Comment
WAN Interface
Aux. WAN IP
Local IP Address
Status
To add or edit port settings, click one index number on the page. The index entry setup page
will pop up. In each index entry, you can specify 10 port ranges for diverse services.
Available settings are explained as follows:
Item
Enable Open Ports
Comment
WAN Interface
WAN IP
Local Computer
Protocol
Specify the name for the defined network service.
Display the WAN interface used by such index.
Display the IP address defined in WAN Alias for
PPPoE/PPPoA or MPoA mode.
Display the private IP address of the local host offering the
service.
Display the state for the corresponding entry. X or V is to
represent the Inactive or Active state.
Description
Check to enable this entry.
Make a name for the defined network application/service.
Specify the WAN interface that will be used for this entry.
Specify the WAN IP address that will be used for this entry.
This setting is available when WAN IP Alias is configured.
Enter the private IP address of the local host or click
Choose PC to select one.
Choose PC - Click this button and, subsequently, a window
having a list of private IP addresses of local hosts will
automatically pop up. Select the appropriate IP address of
the local host in the list.
Specify the transport layer protocol. It could be TCP, UDP,
or ----- (none) for selection.
63 Vigor130 Series User's Guide
