- Page 1 Owner’s Manual Ceiling Fan Installation Instructions For 5EPR60BRD Series Fans READ AND SAVE THESE INSTRUCTIONS Total fan weigh with light...
-
Page 2: Installation
WARNING – Risk of fire, electric shock, or personal injury, The fan in this box may be either directly supported from a structural framing member of a building and/or may be mounted to an outlet box marked acceptable for fan support of 31.8 kg. (70 lbs.) or less. Most outlet boxes commonly used for the support of luminaires may not be acceptable for fan support and may need to be replaced. - Page 3 Thread leadwires and safety cable through downrod. Install yoke cover over downrod onto fan body. Secure mounting neck to the mounting plate with four screws to become a complete mount- ing bracket. Loosen set screw that holds ball.
- Page 4 . If you have more than one fan with remote. You can set the dip switches to different positiosns to have seperate control. Install remote receiver by sliding into opening in the Mounting bracket.
- Page 5 Plug white wire from fan to white wire from light kit. Then plug black wire from fan to black wire from light kit. Install glass onto light kit, install rubber washer and hex nut to hold in place and tighten in direction of arrow.
-
Page 6: Fan Speed
The light will cycle from bright to dim to bright until button is released. Light will FORWARD/REVERSE change rotation direction with fan running. MEDIUM SPEED high. To turn fan off press square”. maintain last setting if turned off. Depress rev button allow a few seconds for remote to FAN REVERSE... -
Page 7: Troubleshooting
If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet. - Page 8 6/21/06 REV.0 New made from 5GMR manual...
