Pin Alternate Output Harness - Code Alarm ca 4552 Installation Manual

5 RED/WHITE
Locate 1 of the vehicle's constant 12 Volt battery wires at the ignition switch.
Verification: This wire will register ( + ) voltage in all positions of the ignition
switch.
Connect the RED/WHITE wire to the constant 12 Volt battery wire.
NOTE: Remove all fuses until all connections are made.
6 PINK
Locate the vehicle's ignition wire at the ignition switch.
Verification: This wire registers voltage when the key is turned to the ON (or
RUN) position. The voltage does not drop out when the key is turned to the
START (or CRANK) position.
Connect the PINK wire to the vehicle's Ignition wire.
This wire is also used for Ignition 1 Output.

4 Pin Alternate Output Harness

1 LT GREEN/BLACK
This wire will supply a ( - ) 500mA pulse both upon disarming the system and when
the remote start feature is activated. Locate the factory perimeter alarm disarm
wire from the key cylinder inside the drivers door.
Verification: This wire registers ground if the key is turned to the unlock
position in the driver's door cylinder.
This output is configurable in option programming.
2 LT BLUE
This wire will supply a ( - ) 500mA pulse upon successful completion of the remote
start activation sequence and is typically used to re-lock the vehicle's doors upon
remote start if necessary.
This output is configurable in option programming.
ca4552. 2011 Audiovox Electronics Corporation. All rights reserved.
BATTERY 12V ( + )
IGNITION 1 ( + )
FACTORY DISARM /
PULSE BEFORE START ( - )
FACTORY ARM /
PULSE AFTER START ( - )
9
