JCTV2110
21" SUPER FLAT STEREO TV
Operating Manual
Please save these instructions
Read these instructions carefully before
using your television. If you follow the
instructions, your television will provide
you with many years of good service.
THE TOLL FREE CITIZEN HELPLINE IS 1-800-663-5954
CALL US IF YOU HAVE ANY PROBLEMS OR QUESTIONS
9am - 5pm (TORONTO TIME) MONDAY TO FRIDAY
®
WITH YOUR NEW
CITIZEN ELECTRONICS
TORONTO CANADA
SETTINGS AND ADJUST
CITIZEN
PRODUCT
INTRODUCTION
CONNECTIONS
MENU OVERVIEW
BASIC TV OPERATION
MENTS
TROUBLESHOOTING
SPECIFICATIONS
PACKING LIST
6
TION
10
IONS
12
IEW
14
TION
17
31
TING
IONS
33
LIST
Advertisement
Table of Contents
Related Manuals for Citizen JCTV2110
Summary of Contents for Citizen JCTV2110
- Page 1 TROUBLESHOOTING TING SPECIFICATIONS IONS PACKING LIST LIST THE TOLL FREE CITIZEN HELPLINE IS 1-800-663-5954 CALL US IF YOU HAVE ANY PROBLEMS OR QUESTIONS WITH YOUR NEW CITIZEN PRODUCT 9am - 5pm (TORONTO TIME) MONDAY TO FRIDAY CITIZEN ELECTRONICS...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION: Read all of these instructions. Save these instructions for later use. Follow all warnings and instructions marked on the audio equipment. CAUTION: Use of controls, adjustments or procedures other than those specified herein may result in hazardous radiation exposure. - Page 3 PROTECTION AND LOCATION OF YOUR SET • Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, etc.. • Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall outlet and refer servicing to qualified service personnel.
- Page 4 OPERATION OF YOUR SET This television set should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply at your home, consult your television dealer or local power company. For television sets designed to operate from battery power, refer to the operating instructions.
-
Page 5: Table Of Contents
TABLE OF CONTENTS INTRODUCTION 1.1 FEATURES ............................1.2 DESCRIPTION OF CONTROLS & CONNECTORS ......... 1.2.1 FRONT PANEL ......................... 1.2.2 SIDE/REAR AV TERMINAL ................... 1.2.3 REMOTE CONTROL ....................1.3 REMOTE CONTROL OPERATION ................1.3.1 INSTALLING BATTERIES ..................1.3.2 EFFECTIVELY USING THE REMOTE CONTROL ....... - Page 6 SETTINGS AND ADJUSTMENTS 5.1 AUTO MEMORY .......................... 5.2 MANUAL TUNE ........................... 5.3 FINE TUNE ............................. 5.4 TV/CATV SELECTION ......................5.5 ADD/ERASE FUNCTION ..................... 5.6 PICTURE ADJUSTMENT ....................5.7 BLUE BACK ..........................CHANNEL LOCK........................TIMER ..............................5.9.1 ON TIMER ........................... 5.9.2 OFF TIMER ........................
