  • Page 1 VES-1000 Series VDSL-Ethernet Switches May 2002 Version 3.40 Hardware Installation Guide...
  • Page 2 ZyXEL Communications Corporation. Published by ZyXEL Communications Corporation. All rights reserved. Disclaimer ZyXEL does not assume any liability arising out of the application or use of any products, or software described herein.

  • Page 3: Zyxel Limited Warranty

    VES-1000 Series Ethernet Switch ZyXEL Limited Warranty ZyXEL warrants to the original end user (purchaser) that this product is free from any defects in materials or workmanship for a period of up to two (2) years from the date of purchase. During the warranty period and upon proof of purchase, should the product have indications of failure due to faulty workmanship and/or materials, ZyXEL will, at its discretion, repair or replace the defective products or components without charge for either parts or labor and to whatever extent it shall deem necessary to restore the product or components to proper operating...

  • Page 4: Customer Support

    VES-1000 Series Ethernet Switch Customer Support If you have questions about your ZyXEL product or desire assistance, contact ZyXEL Communications Corporation offices worldwide, in one of the following ways: Contacting Customer Support When you contact your customer support representative, have the following information ready: ♦...

  • Page 5: Table Of Contents

    MTU Application ..........................1-1 1.1.2 Enterprise Application........................1-2 1.1.3 Campus Applications ........................1-3 Chapter 2 Hardware Installation............................2-1 Operating Environment ..........................2-1 Installing the VES-1008..........................2-1 2.2.1 Free-standing............................. 2-1 2.2.2 Rack-mounted ........................... 2-1 2.2.3 Wall Mounted............................ 2-3 Installing the VES-1012..........................2-4 2.3.1...
  • Page 6 VES-1000 Series Ethernet Switch Rear Panel Connections..........................4-1 4.1.1 Power Cord............................4-1 Front Panel Connections ........................... 4-2 4.2.1 Console Port ............................4-3 4.2.2 VDSL Ports Connections ........................4-4 4.2.3 WAN Port (Ethernet) Connections....................4-4 Chapter 5 Turning On Your VES-1000 Series Switch......................5-1 Introduction ..............................5-1 Front Panel LEDs ............................
  • Page 7 Figure 2-1 Attaching the Mounting Brackets to the VES-1008....................2-2 Figure 2-2 Mounting the VES-1008 in a Rack..........................2-3 Figure 2-3 Attaching the Wall-mounting brackets to the VES-1008 ...................2-4 Figure 2-4 Attaching the Mounting Brackets to the VES-1012....................2-5 Figure 2-5 Mounting the VES-1012 in a Rack..........................2-6 Figure 3-1 Installation Overview for a VES-1012 ........................3-1...

  • Page 8: List Of Tables

    Table 6-4 PORT LED Troubleshooting............................6-2 Table 6-5 Testing Wiring on a VES-1008 ........................... 6-4 Table 6-6 Testing Wiring on a VES-1012 ........................... 6-5 Table 6-7 Pin Assignments for VES-1008 Telco-50 port ......................D viii Lists of Figures, Diagrams and Tables...

  • Page 9: Preface

    VDSL converters to this switch (ports 1 to 8). The VES-1012 extends on the flexibility of the VES-1008 as it provides 12 ports that allow for the connection of up to 12 individual subscribers. This hardware installation guide caters for both models.

  • Page 11: Ves-1000 Series Switch Applications

    This chapter describes the applications and basic operating environment for the VES Ethernet Switches. 1.1 Applications The VES-1008 supports 8 VDSL ports as well as a combined USER/CO Telco connector. Expanding on this flexibility, the VES-1012 features 12 VDSL ports as well as separate CO and USER Telco-50 connectors. The applications and operating environment (and associated diagrams) presented in this chapter primarily focus on the VES-1012;...

  • Page 12: Enterprise Application

    VES-1000 Series Ethernet Switch Figure 1-1 Building Deployment Example Using a VES-1012 1.1.2 Enterprise Application The VES-1000 Series of switches can also be used in enterprises to multiplex employee traffic to the Internet. Applications...

  • Page 13: Campus Applications

    VES-1000 Series Ethernet Switch Figure 1-2 Enterprise Application Using a VES-1012 1.1.3 Campus Applications Independent networks can also have traffic multiplexed to a gigabit switch or fiber ring using a VES-1000 Series switch. Applications...

  • Page 14: Figure 1-3 Ves-1012 Example Of A Campus Application Using A Gigabit Switch

    VES-1000 Series Ethernet Switch Figure 1-3 VES-1012 Example of a Campus Application Using a Gigabit switch Figure 1-4 VES-1012 Example of Campus Application Using a Fiber Ring Applications...

