Summary of Contents for Monte Carlo Fan Company 5EG60XX Series
- Page 1 Owner’s Manual Ceiling Fan Installation Instructions Total fan weight For 5EG60XX Series Fans READ AND SAVE THESE INSTRUCTIONS Quality Ceiling fans...
-
Page 2: Tools Required
WARNING – Risk of fire, electric shock, or personal injury, The fan in this box may be either directly supported from a structural framing member of a building and/or may be mounted to an outlet box marked acceptable for fan support of 31.8 kg. (70 lbs.) or less. Most outlet boxes . Attach the mounting bracket using only the hardware supplied with the outlet box. - Page 3 White White Green Ground Connect black and blue wire from fan to Black or (Hot) wire from house. Connect White wire from Fan to White (Neutral) wire from house. Connect Ground leads from mounting bracket and downrod to Ground lead from house. Refer to Safety Tips section of manual.
- Page 4 Install switch cap by reinstalling the 4 screws removed. Remove twin adhesive tape from the black capacitor as shown above. There is a manual reverse switch located on on the switch cap installed in step 23. Fan must be off to reverse.
- Page 5 If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart.
