• When a spare battery is placed in the charging bay, it may take a few seconds
before the charging indicator begins to turn on.
• The Desk Mount charging LED indicates the charge condition of the Desk Mount
only. It does not reflect the charging state of the GoBook Tablet PC unit. Charge
status for the GoBook Tablet PC is indicated by the battery status LED on the unit.
This will be orange if charging, and green if fully charged.
• The Desk Mount charging LED is Orange when charging a spare or expansion
battery; when the Green LED is on it indicates the battery is fully charged; and if
the Red LED is on a fault condition exists.
Video Connector
• 15-pin external video connector that allows an external monitor to be attached to
the Desk Mount.
Docking Connector
• Mates with GoBook Tablet PC Port and extends the USB 1.1 ports and 15-pin
external monitor port from the GoBook Tablet PC.
Hot Keys and Screen
• GoBook Tablet PC hot keys and screen are accessible while in the Desk Mount.
Communications
• 2 USB 1.1 ports
• 15-pin external monitor.
Main Power Supply
• A 75W AC/DC power adapter is shipped with the Desk Mount.
Rubber Feet
• Four (4) rubber feet are provided as an option that can be installed on the bottom of
the Desk Mount to prevent the Desk Mount from slipping on, or scratching the user's
work surface.
GoBook Tablet PC Desk Mount Specifications
• Size: (L x W x D): 160mm x 170mm x 88 mm
• Weight: 354 grams (.8 lbs)
• Storage Temperature: -20°C to 60°C (-4°F to 140°F)
• Operating Temperature: 5°C to 50°C (41°F to 122°F)
Docking and Undocking a GoBook Tablet PC in the Desk Mount
1 Ensure the port cover on the extension slot is open and the port cover for the
AC power is closed.
2 Line up the bottom of the unit with the guides and press down while feeding
the rubberized I/O port cover through the opening provided.
3 Insert the computer into the pocket and press down until you hear the snap
engage.
