Draytek Vigor130 User Manual page 92

Index
Name
To set a new profile, please do the steps listed below:
1. Click the number (e.g., #1) under Index column for configuration in details.
2. The configuration page will be shown as follows:
Available settings are explained as follows:
Item
Name
Interface
Available IP Objects
Selected IP Objects
3. After finishing all the settings here, please click OK to save the configuration.
Vigor130 Series User's Guide
Display the profile number that you can configure.
Display the name of the group profile.
Description
Type a name for this profile. Maximum 15 characters are
allowed.
Choose WAN, LAN or Any to display all the available IP
objects with the specified interface.
All the available IP objects with the specified interface
chosen above will be shown in this box.
Click >> button to add the selected IP objects in this box.
84
