Model (8040)
Wood Stove
OWNER'S MANUAL
INSTALLATION
&
OPERATING INSTRUCTIONS
PLEASE READ THIS ENTIRE OWNER'S MANUAL BEFORE YOU INSTALL AND USE YOUR
NEW Tribute WOOD STOVE. To reduce the risk of fire, follow the installation instructions.
Failure to follow these instructions may result in property damage, bodily injury, or even
death.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE!
CONTACT LOCAL AUTHORITIES HAVING JURISDICTION (BUILDING DEPARTMENT or FIRE OFFICIALS)
ABOUT PERMITS REQUIRED, RESTRICTIONS AND INSTALLATION INSPECTION IN YOUR AREA.
Tribute Model # 8040
6400-40447
Revised: 9/29/08
Advertisement
Table of Contents
Troubleshooting
Related Manuals for HearthStone Tribute 8040
Summary of Contents for HearthStone Tribute 8040
-
Page 1: Wood Stove
Tribute Model (8040) Wood Stove OWNER'S MANUAL INSTALLATION & OPERATING INSTRUCTIONS PLEASE READ THIS ENTIRE OWNER’S MANUAL BEFORE YOU INSTALL AND USE YOUR NEW Tribute WOOD STOVE. To reduce the risk of fire, follow the installation instructions. Failure to follow these instructions may result in property damage, bodily injury, or even death. -
Page 2: Table Of Contents
Stone ............................. 19 Gaskets............................19 Glass.............................. 19 TROUBLESHOOTING ......................... 21 ........................22 ROUBLESHOOTING UIDE & O ................23 EPLACEMENT ARTS PTIONAL CCESSORIES SAFETY LABEL ............................ 24 HEARTHSTONE WOODSTOVE LIMITED WARRANTIES............25 Hearthstone Quality Home Heating Products, Inc. ® Tribute Model 8040... -
Page 3: Introducing Your Tribute Wood Stove
2.97 grams per hour particulate you can heat is absorbed by them and lost. be proud to join the Hearthstone family with our Premier Soap Stone Wood Burning Stove. The front door, along with the generous depth allow for loading of wood up to... -
Page 4: Codes
Dispose of ashes properly. (See page 18) Inspect the stovepipe, chimney connector and Keep children and pets away from the stove; they chimney, as recommended. could be burned by touching a hot stove. Hearthstone Quality Home Heating Products, Inc. ® Tribute Model 8040... -
Page 5: Periodic Checklist
DO NOT ATTEMPT TO PUT OUT A STOVEPIPE flue) 8” x 8” (20 x 20cm) (square flue) OR CHIMNEY FIRE BY THROWING WATER ONTO THE STOVE, STOVEPIPE, OR Top exit only Flue Exit: CHIMNEY. THE EXTREMELY HIGH Hearthstone Quality Home Heating Products, Inc. ® Tribute Model 8040... - Page 6 Be careful when loading and cleaning your stove to not break this material. If this piece has been fractured or a hole is punctured, it will cause the stove to function improperly. You must replace the board through a qualified HearthStone dealer. Hearthstone Quality Home Heating Products, Inc. ®...
-
Page 7: Setting Up Your Tribute Wood Stove
Setting Up Your Tribute Wood Stove NPACKING Hearthstone Stoves packages your Tribute stove with the greatest care, so that it ships safely. Under certain circumstances, however, damage can occur during transit and handling. When you receive your stove, unpack it carefully, inspecting your stove and all parts for damage. -
Page 8: Outside Air Supply
According to Intertek Testing Services, Inc. Stove 2" Maximum out of Fireplace - if stove is more than 2" out, refer to alcove clearances. According to ASHRAE Handbook of for availability). Fundamentals 1977 Hearthstone Quality Home Heating Products, Inc. ® Tribute Model 8040... -
Page 9: Clearances To Combustibles
Single wall stove pipe with heat shield 16.5 14.5 16.5 19.5 27.5 11 19.5 22.5 59.75 Double wall pipe w/ optional heat shield 16.5 8 10 13 27.5 7 15.5 18.5 Hearthstone Quality Home Heating Products, Inc. ® Tribute Model 8040... - Page 10 Hearthstone Quality Home Heating Products, Inc. ® Tribute Model 8040...
-
Page 11: Venting Components And Configuration
The chimney connector you periodically inspection the stovepipe connection and stovepipe must be 6" (152 mm) diameter, 24 MSG or chimney. 25 MSG blued steel connector pipe. Do not use Hearthstone Quality Home Heating Products, Inc. ® Tribute Model 8040... -
Page 12: Connecting Your Wood Stove
An exterior chimney does not benefit from the warmth of being surrounded by the Hearthstone Quality Home Heating Products, Inc. ® Tribute Model 8040... - Page 13 Tee Support Bracket Tee clean-out Access door Chimney through outer wall with enclosed chase. One story house installation with attic. Chimney is supported by Tee Support Bracket. Chimney is supported by Ceiling. Hearthstone Quality Home Heating Products, Inc. ® Tribute Model 8040...