  • Page 15: Chapter 2 Hardware Installation

    Free-standing Position the VES-1008 on a flat surface. Make certain that the unit has adequate ventilation. 2.2.2 Rack-mounted Please note that rack-mounted is optional for the VES-1008. As a result, rack-mounted accessories are not supplied. • Two mounting brackets (optional).

  • Page 16: Figure 2-1 Attaching The Mounting Brackets To The Ves-1008

    Make sure the position of the VES-1008 does not make the rack unstable or top-heavy. Take all necessary precautions to anchor the rack securely before installing the unit. Position a mounting bracket on one side of the VES-1008, lining up the four screw holes on the bracket Step 1.

  • Page 17: Wall Mounted

    Figure 2-2 Mounting the VES-1008 in a Rack 2.2.3 Wall Mounted The VES-1008 is designed so that it can be mounted on a wall if the need arises. The following is needed in order to mount the VES-1008 on a wall: •...

  • Page 18: Installing The Ves-1012

    This ensures that the combined weight of the VES-1008 and the cables will not force any extra pressure on the actual wall.

  • Page 19: Figure 2-4 Attaching The Mounting Brackets To The Ves-1012

    VES-1000 Series Ethernet Switch • Eight M3 flat head screws (supplied) and a #2 Philips screwdriver. • Four M5 flat head screws and a #2 Philips screwdriver. Before you proceed with mounting the VES-1000 Series switch in a rack, please take note of the following precautions: Precautions: •...

  • Page 20: Figure 2-5 Mounting The Ves-1012 In A Rack

    VES-1000 Series Ethernet Switch Figure 2-5 Mounting the VES-1012 in a Rack Hardware Installation...

  • Page 21: Chapter 3 Installation Scenarios

    It should be noted that although the VES-1012 is shown in the following diagrams, the following scenarios can also apply to the VES-1008 - the primary difference is that a single Telco-50 cable is used for the combined USER/CO signal on the VES-1008. Installation instructions for the following scenarios are given for both the VES-1008 and the VES-1012.

  • Page 22: Telco Cables

    Connect a Telco connector to one end of the cable (see Diagram 5 for VES-1008 and Diagram 6 for VES-1012 in Appendix B for pin assignments) and connect the other end directly to an MDF; alternatively attach RJ-11 connectors and connect directly to VDSL modem(s).

  • Page 23: Typical Scenarios

    VES-1000 Series Ethernet Switch Figure 3-3 MDF (Main Distribution Frame) Wiring Connect wiring to end-user equipment to the lower ports of an MDF and connect wiring from the telephone company to the upper ports of an MDF (see the previous figure). Some MDFs have surge protection circuitry built in between the two banks;...

  • Page 24: Installation Scenario B

    Follow the pin assignments shown in the Appendix – Pin Assignments to wire a Telco cable (not Step 1. supplied in the package) to a Telco-50 connector (supplied). For the VES-1008 only, connect the Telco-50 connector end of the cable to the combined USER/CO Step 2. Telco-50 port located on the front panel of the VES-1008.

  • Page 25: Figure 3-5 One Mdf For End-User And Co Connections

    VES-1000 Series Ethernet Switch Figure 3-5 One MDF for End-user and CO Connections Please refer to the following figure for the connection schema. MDF 1 is the original MDF used for telephone connections only. MDF 2 is used for telephone connections only. MDF 3 is for VDSL service connections.

  • Page 26: Figure 3-6 Installation Scenario B Using Ves-1012

    The VES-1008 requires one cable (not supplied) and the VES-1012 requires two Telco cables (not supplied in the package) to two Telco-50 connectors. For the VES-1008 only, configure the Telco-50 cable to reflect the required phone and VDSL services. Step 3.

  • Page 27: Installation Scenario C

    VES-1000 Series Ethernet Switch Telephone subscribers only (that is, non-VDSL subscribers) retain connections to the lower ports of Step 10. MDF 1. Change the wiring from MDF 1 to MDF 3 for telephone subscribers who want VDSL service. Step 11. 3.4.3 Installation Scenario C Phone service is also available but there are two MDFs;...

