- Page 1 Ether-GSH8TW v2 8-Port Web Managed Pure Gigabit Switch User’s Manual...
-
Page 2: Declaration Of Conformity
Declaration of Conformity We, Manufacturer/Importer OvisLink Corp. 5F., NO.6, Lane 130, Min-Chuan RD., Hsin-Tien City, Taipei County, Taiwan Declare that the product Ethernet Switch Ether-GSH8TWv2 is in conformity with In accordance with 89/336 EEC-EMC Directive and 1999/5 EC-R & TTE Directive Clause Description EN 55022:1994/A1... - Page 3 Ether-GSH8TWv2 CE Declaration Statement Country Declaration Country Declaration OvisLink Corp. tímto prohlašuje, že tento Ether- Šiuo OvisLink Corp. deklaruoja, kad šis Ether- Česky [Czech] GSH8TWv2 je ve shodě se základními Lietuvių GSH8TWv2 atitinka esminius reikalavimus ir kitas požadavky a dalšími příslušnými ustanoveními [Lithuanian] 1999/5/EB Direktyvos nuostatas.
-
Page 4: Table Of Contents
2.2.5 IGMP S ................................27 TATUS 2.2.5 P ..................................27 2.3 M ................................28 AINTENANCE 2.3.1 W ..............................28 EBOOT 2.3.2 F ..............................28 ACTORY EFAULT 2.3.3 F ..............................29 IRMWARE PDATE 2.3.4 C ................................29 ONFIG 3.0 T ..........................29 ERMINAL ODE MANAGEMENT AriLive Ether-GSH8TW v2 User’s Manual... -
Page 5: Introduction
1.0 Introduction AirLive ETHER-GSH8TW v2 switch is a high performance web-smart switch that provides up to 8 10/100/1000Mbps copper Ethernet ports, this device provides a great flexibility for nowadays variety of network application but at lower cost. User doesn’t have to learn many... -
Page 6: Main Features
Support Multicast storm, Broadcast Storm control as well as Flooding Control Support port mirroring LED display for each port to show link and activity status Desktop and optional Rack mountable kit Reset to default “ push button “ and field code upgradeable AriLive Ether-GSH8TW v2 User’s Manual... -
Page 7: Start To Manage This Switch
After enter command page, Press “ ? “ to find command parameters and format, further more, type “ command ? “ to get explanation. Type “ up “ or “ “ to go back to previous page AriLive Ether-GSH8TW v2 User’s Manual... -
Page 8: Web Management
Maintenance Warm Reboot – to restart system Factory Default – to get parameter value back to factory default Firm Upgrade – to upgrade code Config File – to backup configuration data Logout – to logout AriLive Ether-GSH8TW v2 User’s Manual... -
Page 9: Configurations
255.255.255.0 Subnet Mask 192.168.1.254 Gateway Tag VLAN Management Group Name airlive Password Inactivity Timeout (secs) SNMP enabled 0.0.0.0 SNMP Trap destination public SNMP Read Community private SNMP Write Community public SNMP Trap Community Apply Refresh AriLive Ether-GSH8TW v2 User’s Manual... -
Page 10: Ports
Control enable, then press “Apply”, after execution, diagram will shown below Port Configuration Port Link Status Link Mode Flow Control Auto Speed 100FDX Auto Speed Down Auto Speed Down Auto Speed Down Auto Speed Down Auto Speed Down Auto Speed Down Auto Speed Down AriLive Ether-GSH8TW v2 User’s Manual... -
Page 11: Port-Based Vlan
A default diagram is shown below. Port-based VLAN (User Group) Configuration Port-based VLAN Group (User Group) Table Member Port No. Group ID Add/Edit a VLAN (User) Group Member Port Group ID Refresh Delete Apply AriLive Ether-GSH8TW v2 User’s Manual... - Page 12 ID 2, then press “Apply”, after execution, diagram will shown below Port-based VLAN (User Group) Configuration Port-based VLAN Group (User Group) Table Member Port No. Group ID Add/Edit a VLAN (User) Group Member Port Group ID Refresh Delete Apply AriLive Ether-GSH8TW v2 User’s Manual...
-
Page 13: Tag-Based Vlan
A default diagram is shown below. Tag-based (802.1q) VLAN Configuration Tag-based (802.1q) VLAN Group Table Member Port Select No. VLAN ID Add/Edit a VLAN Group Member Port VLAN ID (1-4094) Port Config Refresh Delete Apply AriLive Ether-GSH8TW v2 User’s Manual... - Page 14 Tag VLAN Per Port Configuration VLAN aware Ingress Filtering Acceptable Port Port VID Enabled Enabled Packet Type Tagged Only Tagged Only Tagged Only Tagged Only Tagged Only Tagged Only Tagged Only Tagged Only Apply Cancel AriLive Ether-GSH8TW v2 User’s Manual...
