Connecting HDMI Input (480p/720p/1080i/1080p)

HDMI supports High Definition Input and HDCP (High-bandwidth Digital Content Protection). Some
devices require HDCP in order to display HD signals.
Connect the video/audio cable (not included) as shown in the following illustration, and then
connect the power cord.
(1) Connect an HDMI to DVI signal cable and RCA-PC audio cable to the monitor and VCR/
DVD/Set-top box
(2) Connecting an HDMI signal cable to the monitor and DVR/DVD/Set-top box
Figure 3-25
Select an input signal.
Press the INPUT button on the remote control to select the input signal. Press the SET button to
save your change.
Or, press the SOURCE button on the back side of the monitor panel. Press the AUTO/SET
button to save your change.
When connecting with an HDMI to DVI signal cable or HDMI signal input cable, select HDMI/DVI
from the Input menu.
Chapter 3 Setting Up the Monitor
Connecting HDMI Input to VCR/DVD/Set-Top Box