-
Page 7: Features
JCTV2110 INTRODUCTION 1. INTRODUCTION 1.1 FEATURES TINTED BRIGHT BLACK PICTURE TUBE Dynamically boosts the black level in the dark areas of the picture according to picture content. Increases shadow detail without compromising overall picture contrast. S-VIDEO S-Video connections transmit the black & white and colour portions of the video signal on 2 individual sets of wires within a single cable. -
Page 8: Description Of Controls & Connectors
JCTV2110 1.2/1.2.1/1.2.2 INTRODUCTION 1.2 DESCRIPTION OF CONTROL KEYS & CONNECTORS 1.2.1 FRONT PANEL 1. POWER BUTTON VOLUME/PICTURE CONTROL ( / ) BUTTONS To turn ON/OFF the TV set. To decrease/increase the sound volume and the 2. STANDBY INDICATOR picture setting level. -
Page 9: Remote Control
JCTV2110 1.2.3 INTRODUCTION 1.2.3 REMOTE CONTROL Description of Remote Control Keys. DISPLAY BUTTON Press to display the current program number, colour system. SLEEP BUTTON Set the sleep timer from 120 to 10 minutes by pressing the SLEEP button repeatedly. STANDBY... -
Page 10: Remote Control Operation
JCTV2110 1.3/1.3.1/1.3.2 INTRODUCTION 1.3 REMOTE CONTROL OPERATION 1.3.1 INSTALLING BATTERIES NOTES: The lifetime of the batteries may last up to one year, depending on how often the remote control is used. For the best performance, the batteries should be replaced on a yearly basis, or when remote operation becomes erratic. -
Page 11: Installation Of Antenna
JCTV2110 2.1/2.2 CONNECTIONS 2. CONNECTIONS 2.1 INSTALLATION OF ANTENNA VHF TV ANTENNA UHF TV ANTENNA TO TV ANTENNA JACK COAXIAL CABLE ADAPTOR 300 FLAT CABLE Connect the 75 coaxial cable from the antenna to the antenna jack on the rear panel, as shown above. -
Page 12: External Connection
JCTV2110 CONNECTIONS 2.3 EXTERNAL CONNECTION REAR AV SIDE AV IN AV IN AV OUT VCR/AV RECEIVER/DVD xxxxxxxxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx |||||||||||||||||||| xxxxxxxx xxxxxxxx xxxxxxxxxxxx The AUDIO/VIDEO input terminals on the front panel (if provided) and rear terminals can be VIDEO1... -
Page 13: Menu Overview
JCTV2110 MENU OVERVIEW 3. MENU OVERVIEW Within the on screen menu, almost all of the functions and adjustments for this television can be achieved. The MENU button is used to access the main menu or go back to the previous screen. -
Page 14: Map Of The Parental Control Menu
JCTV2110 MENU OVERVIEW MAP OF THE PARENTAL CONTROL MENU THE THIRD THE FOURTH THE FIFTH STEP MENU STEP MENU STEP MENU ENTER SECRET CODE: _ _ _ _ PG-13 MPAA RATING NC-17 NONE TV-Y TV-Y7 TV PARENTAL GUIDELINES TV-G TV-PG... -
Page 15: Basic Tv Operation
JCTV2110 4.1/4.2/4.3/4.4/4.4.1/4.4.2 BASIC TV OPERATION 4. BASIC TV OPERATION 4.1 TURN ON THE TV Make sure you plug the AC cord into an AC outlet and connect the equipment correctly. POWER Press the POWER button once on the main unit to turn on the TV (normal watching TV). If the TV set is in standby mode, the STANDBY indicator lights up. -
Page 16: Volume Adjustment
JCTV2110 BASIC TV OPERATION 4.5/4.6/4.7 4.5 VOLUME ADJUSTMENT Press VOLUME DOWN/UP button on the main unit or remote handset to increase or decrease volume. When the TV is set to MUTE, press VOLUME UP button, the volume will increase from the former setting, and the mute function is dismissed; press VOLUME... -