-
Page 15: Port Trunking
Choose and click the trunk ports you want to group, for example, choose port 1, port 2 into group 1, then press “Apply”, after execution, diagram will shown below Port Trunking (Aggregation) Configuration Group\Port Normal Group 1 Group 2 Group 3 Group 4 Apply Refresh AriLive Ether-GSH8TW v2 User’s Manual... -
Page 16: Port Mirroring
Refresh Choose and click the ports you want to monitor, for example, choose port 2 To be monitored, then press “Apply”, after execution, diagram will shown below Port Mirroring Configuration Mirror Port Port Mirror Source AriLive Ether-GSH8TW v2 User’s Manual... -
Page 17: Quality Of Service
QoS Mode Default Class Table Port Default Class high high high high high high high high Choose the priority level for the port you want to set, then same priority will get same priority service. AriLive Ether-GSH8TW v2 User’s Manual... -
Page 18: Storm Control
Press “Apply”, after execution, diagram will be shown below Storm Control Configuration Storm Control Number of frames per second 3964 Broadcast Rate No Limit Multicast Rate No Limit Flooded Unicast Rate Apply Refresh AriLive Ether-GSH8TW v2 User’s Manual... -
Page 19: Lacp
Choose and click the trunk ports you want to group. For example, select port 7 and port 8 to group into a LACP group with key value 20 for both ports, then press “ Apply” to activate the setting. The following figure is the result: AriLive Ether-GSH8TW v2 User’s Manual... - Page 20 AriLive Ether-GSH8TW v2 User’s Manual...
-
Page 21: Rstp
RSTP Configuration System Configuration 32768 System Priority Hello Time Max Age Forward Delay Normal Force version Port Configuration Port Protocol Enabled Edge Path Cost Aggregations auto auto auto auto auto auto auto auto Apply Refresh AriLive Ether-GSH8TW v2 User’s Manual... - Page 22 Path Cost – A value on a port that switch uses to determine which port are the forwarding ports. The lowest number is forwarding ports. The value can be set from 1 to 200000000 or “auto” to be automatically generated. AriLive Ether-GSH8TW v2 User’s Manual...
-
Page 23: Igmp
IGMP enabled, uses port 5 and 6 as router ports to forward the IGMP frames, forwards unregistered IPMC frames to router ports (port 5 and 6), and enables snooping IGMP and sending querying frames for the VLAN group which VID = 1. AriLive Ether-GSH8TW v2 User’s Manual... - Page 24 Re-authenticate Force Reinitialize Statistics Force Authorized 802.1X Disabled Re-authenticate Force Reinitialize Statistics Force Authorized 802.1X Disabled Re-authenticate Force Reinitialize Statistics Force Authorized 802.1X Disabled Re-authenticate Force Reinitialize Statistics Re-authenticate All Force Reinitialize All Apply Refresh AriLive Ether-GSH8TW v2 User’s Manual...
-
Page 25: Monitoring
Choose and click command manual, after execution, diagram will shown below, user can clear counter or refresh as will Statistics Overview for all ports Port Tx Bytes Tx Frames Rx Bytes Rx Frames Tx Errors Rx Errors 4837 1122 Clear Refresh AriLive Ether-GSH8TW v2 User’s Manual... -
Page 26: Detailed Port Statistic
- Tx 512-1023 Bytes Rx 1024- Bytes - Tx 1024- Bytes Receive Error Counters Transmit Error Counters Rx CRC/Alignment - Tx Collisions Rx Undersize - Tx Drops Rx Oversize - Tx Overflow Rx Fragments Rx Jabber Rx Drops AriLive Ether-GSH8TW v2 User’s Manual... -
Page 27: Lacp Status
Forwarding Port link up and forwarding frames Port link up and forwarding by RSTP. Number is Partner port number if other switch has Forwarding LACP enabled Refresh LACP Port Status Port Protocol Active Partner Port Number Operational Port Key AriLive Ether-GSH8TW v2 User’s Manual... -
Page 28: Rstp Status
Port/Group Vlan Id Path Cost Edge Port P2p Port Protocol Port State Non-STP Port 1 Port 2 Non-STP Non-STP Port 3 Port 4 Non-STP Non-STP Port 5 Port 6 Non-STP Non-STP Port 7 Port 8 Non-STP AriLive Ether-GSH8TW v2 User’s Manual... -
Page 29: Igmp Status
A default diagram is shown below, Ping Function Ping parameters Target IP address Count Time Out (in secs) Apply Ping Results 0.0.0.0 Target IP address Test complete Status Received replies Request timeouts Average Response Time (in ms) Refresh AriLive Ether-GSH8TW v2 User’s Manual... -
Page 30: Maintenance
Are you sure you want to perform a warm reboot? 2.3.2 Factory Default Choose and click command manual, diagram will shown like below, user can press Yes or No Factory Default Are you sure to reset configurations to factory default? AriLive Ether-GSH8TW v2 User’s Manual... -
Page 31: Firmware Update
IP address, subnet mask, …etc, he may do these things through terminal mode. before it starts, user must set up the terminal parameters, such as Hyper terminal in Microsoft Window, AriLive Ether-GSH8TW v2 User’s Manual... - Page 32 After enter command page, Press “ ? “ to find command parameters and format, for example >system System> System>? Commands at System level: System Configuration [all] System Restore Default [keepIP] System Name [<name>] System Reboot AriLive Ether-GSH8TW v2 User’s Manual...
- Page 33 H/W Version: 1.0 MAC address: 00-0a-17-02-10-06 SNMP: enabled Trap IP: 0.0.0.0 Readcommunity: public Writecommunity: private Trapcommunity: public Type “ up “ or “ “ go back to previous page All others command are operated likewise. The end AriLive Ether-GSH8TW v2 User’s Manual...
