Page 1 USER MANUAL BUILT-IN COOKING APPLIANCES POR663, PORS663L/R, POR667, POR668, PORS668L/R, POR783, POR881, POR883, PPR776, PGR657, PGR659, PXR688, PXR698, PDR790, PDR794...
Page 2: Table Of Contents
Important safety instructions .............. 3 Description of your appliance ............. 5 Congratulations on the purchase of your new oven. POR663 ..................5 Follow the instructions below to ensure that your oven is PORS663 ..................5 installed with oven accessories fitted correctly for safety, POR667 ..................
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Please read the user manual carefully and store in a handy WARNING place for later reference. The symbols you will see in this booklet have these meanings: • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and WARNING...
Page 4 IMPORTANT SAFETY INSTRUCTIONS WARNING WARNING GRILL COOKTOPS The grill door must be left fully open whilst grilling Do not allow pots to boil dry, as damage to both in a separate grill wall oven. pan and cooktop may result. The grill drawer must be left approximately two Do not operate the cooktop for an extended period finger widths ajar whilst grilling in a separate grill of time without a utensil on the hot plate.
Page 5: Description Of Your Appliance
POR663 PORS663 Function oven/Grill 90 minute‘Auto off’ timer selector temperature selector POR667 Function electronic oven/Grill selector clock temperature selector POR668 PORS668 Function electronic oven/Grill selector clock temperature selector POR783 Programmable controller POR881 Temperature Function electronic selector selector clock POR883 Programmable controller...
Page 6: Pgr657
PGR657 oven Grill 90 minute temperature selector temperature selector ‘Auto off’ timer PGR659 Function oven electronic Grill selector temperature selector clock temperature selector PXR688 oven Grill 90 minute temperature selector temperature selector ‘Auto off’ timer PXR698 Function oven electronic Grill selector temperature selector clock...
Page 7: Before Operating Your Appliance For The First Time
BEFORE OPERATING YOUR APPLIANCE FOR THE FIRST TIME SETTING THE TIME FOR POR881 When power is supplied to your oven “12.00“ will be TIPS & INFORMATION displayed on the clock and the display will flash. • To set the time of day hours, press – or +, then press SETTING THE TIME CLoCK and the seconds will begin to flash which can If you have purchased a model fitted with an electronic or...
Page 8: Installing Your Oven Accessories
INSTALLING YOUR OvEN ACCESSORIES 2. Side racks • Insert the twin pegged side into the rear access holes provided, ensuring pegs are fully inserted. • Then locate the front peg into the front access hole and push in firmly. 1. Catalytic liners (on selected models) Catalytic liners are coated with a specially formulated enamel coating.
Page 9 INSTALLING YOUR OvEN ACCESSORIES • When locating the side racks into the small oven or grill 3. Shelves and trays (excluding POR881) (Refer Fig. 2) ensure the left pegs go into the lower two access holes. The shelves are designed so that they have maximum travel but cannot be accidentally pulled right out.
Page 10: Using Your Oven
USING YOUR OvEN Understanding your oven functions Your oven will have a selection of the following functions; description and touch control symbol illustrated below. Refer to “Description of your appliance” (page 5) to confirm what functions are available to you. Function 4 Base Heat Heat comes from the element below the food.
Page 11 USING YOUR OvEN Function 7 Function 10 Defrost Maxi Grill The “defrost” function uses low temperature air that is “maxi grill” directs radiant heat from 2 powerful upper circulated by the fan. You can defrost (thaw) your food elements onto the food. You can use the “maxi grill” before you cook it.
Page 12 USING YOUR OvEN Cooling/venting fan Your built-in appliance is fitted with a cooling fan. This prevents your kitchen cabinet from overheating and reduces the condensation inside the oven. It will operate whenever you are using your oven or grill and will blow Small Oven Grill warm air across the top of the oven door.
Page 13 USING YOUR OvEN Pre-heating your appliance Setting temperatures For best results when baking it is recommended that you preheat The following table displays the temperature settings for your oven for 30 minutes. Preheat the grill for 3 minutes to recipes which do not show actual temperatures for non fan obtain best results.
Page 14: Using Your Cooktop
USING YOUR COOKTOP Cleaning your ceramic hotplate CAUTION 1. Remove all spilt food and fat with a razor blade scraper (supplied with the unit) while the ceramic glass The ceramic cooktop is made from ceramic glass, is still warm, but not hot. Wipe clean with dishwashing a tough durable material that withstands heating and detergent on a damp cloth.