Page 17: Status Display
JCTV2110 4.8/4.9 BASIC TV OPERATION 4.8 STATUS DISPLAY To display the current program number, colour system. TV 18 AUTO status information on the screen. DISPLAY 4.9 SLEEP TIMER SLEEP SLEEP SLEEP : OFF SLEEP : 120 MIN. SLEEP : 110 MIN. -
Page 18: Auto Memory
JCTV2110 SETTINGS AND ADJUSTMENTS 5.1/5.2 5. SETTING AND ADJUSTMENT 5.1 AUTO MEMORY PIC. TUN. PIC. TUN. COLOR CHANNEL BRIGHTNESS TV/CATV CONTRAST ADD/ERASE (X2) SHARPNESS MANUAL TINT FINE BLUE BACK AUTO MEMORY DISPLAY MAIN MENU SELECT TUNE MENU SELECT AUTO MEMORY PIC. -
Page 19: Fine Tune
JCTV2110 5.3/5.4 SETTINGS AND ADJUSTMENTS 5.3 FINE TUNE PIC. SET TUN. PIC. SET TUN. PIC. SET TUN. COLOR CHANNEL CHANNEL TV/CATV BRIGHTNESS TV/CATV ADD/ERASE CONTRAST ADD/ERASE (X2) SHARPNESS MANUAL MANUAL TINT FINE FINE ENTER TUNE MENU DISPLAY MAIN MENU SELECT TUNE MENU... -
Page 20: Add/Erase Function
JCTV2110 SETTINGS AND ADJUSTMENTS 5.5/5.6 5.5 ADD/ERASE FUNCTION This television is equipped with a channel memory feature which allows channels to be skipped to or over. The wanted and unwanted channels must be programmed into the television s memory. To do this, follow the direction below. -
Page 21: Blue Back
JCTV2110 5.7/5.8 SETTINGS AND ADJUSTMENTS 5.7 BLUE BACK If you choose BLUE BACK ON, the screen will become blue when no signal is received. PIC. SET TUN. PIC. TUN. COLOR COLOR BRIGHTNESS BRIGHTNESS CONTRAST CONTRAST SHARPNESS SHARPNESS TINT TINT BLUE BACK... -
Page 22: Timer
JCTV2110 SETTINGS AND ADJUSTMENTS 5.9/5.9.1 5.9 TIMER 5.9.1 ON TIMER PIC. TUN. PIC. TUN. PIC. TUN. COLOR CLOSED CAPTION CLOSED CAPTION BRIGHTNESS PARENTAL CONTROL PARENTAL CONTROL CONTRAST TIMER TIMER SHARPNESS LANGUAGE LANGUAGE TINT CHILD LOCK CHILD LOCK BLUE BACK DISPLAY MAIN MENU... -
Page 23: Off Timer
JCTV2110 5.11.2/5.11.3 SETTINGS AND ADJUSTMENTS 5.9.2 OFF TIMER PIC. TUN. PIC. TUN. PIC. TUN. COLOR CLOSED CAPTION CLOSED CAPTION BRIGHTNESS PARENTAL CONTROL PARENTAL CONTROL CONTRAST TIMER TIMER SHARPNESS LANGUAGE LANGUAGE TINT CHILD LOCK CHILD LOCK BLUE BACK DISPLAY MAIN MENU... -
Page 24: Language
JCTV2110 SETTINGS AND ADJUSTMENTS 5.10/5.11 5.10 LANGUAGE PIC. TUN. PIC. TUN. LANGUAGE CLOSED CAPTION CLOSED CAPTION ENGLISH PARENTAL CONTROL PARENTAL CONTROL FRANCAIS TIMER TIMER PORTUGUES ESPANOL LANGUAGE LANGUAGE ENTER SET SELECT LANGUAGE ENTER LANGUAGE CHILD LOCK CHILD LOCK MENU ENTRY... -
Page 25: Closed Caption
JCTV2110 5.12/5.12.1/5.12.2/5.12.3 SETTINGS AND ADJUSTMENTS 5.12 CLOSED CAPTION You may view labeled (cc)TV programs, movies, news, prerecorded tapes, etc. with either a dialogue caption or text display added to the program. 5.12.1 CAPTION MODE Characters can be displayed on the TV screen when the received broadcast signal contains the caption signals. -
Page 26: Parental Control Set Up
JCTV2110 SETTINGS AND ADJUSTMENTS 5.13/5.13.1 5.13 PARENTAL CONTROL SET UP PARENTAL CONTROL enables parents to prevent their children from watching inappropriate material on TV. PARENTAL CONTRO L reads the ratings for programming(except for news, sports programs, unedited movies on premium cable channels and emergency broadcast system signals), then denies access to programming if the programs rating meets the limitations you select. -
