Draytek Vigor130 User Manual page 17

Item
Default Gateway
Primary DNS
Second DNS
4. After finished the above settings, click Next to access into next page.
Available parameters are listed below:
Item
User Name
Password
Confirm Password
Description
MPoA/Static or Dynamic IP.
Assign an IP address to the gateway for the protocol of
MPoA/Static or Dynamic IP.
Assign an IP address to the primary DNS.
Assign an IP address to the secondary DNS.
Description
Assign a specific valid user name provided by the ISP. It
will be used to access Internet.
Assign a valid password provided by the ISP. It will be
used to access Internet.
Retype the password.
9 Vigor130 Series User's Guide
