic Programme Guide) for the current, next & weekly informations. EPG displays the programme schedules with short & extended description of the selected service. EPG menu could be invoked by pressing the GUIDE key. EPG of the selected service will be displayed in the EPG menu. EPG menu contains all the current day event information of the programmes.
  • Page 36 Quick Select menu list the services based on the selected satellite and service type. To invoke this menu OK Key should be pressed. In this menu, service list can be viewed based on: • Satellite • Mode - Service Type •...
  • Page 37 Favourite list option allows you to browse the Favourite services quickly. This menu can be invoked by pressing Favourite key. You can group the services under 4 favourite categories supported in this s/w, You can set favourite option for the preferred service in the Channel organizer menu.
  • Page 38 If your television set is not equipped with an integrated Teletext decoder, you can still View the Teletext pages via STB. Select and switch to the channel you would like to view the Teletext information for. Press the TTxt function key to switch on the Teletext.
  • Page 39 Teletext Subtitle: Teletext Subtitle Selection menu, can be invoked by pressing Text key when no dialog is active. • Teletext/TTxT Subtitle - To select Teletext or TTxT Subtitle by Left/Right arrow keys if available in the stream. • Language selection - To select the language for Teletext or TTxT Subtitle if available in the stream.
  • Page 40 If the current service contains an MHEG page and Subtitles are OFF, the MHEG page will be loaded automatically. MHEG will be invoked with the "TEXT" key. If you set the Subtitles ON then the MHEG Page will be loaded after pressing the TEXT key manually.
  • Page 41 This S/W supports ESG (Electronic service Guide) for the Now/Next information. ESG displays the programme schedules with short & extended description of the selected service. Calling up Electronic service Guide ESG menu can be invoked by pressing the INFO key. ESG of the selected service will be displayed in the ESG menu.
  • Page 42 If the "OSD Time" is set as ON in the OSD menu, then the current time will be displayed in the top right part of the screen in the format of hh:mm:ss, when no menu is active. When no menu is active, you can switch or hop to a speci c channel directly by entering the channel index using the numeric keys of the RCU.
  • Page 43 When you presses CH+/CH- keys, in the absence of any other menu channel hopping takes place and then the current channel's quick information is displayed in the Channel Banner. The information includes Channel index, Channel name, Date & Time, Satellite name, Carrier name, Carrier parameters, Multi Audio &...

  • Page 44: Remote Control
