Refrigerant Line Set Requirements; Heat Pump Electrical Specifications; Insulation Thickness & Material Information - Johnson Controls 22 SEER Installation Manual

898841-UIM-B-0113
TABLE 4: Heat Pump Electrical Specifications
Heat Pumps
Power Supply (V, Phase, Hz)
Min. Circuit Ampacity
Fan Motor (F.L.A)
Heat Pumps
Power Supply (V, Phase, Hz)
Min. Circuit Ampacity
Fan Motor (F.L.A)
Heat Pumps
Power Supply (V, Phase, Hz)
Max. Fuse Size (time delay) (A)
Min. Circuit Ampacity
Fan Motor (F.L.A)
R.L.A
Compressor
L.R.A
Heat Pumps
Power Supply (V, Phase, Hz)
Max. Fuse Size (time delay) (A)
Min. Circuit Ampacity
Fan Motor (F.L.A)
R.L.A
Compressor
L.R.A
Connecting Wires and the Ground Wire
• Use double insulated copper wire with 600V insulation.
• Use copper conductors only.
• Follow all local electrical codes.
Power Supply Cable and Ground Wire
• Use copper conductors only.
• Follow all local electrical codes.
NOTICE
The the indoor unit is powered from the outdoor unit, depending on
local code, a disconnect switch needs to be installed to a power sup-
ply circuit.
SECTION VII: REFRIGERANT LINE SET
REQUIREMENTS
TABLE 5: Insulation Thickness & Material Information
Pipe
Liquid Line
Gas Line
6
DHPM09NWM42Q1
208/230V/1
10
0.2
DHPM18NWM42Q1
208/230V/1/60HZ
16A
0.28A
DHPM09CSM42Q1
208/230V/1
15
10
0.14
6.21
13.8
DHPM18CSM42Q1
208/230V/1/60HZ
20A
16A
0.32A
9.35A
/
Outside Diameter
Inch (mm)
.375 (9.52)
.625 (15.9)
INDOOR UNIT
DHPM09NWM41Q1
115V/1
16
0.38
INDOOR UNIT
DHPM24NWM42Q1
208/230V/1/60HZ
16A
0.24A
OUTDOOR UNIT
DHPM09CSM41Q1
115V/1
25
16
0.17
12.23
33
OUTDOOR UNIT
DHPM24CSM42Q1
208/230V/1/60HZ
20A
16A
1.1A
10.45A
/
• To prevent condensation, insulate the two refrigerant pipes.
• Refrigerant pipe bending radius must be 4 in. (100 mm) or more.
Be sure to use the insulation of specified thickness (refer to Table 5).
Excessive insulation may cause incorrect installation of the indoor
unit, and too little insulation may cause condensate to form.
• The unit has flared connections on both indoor and outdoor sides
• Remove the valve cover from the outdoor unit then connect the
pipe
• Refrigerant pipes are used to connect the indoor and outdoor units
• Be careful not to crush or over bend the pipe in pipe bending
• Refrigerant adjustment
• If pipe length exceeds 25 ft. (7.5 m), additional refrigerant (R410A)
charge is required (The outdoor unit is charged with refrigerant for
pipe length up to 25 ft. [7.5 m]).
Minimum Wall
Thickness
0.0315 (0.8)
0.0394 (1.0)
DHPM12NWM42Q1 DHPM12NWM41Q1
208/230V/1
10
0.2
DHPM30NWM42Q1 DHPM36NWM42Q1
208/230V/1/60HZ 208/230V/1/60HZ
15
0.4
DHPM12CSM42Q1 DHPM12CSM41Q1
208/230V/1
15
10
0.14
5.34
13.8
DHPM30CSM42Q1 DHPM36CSM42Q1
208/230V/1/60HZ 208/230V/1/60HZ
25
15
0.45
11.42
/
Insulation
Thickness
0.315 (8)
Heat Resistant Foam Plastic
0.045 Specific Gravity
0.315 (8)
Johnson Controls Unitary Products
115V/1
16
0.38
23
0.47
115V/1
25
16
0.17
12.43
33
35
23
0.73
16.95
/
Insulation
Material