- Page 14 This stove requires a minimum chimney height of 13 feet structure (4 m). The maximum allowable chimney height is 30 feet (9m). 2'-0" 2'-0" MINIMUM MINIMUM 3'-0" 3'-0" MINIMUM MINIMUM 10'-0" Hearthstone Quality Home Heating Products, Inc. ® Tribute Model 8040...
-
Page 15: Installing I N A Mobile Home
DO NOT INSTALL IN A SLEEPING ROOM ▌ CAUTION: MAINTAIN THE STRUCTURAL INTEGRITY OF THE MOBILE HOME WALLS, FLOOR, CEILING, AND ROOF WHILE YOUR STOVE IS INSTALLED AND IN USE Hearthstone Quality Home Heating Products, Inc. ® Tribute Model 8040... -
Page 16: Operating Your Tribute Wood Stove
Once your Tribute has been set in place, connected, and HOOSING IREWOOD assembled, you are ready to light a fire. Hearthstone Stoves tests each wood stove before we ship, so you should be able Your Tribute Wood Heater is designed to only burn to easily light your first fire. -
Page 17: Buildinga Fire
We recommend a visual inspection (and cleaning if necessary) of your stovepipe and chimney once the break-in Avoid the following conditions that can cause the soapstone procedure is completed. or cast iron pieces to break: Hearthstone Quality Home Heating Products, Inc. ® Tribute Model 8040... -
Page 18: Normal Operation
Also, reloading on a fuel, and operator error. Correct an over-fire situation as bed of hot, red coals reduces smoking time and will follows: bring fresh fuel up to a high temperature rapidly. Hearthstone Quality Home Heating Products, Inc. ® Tribute Model 8040... -
Page 19: Removal And Disposal Of Ashes
Coals within a bed of ashes can remain hot for several days once removed from the firebox. Hearthstone Quality Home Heating Products, Inc. ® Tribute Model 8040... -
Page 20: Cast Iron
Apply the cleaner to the glass and allow it to finish), on top of your stove. set for a few minutes. By laying the door flat, it will allow Hearthstone Quality Home Heating Products, Inc. ® Tribute Model 8040... - Page 21 7. Screw the glass retainer clips (6) back on the door. D O O R 8. Install the door. Hearthstone Quality Home Heating Products, Inc. ® Tribute Model 8040...
-
Page 22: Troubleshooting
(infiltration) air established. supply to the interior of the house may be inadequate. This Hearthstone Quality Home Heating Products, Inc. ® Tribute Model 8040... -
Page 23: Troubleshooting Guide
Do not over-fire the stove. Monitor stove temperatures. Use ENAMEL CASTING seasoned wood only. Excessive Draft Check the DRAFT. A damper may be required. Operate the stove at a LOW BURN range. Hearthstone Quality Home Heating Products, Inc. ® Tribute Model 8040... -
Page 24: Replacement Parts & Optional Accessories
5210-3070 ROD: 1/4-20X19", 3/4"&3/4" TUC/SAN 5904-015 REAR HEAT SHIELD BRACKET 5210-3080 ROD: 1/4-20X20 1/4", STG/TRI 90-69400 VIEWING SCREEN SPLINE 90-57210 BLOWER: HER1,TRI 90-68400 REAR HEAT SHIELD KIT 90-53400 OUTSIDE AIR SHROUD Hearthstone Quality Home Heating Products, Inc. ® Tribute Model 8040... -
Page 25: Safety Label
U.S. ENVIRONMENTAL PROTECTION AGENCY Certified to comply with July 1, 1990 particulate emissions standards Date of Manufacture 2004 2005 2006 DO NOT REMOVE OR COVER THIS LABEL MADE IN USA 3300-628 Hearthstone Quality Home Heating Products, Inc. ® Tribute Model 8040... -
Page 26: Hearthstone Woodstove Limited Warranties
“Original Purchaser”) the new woodstove manufactured by Hearthstone and purchased by the Original Purchaser (the “Woodstove”) against any of the occurrences listed in this document that result from defects in material or workmanship. All obligations of Hearthstone under this document commence on the date the Original Purchaser purchases the Woodstove (the “Purchase Date”). - Page 27 12. A defect in any part of the Woodstove if the Original Purchaser fails to comply with Hearthstone’s or a Dealer’s request to ship the part or the Woodstove to Hearthstone or a Dealer, as the case may be.
- Page 28 Woodstove is located. In the event the Original Purchaser refuses to allow a Dealer to make a service call, Hearthstone or a Dealer, as the case may be, will request that the Original Owner return the defective part, or the entire Woodstove (if needed), with shipping prepaid, to Hearthstone or a Dealer.
