Pico Macom C860 Specifications

Broadband 5-1000 MHz
Broadcast quality specifications for
unparalleled picture quality
Sub-band output port provides high isolation
VHF/UHF ingress-free return path for CMTS
and remote audio/video application
>18 dB return loss provides reduced
reflections for exceptional digital
signal performance
Directional coupler design provides
improved carrier-to-noise, system
performance and picture quality
High -50 dB port to port isolation provides
spurious carrier rejection and minimizes
undesired channel interaction, thereby
reducing picture distortion
Passive design allows bi-directional
flexibility for two-way digital and
analog requirements
Plug-in equalizers and attenuators
(included) enable uniform gain and slope
system balancing for minimum distortion
-20 dB test port provides convenient
access for headend testing and
system monitoring
8
The MACOM C860 is a professional re-broadcast grade, rack-mounted, high isolation, passive headend signal combiner
available in a 24-channel configuration. This unit combines the outputs from multiple modulators and processors into a single
common broadband output. The high quality directional coupler design enables high isolation between input ports, providing
minimum interaction between digital and/or analog input sources. Plug-in equalizers and attenuators provide system balancing
capability and a high isolation sub-band output port for return path applications further enhance the versatility of this combiner. The
C860 combiner makes it ideally suited for bi-directional applications, such as cable modems, remote audio/video origination or
other applications where remote signal origination is returned to the headend. The MACOM line is backed by an industry lead-
ing 5-year limited warranty.
C860
Bi-Directional Combiner