Page 15 USING YOUR COOKTOP Dealing with cooktop problems PROBLEM POSSIBLE CAUSE WHAT TO DO Heating 1 Power not • Check cooktop elements switched on is plugged in and not working power is on 2 Controls incorrectly set • Check correct knob turned for element 3 Household fuse blown •...
Page 16: Cooking With Your Timer
COOKING WITH YOUR TIMER OPERATING THE ELECTRONIC CLOCK 90 minute “Auto Off” timer ELECTRONIC CLOCK The 90 minute timer features an automatic oven “cut off”. A cooking period of up to 90 minutes can be used. Touch Control (selected models only) When the timer has counted back to “Auto off”...
Page 17 MODEL POR783 & POR883 PROGRAMMABLE CONTROLLER 4. Set the cooking duration you want by using – or +. Touch Control 5 seconds after the last change, the “cook time” indicator I will stop flashing, and the time of day will be displayed.
Page 18 MODEL POR783 & POR883 PROGRAMMABLE CONTROLLER Setting the cooking time Using FHU (Fast Heat Up) mode 1. Select the desired oven function and cooking temperature. To quickly and efficiently preheat your oven, it is 2. Press the “Timer” as often as necessary, until the “cook recommended to select the “Fast Heat”...
Page 19 MODEL POR881 ELECTRONIC CLOCK Setting the cooking time 1. Select the desired oven function and cooking temperature. 2. Press the CLoCK button as often as necessary, until the “cook time” ❘➔❘ symbol appears. 3. Set the desired cooking time commencing with minutes by using the –...
Page 20 MODEL POR881 ELECTRONIC CLOCK Setting the timer Switching the clock display ON and OFF 1. Press TImeR button until the display begins to flash. 1. Press together + and – for 2 seconds to switch ‘off’ 2. Set the countdown time you want by using – and +. the display.
Page 21 OvEN SHELF LOCATION • Select the correct shelf location for food being cooked. Oven shelf location (POR881) • Make sure dishes will fit into the oven before you Your oven comes with formed “easy clean” runners that switch it on. allow five positions for shelves.
Page 22: Cooking Guide
COOKING GUIDE Choosing the best oven settings The following table is intended as a guide and experience may show some variation in cooking times necessary to meet individual requirements. It may be necessary to change some cooking times and temperatures from your previous oven.
Page 23 Roasting Meat 1. Place the meat in the oven and set the temperature between 180°C and 200°C. (It is recommended to wrap your meats in an oven roasting bag or foil to prevent fats and oils from splattering, making it easier to clean your oven.) 2.
Page 24: Grilling Guide
GRILLING GUIDE Grilling hints Guide to better grilling TIPS & INFORMATION Steak 15 – 20 minutes NOTE: Always clean the grill/oven dish after every use. Chops 20 – 30 minutes Excessive fat build up may cause a fire. Fish 8 – 10 minutes Bacon 4 –...
Page 25: Dealing With Cooking Problems
DEALING WITH COOKING PROBLEMS (SEE ALSO Pg.37) PROBLEM CAUSES REMEDIES Uneven cooking: • Incorrect shelf position. – Select shelf that puts food in the centre of the oven. • Oven tray too large. – Experiment with other trays or dishes. •...
Page 26: Cleaning Your Appliance
CLEANING YOUR APPLIANCE Oven TIPS & INFORMATION • Always keep your appliance clean. Ensure that fats and • Always make sure that the oven is electrically isolated oils do not accumulate around elements, burners or fans. before cleaning. This can be done via the functional •...
Page 27 CLEANING YOUR APPLIANCE CATALYTIC LINERS (WHERE FITTED) Cleaning your oven accessories Some models come with Catalytic liners. These models contain: 2 Catalytic side liners (to be fitted by you) 1 Catalytic fan cover (already fitted) NOTE: If your oven does not have catalytic liners and you wish to purchase them, they are available from the Customer Care Centre.
Page 28 CATALYTIC LINERS (WHERE FITTED) Removing the catalytic liners Removing and replacing the oven light and side light (where fitted) • Remove Side Racks. • Turn oven light glass anticlockwise to remove it for • Lift the liner up to disengage the hooks. globe replacement.
Page 29 CLEANING YOUR APPLIANCE Replacing the oven top light (POR883 model only) WARNING WARNING make sure the appliance is turned off before you remove or replace parts, to avoid the possibility of electric shock. Turn the appliance off at the main switch to make sure there is no power to the oven.
Page 30 CLEANING YOUR APPLIANCE • Grasp the oven door with a hand each side of the Cleaning oven door (except models POR883 & POR881) door and remove it from the oven by pulling it towards you. WARNING Do not lift the door by the handle. Rough handling will cause glass to break.