  • Page 28: Figure 3-8 Installation Scenario C Using The Ves-1012

    Procedure To Connect To MDFs Acquire two additional MDFs (3 and 4). Step 1. For the VES-1008 only, follow the pin assignments shown in Diagram 5 to configure a cable for this Step 2. installation. For the VES-1012 only, follow the pin assignments shown in the Diagram 6 and Diagram 7 to wire two Telco cables (not supplied in the package) to two Telco-50 connectors (supplied).
  • Page 29 VES-1000 Series Ethernet Switch Connect the wiring on the other side of the Telco-50 cable to the lower ports of MDF 4 using a punch- Step 8. down tool. Connect the top ports of MDF 4 to the bottom ports of MDF 1 using regular telephone cables. Step 9.

  • Page 31: Chapter 4 Hardware Connections

    The following figure shows the rear panel of the VES-1012 only. The VES-1008 differs in that the 12-volt DC power socket is located on the front panel. There are no sockets or switches on the back panel of the VES-1008.

  • Page 32: Front Panel Connections

    Figure 4-2 Connecting the Power Cord to the VES-1012 and a Power Source 4.2 Front Panel Connections The VES-1000 Series of Ethernet switches all feature the Console port, VDSL and WAN Ethernet switch connections on the front panel. Figure 4-3 VES-1008 Front Panel Connections Overview Hardware Connections...

  • Page 33: Console Port

    VES-1000 Series Ethernet Switch Figure 4-4 VES-1012 Front Panel Connections Overview 4.2.1 Console Port For the initial configuration, you need to use terminal emulator software on a computer and connect it to the VES- 1000 Series switch through the console port. Connect the male 9-pin end of the console cable to the console port of the VES-1000 Series switch.

  • Page 34: Vdsl Ports Connections

    MDF. The VDSL Port pins are used to connect the VES-1008 to the VDSL modems (for example, ZyXEL’s Prestige 841). As with the phone port pins, each VDSL port requires 2 separate pins. Eight separate VDSL ports are available on the VES-1008 and each port is available to a separate user.

  • Page 35: Figure 4-6 Stacking The Ves-1012

    VES-1000 Series Ethernet Switch Figure 4-6 Stacking the VES-1012 If the number of ports on the WAN switch is limited, it is possible to daisy-chain the VES-1000 Series of switches before connecting to the WAN switch. Use crossover cables between VES-1000 Series Switches and a straight- through cable (as described above) between VES-1000 Series Switches and an Ethernet switch.

  • Page 37: Turning On Your Ves-1000 Series Switch

    Can see the status LEDs on the front panel while you view the VT100 terminal emulator. Push the power switch (located on the front panel of VES-1008 and on the back panel for the VES-1012) to the ON position. The VES-1000 Series switch will automatically run a self-test that takes approximately 20 seconds.

  • Page 38: Table 5-1 Ves-1000 Series Switches: Led Descriptions

    VES-1000 Series Ethernet Switch Table 5-1 VES-1000 Series Switches: LED Descriptions COLOR STATUS DESCRIPTION Green The system is turned on. The system is off. Green Blinking The system is rebooting and performing self-diagnostic tests. The system is on and functioning properly. The power is off or the system is not ready/malfunctioning.

  • Page 39: Chapter 6 Hardware Troubleshooting

    CORRECTIVE ACTION Make sure the power cord is connected properly to the power outlet. Make sure you are using the correct power source (For VES-1012, 35 watt max., 100-240 VAC/1A, 50/60Hz. For VES-1008, 24 watt max., 100-240 VAC/1A, 50/6-Hz). Make sure the power cord is connected to the VES-1000 Series switch properly.

  • Page 40: The Alm Led Is On

    VES-1000 Series Ethernet Switch The ALM LED Is On The ALM (alarm) lights when the VES-1000 Series switch is overheated and/or the fans are not working properly (VES-1012 only) and/or voltage readings are outside the tolerance levels. The VES-1000 Series switch may become damaged if the ALM LED remains on.

  • Page 41: The Wan Link Is Down

    STEP CORRECTIVE ACTION Check that the Ethernet ports (ports 9 and 10 on a VES-1008 and ports 13 and 14 on the VES-1012) connect to a WAN Ethernet using straight-through Category 5 UTP (Unshielded Twisted Pair) cables with RJ-45 connectors.

  • Page 42: Figure 6-1 Testing In-House Wiring On A Ves-1012

    If the problem remains, check the pin assignments of the Telco-50 connector. If the problem remains, then the VES-1008 or MDF 2 is faulty. Repeat the test in step A using MDF 2 to determine if MDF 2 has problems. Contact the telephone company if that is the case.

  • Page 43: Table 6-6 Testing Wiring On A Ves-1012

    STEP TEST If the problem remains, then the VES-1008 or MDF 3 is faulty. Repeat the test in step A using MDF 3 to determine if MDF 3 has problems. Contact the telephone company if that is the case. If not, contact your VES-1008 vendor outlining the problem and the steps you took to solve it.

