2. The configuration page will be shown as follows:
Available settings are explained as follows:
Item
Name
Interface
Address Type
MAC Address
Vigor130 Series User's Guide
Description
Type a name for this profile. Maximum 15 characters are
allowed.
Choose a proper interface.
For example, the Direction setting in Edit Filter Rule will
ask you specify IP or IP range for WAN or LAN or any IP
address. If you choose LAN as the Interface here, and
choose LAN as the direction setting in Edit Filter Rule,
then all the IP addresses specified with LAN interface will
be opened for you to choose in Edit Filter Rule page.
Determine the address type for the IP address.
Select Single Address if this object contains one IP address
only.
Select Range Address if this object contains several IPs
within a range.
Select Subnet Address if this object contains one subnet
for IP address.
Select Any Address if this object contains any IP address.
Select Mac Address if this object contains Mac address.
Type the MAC address of the network card which will be
controlled.
