Pico Macom SSP-10/2150A Specifications

Headend & Electronics
Distribution system compactly
combines LNB powering, signal
separation, and amplification in a
single rack space
Fully-conditioned power source
eliminates power drawn from
receiver, reducing heat buildup and
increasing product life
Dual independent 1000mA high-
capacity supplies have ample
power reserve to reliably feed
multiple line amplifiers
5 amplified outputs per polarity
provide for multiple receiver
flexibility
Single polarity configuration pro-
vides 9 outputs for maximum
receiver operation
Front panel LED's provide quick
and easy LNB open-or-short status
monitoring
Automatic current sensing enables
short circuit shutdown protection
to safeguard from potential dam-
age while servicing LNBs
Plug-in external UL approved
power adapter supplied for ease of
installation and to reduce heat
build-up within the unit
www.picomacom.com
SSP10/2150A
Satellite Power-Conditioned Distribution System
SSP10/2150A
Satellite Power-Conditioned Distribution System
Pico Macom's SSP10/2150A is an L-band satellite power-conditioned distribu-
tion system, compactly combining multiple functions into a single rack unit.
The unit powers two satellite LNB polarities in the 950-2150 MHz range, ampli-
fies and splits the signals for distribution to multiple satellite receivers. Two
high capacity 1000mA power supplies provide enough power for each LNB
polarity and several line amplifiers, reducing wear-and-tear on commercial
receivers. Front panel current-sensing indicators warn of system faults and
allow quick system status. Pico Macom backs up this product with its industry
leading 5-year limited warranty.
PICO MACOM, INC.
355 Parkside Drive San Fernando, CA 91340
Ph: 818-493-4300 Toll Free: 800-421-6511 Fax: 818-493-4433
355 A-69
Parkside
Rev. 12/02
