Citizen C32612HD User Manual

Citizen C32612HD User Manual

32" high definition lcd television
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
C32612HD
32" High Definition
HDMI™ (High Definition Multimedia Interface)
8ms Response Time
VGA Input
www.citizen-electronics.com
USER MANUAL
LCD Television
*
*Requires HD Signal
For Custom
1-800-66

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C32612HD and is the answer not in the manual?

Questions and answers

Related Manuals for Citizen C32612HD

Summary of Contents for Citizen C32612HD

  • Page 1 For Custom 1-800-66 USER MANUAL C32612HD 32” High Definition LCD Television HDMI™ (High Definition Multimedia Interface) 8ms Response Time VGA Input *Requires HD Signal www.citizen-electronics.com...

  • Page 2: Table Of Contents

    CONTENTS 2. Descriptions of Main Unit and Remote-Control Unit ....... . . 5 2.1.
  • Page 3 1. Safety Warnings and Cautions Warning High voltages are used in the operation of this product. Do not remove the cabinet back from your set. Refer servicing to a qualified service technician. Warning To prevent fire or risk of electric shock, do not expose the main unit to rain or moisture.
  • Page 4 Minimum Caution If the television is to be built into a compartment or enclosure, the minimum distances must be maintained to allow for proper ventilation. Heat build-up can reduce the service life of your television, and can also be dangerous. Caution Never stand on, lean on, or push the product or its stand.
  • Page 5 Caution When the product is not used for an extended period of time, it is advisable to disconnect the AC power cord from Caution Avoid exposing the main unit to direct sunlight or other source of the heat. Do not stand the television receiver directly on other products which give off heat, E.g.

  • Page 6: Descriptions Of Main Unit And Remote-Control Unit

    2. Descriptions of Main Unit and Remote-Control Unit 2.1 Main Unit Buttons / Display: Sockets / Main Power Switch:...

  • Page 7: Remote-Control Unit

    2.2 Remote-Control Unit...

  • Page 8: Specifications

    3. Specifications Items Relevant illustrations Active Screen Size 32 inches Screen format 16:9 Number of Pixels 1366×768 Typical Contrast Ratio 1000:1 Maximum Brightness 500 cd/m² Display colors 16.7M Wide Viewing Angle 170° (Horizontal) 170° (Vertical) Parameters Standard FCC etc. of the Accessories Remote-Control Unit, AC cord, User product...

  • Page 10: Connection And Preparation

    4. Connection and Preparation 4.1 Connecting Antenna or Video Facility 1. Use a 75Ω coaxial cable or 300-75Ω impedance converter (sold separately) to plug in the antenna input terminal on the rear of the cabinet. 2. Connect the video or audio facility with the video, audio interface on the rear of the cabinet.

  • Page 11: Auto Search The Channels

    4.4 Auto Search the Channels 1. Press the Power On/Off key on the television or the Remote-Control. 2. Press the MENU key on the remote-control unit. The screen displays the Menu OSD. Press the key repeatedly till “TV-CHANNEL” is highlighted in the first main menu.

  • Page 12: Tv/Av

    5.3 TV/AV Press once to display Source List. Using ▲ and ▼ select the video input from TV, AV, SVIDEO, SVIDEO YPBPR YPBPR, YPBPR2, HDMI, and PC. The OSD YPBPR2 display will disappear after several seconds, or HDMI by pressing TV/AV. 5.4 Channel Up/Down Press CH▲...

  • Page 13: Scan

    5.7 QV Pressing this will quickly switched back to the previous channel viewed. 5.8 SCAN Pressing this button will automatically scan through the channels. Pressing this button again will stop scan. 5.9 ZOOM Press this key repeatedly to change aspect radio as follows.

  • Page 14: Picture Mode

    5.12 OK The OK key is used to confirm your selection in the menu， and let you quickly enter the result. 5.13 Picture Mode Press repeatedly to select the picture mode among STANDARD, DYNAMIC, SOFT, and PERSONAL. STANDARD →DYNAMIC →SOFT→ PERSONAL 5.14 Sound Mode Press repeatedly to select audio mode among STANDARD, NEWS, MUSIC, and PERSONAL.

  • Page 15: Call

    5.16 CALL Pressing displays (1) the name of current the program or source; (2) Current aspect ratio; (3) Current mts mode; (4) Current picture mode; (5) Current sleep time. 5.17 FREEZE Press to hold the current state or image. Pressing again releases back to normal state.

  • Page 16: Menu Operation And Function Descriptions

    7. MENU OPERATION AND FUNCTION DESCRIPTIONS: 7.1. Menu operation under TV, AV, SVIDEO, YPBPR. 7.1.1 PICTURE MENU： a. The above image is a sample of the display menu. b. The definition of each option: b.1 PICTURE MODE: Set the picture preset to STANDARD→DYNAMIC→SOFT→PERSONAL→STANDARD by using keys.

  • Page 17: Sound Menu

    b.6 SHARPNESS: Change the value of the sharpness with the keys, in the range of 0 to 100. b.7 COLOR TONE: Set the color temperature preset to STANDARD→WARM→COOL→STANDARD by using the keys. b.8 SCALE: Set the picture size preset to FULL→ZOOM → 4：3 → PANORAMA→FULL by using the keys.

  • Page 18: Function Menu

    b.3 TREBLE: Change the value of the treble with the keys in the rang of 0 to 100. b.4 BALANCE: Change the value of the balance with the keys from -50 to 50. Recommended setting is 0. b.5 MTS: Set the modes of sound processing with the keys to MONO→STEREO→SAP.
  • Page 19 b.4 VCHIP: Press the key to enter the password input menu, now enter your password to enter V-CHIP mode. V-CHIP has two American standards (MPAA Rating/ TV Parental Guidelines) and two Canadian standards (English Rating/ French Rating). b.4.1 CHANGE PASSWORD: Press the keys to enter the password change menu.
  • Page 20 b.4.4 MOVIE RATING: Press the keys to adjust the movie rating to NONE PG13 NC17 X NONE. General Audiences Parental Guidelines Suggested PG－13 Parents Strongly Cautioned Restricted NC－17 No 17 And Under Admitted b.4.5 ENGLISH: Press the keys to adjust the English rating to 18+.

  • Page 21: System Menu

    7.1.4. SYSTEM MENU： SYSTEM MENU a. The above image is a sample of the display menu. b. The definition of each option: b.1 OSD LANGUAGE: Change the language to ENGLISH→FRENCH→PORTUGUESE→SPANISH→ENGLISH by using the keys. b.2 BLUE SCREEN: When set to ON，the blue screen indicated there is no signal to the current input channel.

  • Page 22: Channel Menu

    b.7 OSD HALFTONE：Change the transparence of the OSD (it has 9 grades) by using the keys. 7.1.5. CHANNEL MENU： Only displayed when current source is TV. CHANNEL MENU a. The above image is a sample of the display menu. b. The definition of each option: b.1 AUTO SCAN: Press the key to auto scan the channels and display the auto scan sub menu.

  • Page 23: Menu Under The Source Of Vga

    7.2. MENU UNDER THE SOURCE OF VGA： 1. When the system signal source switches to VGA，there will be a PC mark in the up-right corner of the screen. 2. In VGA Input Mode，if there is no signal，it will display NO SYNC in the middle of the screen.

  • Page 24: Trouble Shooting

    8. Trouble Shooting： Before arranging for service, first know the status and then check simply as follows: Problems Check No picture. Check if the power supply is plugged in. Picture is fine, but no Check if the volume control is set to the minimum or audio.
