PROCEDURE 14
15. Connect the wiring harness (BLUE) to the con-
troller connector (BLUE).
M
16. Resecure the wiring harness and motor cables to
the crossbraces with new tie wraps at the posi-
W
tions noted in STEP 8.
D
W
H
E
NOTE: Position of Charger
E Cable Mounting Bracket may
vary depending on wheel-
L
chair model and options.
C
H
A
(STEPS 4, 11)
I
Charger
Locknuts
R Cable
(STEPS 6, 13)
Mounting
S
Bracket
Phillips Bolts
(STEPS 6, 13)
Locknuts
(STEPS 5, 12)
MKIV Joystick
Phillips Screws
(STEPS 4, 11)
Spacers
Wiring
Harness
FIGURE 10 - REPLACING WIRING HARNESS
17. Reinstall the battery boxes. Refer to INSTALLING/
REMOVING BATTERY BOXES in this procedure of
manual.
18. If necessary, install the front and rear shrouds. Refer
to REMOVING/INSTALLING SHROUDS in PRO-
CEDURE 10 of this manual.
Controller
To Controller
(STEPS 3, 15)
Phillips Bolts
(STEPS 5, 12)
72
MWD WHEELCHAIRS
(STEPS 7, 14)
DETAIL "A"
Phono Jack Nut
Limit Switch Bracket
Phono Jack
Tie Wraps
(STEPS 8, 16)
