Summary of Contents for Pico Macom PFAP550MS
- Page 1 PFAP550MS 550MHz Sub-Band Extended Agile Signal Processor Installation and Operation Manual Operation Ph:800-421-6511 www.picomacom.com Manual Rev. 05/03...
-
Page 2: Product Inspection
To insure proper installation and operation, take a moment to read this guide before proceeding with the installation. If you have any questions or comments about the PFAP550MS digital signal processor, please contact your dealer or have him contact the PICO MACOM Service Center at these phone numbers: 800-421-6511, 818-493-4300. - Page 3 Safeguards PFAP550MS 11. Power Sources: This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supplied to your home, consult your appliance dealer or local power company.
- Page 4 SAW filtered for superior adjacent channel performance enables drop-in channel expansion of FCC Docket 21006. Pico Macom backs up this product with its industry leading 5-year limited warranty. IRC and HRC input and output offset available...
-
Page 5: Specifications
Specifications PFAP550MS 550MHz Sub-Band Extended Agile Signal Processor PFAP550MS 806MHz Sub-Band Extended Agile Signal Processor IN/OUT STORE CH. MODE CHANNEL OUTPUT ADJUST TEST POINT POWER -30 dB AURAL ADJUST Front View STAND BY 250 V 600W MAX AC117V 60Hz/38W 0.5A... -
Page 6: Operation And Controls
Operation and Controls PFAP550MS PFAP550MS 806MHz Sub-Band Extended Agile Signal Processor IN/OUT STORE CH. MODE CHANNEL OUTPUT ADJUST TEST POINT POWER AURAL -30 dB ADJUST 125V STAND BY 117 VAC 0.5A 60 Hz 35 W 600W MAX RF OUT IF IN... -
Page 7: Installation Procedure
MOUNTING: Install chassis in equipment rack (equipment rack sold sepa- fiers. Three methods are suggested to combine strip amplifier, modulator rately) by supporting the bottom and rear of PFAP550MS at the desired and processor outputs. elevation in rack. Line up the side holes of chassis with the tapped equip- A) The PHC-12G twelve channel and PHC-24G twenty-four channel com- ment rack holes. -
Page 8: Limited Warranty
List Price of the loaner unit plus shipping costs. When you receive the loaner unit, pack the failed unit in the loaner unit’s box and ship it freight prepaid to Pico Macom for repair. When you receive the repaired unit, a new RMA number will be provided in the box. Carefully pack the loaner unit and affix the new RMA number on the box and ship it back to us for full credit excluding shipping costs.
