- Page 1 USER MANUAL 19CL705 19” LCD Television Easy PC Connection Customize your Picture and Sound www.citizen-electronics.com...
-
Page 3: Table Of Contents
Table of Contents Important Safety Instructions……………………………………… 1 Packing List…………………………………………………………. 4 Batteries for Remote Control……………………………………… 5 Remote Control……………………………………………………... 7 Product Overview…………………………………………………… 8 Installation…………………………………………………………… 10 Menu Operation…………………………………………………….. 10 (1) Picture Setting Menu……………………………………….. 10 (2) Sound Setting Menu………………………………………... 12 (3) Channel Setting Menu……………………………………… 13 (4) Timer Setting Menu…………………………………………. -
Page 5: Important Safety Instructions
Important Safety Instructions Electrical energy can perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. - Page 6 Refer to the identification/rating label located on the back panel of your 9、 Power plug product for its proper operating voltage. 10、 The MAINS plug or appliance coupler of this apparatus is used as the disconnect device. The disconnect device shall remain readily operable. 11、Overloading---Do not overload wall outlets, extension cables, or convenience receptacles on other equipment as this can result in a risk of fire or electric shock.
- Page 7 18、 Careful move--- Use only the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. Sudden stops, excessive force and uneven floor surfaces can cause the product to fall from the trolley.
-
Page 8: Packing List
28. When the LCD TV reaches its end of life and needs to be disposed. Please contact your local waste disposal facility to arrange proper disposal procedures. 29. Working condition of the product: Temperature: 0℃~40℃ Storage condition of the product: Temperature: -20℃~50℃ Notes: ①... -
Page 9: Batteries For Remote Control
BATTERIES FOR REMOTE CONTROL If the remote control fails to operate the LCD TV functions, replace the batteries in the remote control. 2. Insert two AAA-size batteries. 1. Push down to open the battery 3. Close up the cover until the cover. - Page 10 YPBPR input Capable of receiving high definition Component video signal in 480i, 480P, 576i, 576P, 720P, 1080i formats. MTS Stereo Decoding Function Enjoy stereo, bilingual and mono programs. VGA input a. This television can be used as a monitor by connecting it to a computer. Use as the display terminal By connecting the 3.5mm audio cord from your computer into this television, you will be...
-
Page 11: Remote Control
Remote Control PAGE 7... -
Page 12: Product Overview
RECALL : Return to the last viewed program AV/TV : Toggle between different signal sources available P.MODE : Select different modes of picture settings S.MODE : Select different modes of sound settings MENU : To go to the On Screen Display (OSD) menus 】... - Page 13 The button names and functions are as follows: Panel buttons Button Description To switch between TV, AV, S-VIDEO, YPBPR, and PC signal sources. 【TV/AV】 The same function as【AV/TV】on the remote control. To enter or quit from the OSD (On Screen Display) menu. 【MENU】...
-
Page 14: Installation
Installation 1. Remove the LCD TV from the box and place it on a flat surface in a well ventilated location. Connect the output terminal of the RF cable to the corresponding TV RF signal input terminal. The LCD TV is a high-tech digital product. To obtain optimal results, please use quality RF Cables. - Page 15 There are three built-in functions for enhancing the quality of the picture, LTI (Luminance Transient Improvement), CTI (Chroma Advance Transient Improvement) and Black Extend. Press【 】 to enter into the sub-menu of Color Temp for picture control, the 】and【 display is as follows: Only when the Color Temp is set as User mode, you can change the value of Red, Green or Blue.
-
Page 16: Sound Setting Menu
Function Description Item To adjust the picture’s contrast. Contrast To adjust the picture’s brightness. Brightness To adjust the picture’s Horizontal Position H Position To adjust the picture’s Vertical Position. V Position To adjust the picture’s sampling frequency Clock To adjust the picture’s sampling phase. Phase To adjust the color temperature Color Temp. -
Page 17: Channel Setting Menu
(3) Channel Setting Menu Item Function Description Switch the TV input mode between cable and air. Source Display the current channel number, you can switch between the Channel Buttons. channels through the 【 】or【 】 Erase or add the channel. Add/Erase Select this item, and then press【... -
Page 18: Parental Controls
Item Function Description Set the current time by pressing 【 】 / 【 】to change the time Current parameter (hour:minute ). Time Set the time to turn off the TV by pressing 【 】 / 【 】to change the time Off Time parameter (hour:minute ). - Page 19 ◆ Change Passwords 】to see the password submenu. Press the In Parent Control mode, press【 】/【 number button to enter the password. The default password is “0000”. ※ After a password correction has been confirmed, please remember it for entering into the Parent Ctrl menu, all functions can not be activated until the correct password is entered.
- Page 20 ◆French Rating For Canadian French Language Rating System, the following six ratings are available: E, G, 8 ANS +, 13 ANS +, 16 ANS +, 18 ANS + : Exempt : General programming, suitable for all audience : Children 8 years and older 8 ANS + : Children 13 years and older 13 ANS +...
-
Page 21: Sleep Timer
Signal Switch Use 【 】to select the desired signal after pressing【AV/ 】 on the remote control 】/【 select between the signal sources: TV, AV, S-VIDEO, YPBPR and PC. The order is as below: S-VIDEO YPBPR Sleep Function Press【SLEEP】 on the remote control, the following picture will be displayed on the screen: Sleep Press 【SLEEP】... -
Page 22: Trouble Shooting
TROUBLESHOOTING Before calling a technician, please check the following table to see if the below mentioned symptoms can be diagnosed and fixed. Symptoms Possible Causes Solution No picture, no sound, 1.The power cable is not 1.Plug the power cable in and no indicator light plugged in 2.Turn the power on... -
Page 23: Warranty Information
CITIZEN product or the loss of information. The purchaser will be responsible for any removal, reinstallation, transportation and insurance costs incurred.