Page 31 CLEANING YOUR APPLIANCE Re-assembling door glass panels • Insert the smaller clear glass panel (when fitted) first from above and at an angle to the profile of the door. Cleaning door glass panels WARNING Do not to use harsh abrasives on the glass panes as the reflective surface plays a role in the function of the oven.
Page 32: Re-Assembling Top Door Trim
CLEANING YOUR APPLIANCE • Open the door fully to access the hinges then rotate Re-assembling top door trim • Take hold of the top door trim at each side and the ‘stirrups’ (see image below) until they lock into the hook.
Page 33 CLEANING YOUR APPLIANCE Removing side open door glass panel Cleaning side open door glass panels WARNING WARNING Rough handling, especially around the edges can cause Do not to use harsh abrasives on the glass panes as the the glass to break. reflective surface plays a role in the function of •...
Page 34 CLEANING YOUR APPLIANCE CLEANING THE PYROLYTIC OvEN DOOR (POR883 & POR881 MODELS ONLY) Your pyrolytic oven is equipped with an oven door that can Replacing top door trim • Take hold of the top door trim at each side and be disassembled in order to clean all the panes of glass.
Page 35 Removing the glass panes • Remove the 3 panes of glass starting with pane 1. • When removing pane 3 ensure that the 2 rubber supports are removed before cleaning. Do not misplace them! Cleaning the glass panes Clean with a damp cloth. Do not use scouring agents or abrasive sponges as these could damage the reflective surface.
Page 36 PYROLYTIC CLEANING OF THE OvEN CAvITY (POR883 & POR881 MODELS ONLY) Operation Pyrolytic Cleaning Operation (POR881 only) If your oven has the Pyrolytic self-cleaning function, it cleans by 1. The pyrolytic cleaning function can be selected by burning off the spatters and accumulated dirt and grease turning the function selector switch clockwise to the from the oven cavity, at high temperature.
Page 37: Solving Problems
SOLvING PROBLEMS Faults PROBLEM POSSIBLE CAUSE If there is a problem with the oven and/or grill, please: oven or grill • Time of day not set. • Check the points listed below before calling for service. not working: • Power not turned on. It may be possible to avoid a call by fixing the problem •...
Page 38: Installing Your Appliance
INSTALLING YOUR APPLIANCE Cabinet Construction for your appliance For the best integration within a kitchen, install this appliance WARNING in a standard 600mm wide cupboard that gives a flush fit USE AN AUTHORISED PERSON with the surrounding cupboard fronts (figure A). As stated in the local municipal building codes and other relevant statutory regulations.
Page 39 Hard Wiring Detail 1. Remove terminal cover plate from rear panel of appliance. 2. Fit wires through hole in cover plate and make connections to terminals. Second active wire only 3. engage wires into plastic clip. Secure plastic clip with required (optional) for two long silver screws (supplied in separate bag).
Page 40 Underbench Ovens and Side Opening Door Ovens Your underbench oven looks best when the control panel is directly under the benchtop. An upper infill panel may have to be added if the cooktop placed above the benchtop is too deep. Refer to cooktop installation instructions for required clearance between cooktop and oven.
Page 41 Separate Grill Underbench Ovens GAS TYPE Flush fit 581min Proud fit 560min mounting holes mounting holes Recommended Cabinet Design NOTE TO INSTALLER: For Separate Grill Underbench Installations where a Cooktop is installed directly above the appliance, a minimum clearance distance of 10mm must be allowed for between the bottom of the cooktop & the top of the Separate Grill Underbench Oven.
Page 42 INSTALLATION Double Ovens GAS TYPE Flush fit 1086 581min Proud fit 1078 560min 561mm use 25mm black installation screws (as supplied) mounting holes use 15mm black installation screws (as supplied) 650mm mounting holes 596mm Cooktop cut-out dimensions (combo models) COOKTOP DIMENSIONS Overall Cooktop Dimensions Width 610mm...
Page 43: Warranty
Warranty FOR SALES IN AUSTRALIA AND NEW ZEALAND APPLIANCE: BUILT-IN OVEN, COOKTOP AND FREESTANDING COOKER This document sets out the terms and conditions of the product 6. Proof of purchase is required before you can make a claim under warranties for Electrolux Appliances. It is an important document. this warranty.
Page 44 Top Service encompasses the after sales service provided by The electrolux Group to consumers including delivery, home service and spare parts. Westinghouse. We are part of the Electrolux family. Share more of our thinking at www.electrolux.com Part Number: 0342 001 589 Issue A ©...