  • Page 45: Appendix A Removing And Installing A Fuse

    VES-1000 Series Ethernet Switch Appendix A Removing and Installing a Fuse This appendix shows you how to remove and install fuses for the VES-1012. This section applies to the VES-1012 only. The VES-1012 uses one 250V-3A fuse. The VES-1012 comes with two 250V-3A fuses; one is installed at the factory (in the fuse housing), while the other one is a spare that comes with your VES-1012.

  • Page 46: Diagram 2 Opening The Fuse Housing

    VES-1000 Series Ethernet Switch Diagram 2 Opening the Fuse Housing Gently pull out the casing that holds the two fuses as shown next. Step 4. Diagram 3 Fuses in the Fuse Housing Pull gently, but firmly, to remove the burnt out fuse from the fuse housing. A burnt-out fuse is Step 5.

  • Page 47: Appendix B Pin Assignments

    VES-1000 Series Ethernet Switch Appendix B Pin Assignments Console Port Pin Assignments Diagram 4 Console Port Assignments VES-1008 Telco-50 Pin Assignments for Phone and VDSL Diagram 5 Wiring Diagram for the VES-1008 Telco-50 connector Appendix B PIN Assignments...

  • Page 48: Diagram 6 Ves-1012 Telco-50 Pin Assignments For Phone Lines

    VES-1000 Series Ethernet Switch Table 6-7 Pin Assignments for VES-1008 Telco-50 port PHONE PORT TELCO-50 PIN ASSIGNMENTS 8, 33 7, 32 6, 31 5, 30 4, 29 3, 28 2, 27 1, 26 VDSL PORT PINS TELCO-50 PIN ASSIGNMENTS 25, 50...

  • Page 49: Diagram 7 Ves-1012 Telco-50 Pin Assignments For Vdsl Connections

    VES-1000 Series Ethernet Switch VES-1012 Telco-50 Pin Assignments for VDSL Connections Diagram 7 VES-1012 Telco-50 Pin Assignments for VDSL Connections RJ-45 Pins PIN # RJ-45 (ETHERNET PORT) Not connected Not connected Not connected Not connected RJ-11 Pins PIN # RJ-11 (TELEPHONE PORT) Not connected RING Not connected...
  • Page 50 VES-1000 Series Ethernet Switch Appendix B PIN Assignments...

  • Page 51: Appendix C Hardware Specifications

    VES-1000 Series Ethernet Switch Appendix C Hardware Specifications VES-1008 Specifications Physical Interfaces • Compact A4-sized enclosure • 10” 1U rack/wall mountable unit • One Telco-50 connector for 8 ports to CPE and POTS/ISDN to MDF or CO • One Console port for local management •...

  • Page 52: Power Consumption

    VES-1000 Series Ethernet Switch VES-1012 Specifications Physical Interfaces • 19” 1U rack-mountable, wall-mountable unit • Two Telco-50 connectors, including 1 Telco-50: 12 USER lines (to the VDSL subscriber) 1 Telco-50: 12 CO lines (to the central office or PBX) • One DB-9F RS-232 local console port •...

  • Page 53: Index

    VES-1000 Series Ethernet Switch Index #2 Philips screwdriver....2-1, 2-2, 2-3, 2-4, 2-5 Enable the VDSL port..........6-2 10 Mbps Ethernet ........... 5-2 Fans ..............5-1, 6-2 100 Mbps Ethernet ..........5-2 Fiber Ring ............1-3, 1-4 Flow control ............6-3 Free-standing............2-1 Front Panel LEDs ..............
  • Page 54 VES-1000 Series Ethernet Switch Power Cord............4-1 Rear Panel ............4-1 lightening..............H Related Documentation ..........ix Removing and Installing A Fuse ......A Removing Fuses ............A Before you Begin ..........A M3 flat head screws......... 2-1, 2-3, 2-5 Opening the Fuse Housing ........B M5 flat head screws......2-1, 2-2, 2-3, 2-5 Repair ...............iii MDF (Main Distribution Frame)....
  • Page 55 VES-1000 Series Ethernet Switch Trunking..............6-3 VES-1012..............ix Turning On your VES-1012........5-1 voltage levels ............6-2 USER port ........4-4, 6-2, 6-4, 6-5 WAN Link ............. 6-3 User’s Guide............ix, 6-1 Warning Sticker ............. 4-1 Weight..............G, H Working Fans............6-2 VDSL ...............
