- Page 1 Owner’s Manual Ceiling Fan Installation Instructions For 5ED56WAD-L Series Fans READ AND SAVE THESE INSTRUCTIONS Total fan weight wirh light kit...
-
Page 2: Installation
Installation AFETY WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70- 1999), including fire-rated construction. - Page 3 Insert downrod into yoke on top of fan body. Align the hole in the down- Check the fan motor for shipping sta- Tighen set screws and nuts to secure rod with hole in the yoke. Insert pin downrod in yoke. bilizer and remove if present.
- Page 4 Push plug from fan and plug from Put plug from fan through hole in Install switch plate by placing over switch plate together. switch plate. the 2 screws and twisting into place. Install screw removed and tighten all 3 screws securely. Place light kit over screws and twist Loosen 3 screw on light plate as Plug white wire from fan to white...
-
Page 5: Troubleshooting
Trouble Shooting If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet.