Page 27: Mpaa Rating Set Up
JCTV2110 5.13.2 SETTINGS AND ADJUSTMENTS 5.13.2 MPAA RATING SET UP PIC. TUN. PIC. TUN. PIC. SET TUN. CLOSED CAPTION COLOR CLOSED CAPTION PARENTAL CONTROL BRIGHTNESS PARENTAL CONTROL TIMER CONTRAST TIMER LANGUAGE SHARPNESS (X2) LANGUAGE TINT CHILD LOCK CHILD LOCK BLUE BACK... -
Page 28: Tv Rating Set Up
JCTV2110 SETTINGS AND ADJUSTMENTS 5.13.3 5.13.3 TV RATING SET UP PIC. TUN. PIC. TUN. PIC. TUN. CLOSED CAPTION CLOSED CAPTION COLOR BRIGHTNESS PARENTAL CONTROL PARENTAL CONTROL CONTRAST (X2) TIMER TIMER SHARPNESS LANGUAGE LANGUAGE TINT CHILD LOCK CHILD LOCK ENTER SET... -
Page 29: Parental Guidance
JCTV2110 5.13.4 SETTINGS AND ADJUSTMENTS 5.13.4 CANADIAN ENGLISH LANGUAGE RATING SET UP PIC. TUN. PIC. SET TUN. PIC. TUN. CLOSED CAPTION COLOR CLOSED CAPTION PARENTAL CONTROL BRIGHTNESS PARENTAL CONTROL TIMER CONTRAST TIMER LANGUAGE (X2) SHARPNESS LANGUAGE TINT CHILD LOCK CHILD LOCK... -
Page 30: Canadian French Language Rating Set Up
JCTV2110 SETTINGS AND ADJUSTMENTS 5.13.5 5.13.5 CANADIAN FRENCH LANGUAGE RATING SET UP PIC. TUN. PIC. SET TUN. PIC. TUN. CLOSED CAPTION COLOR CLOSED CAPTION PARENTAL CONTROL BRIGHTNESS PARENTAL CONTROL TIMER CONTRAST TIMER (X2) LANGUAGE SHARPNESS LANGUAGE TINT CHILD LOCK CHILD LOCK... -
Page 31: Make Parental Control Active
JCTV2110 5.13.6 SETTINGS AND ADJUSTMENTS 5.13.6 MAKE PARENTAL CONTROL ACTIVE PIC. TUN. PIC. TUN. PIC. SET TUN. CLOSED CAPTION COLOR CLOSED CAPTION PARENTAL CONTROL BRIGHTNESS PARENTAL CONTROL TIMER CONTRAST TIMER (X2) LANGUAGE SHARPNESS LANGUAGE TINT CHILD LOCK CHILD LOCK BLUE BACK... -
Page 32: Troubleshooting
JCTV2110 TROUBLESHOOTING TROUBLESHOOTING 6.1 PICTURE PROBLEMS The most common types of picture problems are as follows: IGNITION Black spots or horizontal streaks appear, or the picture flutters or drifts. This is usually caused by interference from car ignition system, neon lamps, electric drills, or other electrical appliances. -
Page 33: Operation Problems
JCTV2110 TROUBLESHOOTING 6.2 OPERATION PROBLEMS If this unit does not seem to operate properly, check the POSSIBLE CAUSES below. SYMPTOM POSSIBLE CAUSES NO POWER • The power cord is not connected. • The POWER BUTTON on the main unit is off. -
Page 34: Specifications/Packing List
JCTV2110 SPECIFICATIONS/PACKING LIST 7.1/7.2 7.1 SPECIFICATIONS TELEVISION SYSTEM : NTSC-M TV STANDARD : NTSC 3.58 CLOSED CAPTION SYSTEM 15.119/FCC CHANNEL COVERAGE : : 2-13 : 14-69 CATV : 2-13, A-W, W+1~W+84, A-5~A-1, 5A TUNING SYSTEM : 181 CHANNEL FREQUENCY SYNTHESIZED TUNING SYSTEM... -
Page 35: Warranty Information
The foregoing is in lieu of all other warranties expressed or implied by Citizen Electronics. In no event shall Citizen Electronics or its dealers be liable for special or consequential damages arising from the use of this product, or for any delay in performance of this warranty due to cause beyond our control. The purchaser may have other rights under existing provincial or federal laws, and where such laws prohibit any terms of this warranty, they are deemed null and void, but the remainder of the warranty shall remain in effect.
