BUILT-IN NG SIDE BURNER INSTALLATION/OWNER'S GUIDE
YOU MUST READ THIS OWNERS GUIDE
BEFORE OPERATING YOUR GAS GRILL
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open fl ames.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fi re department.
Leaking gas may cause a fi re or explosion
which can cause serious bodily injury or
death, or damage to property.
1. Do not store or use gasoline or other
fl ammable liquids or vapors in the vicinity
of this or any other appliance .
2. An LP cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
SUMMIT
DANGER
WARNING
®
#
Summit
THESE ACCESSORIES MAY BE PURCHASED
WARNING: Follow all leak-check procedures
carefully in this manual prior to barbecue
operation. Do this even if the barbecue was
dealer-assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not try to light this appliance
without reading the "Lighting Instructions"
section of this manual.
42377
®
Built-In NG Side Burner
SEPARATELY.
42377 US 01/18/06
NG
Advertisement
Table of Contents
Related Manuals for Weber Summit 42377
Summary of Contents for Weber Summit 42377
- Page 1 SUMMIT ® 42377 BUILT-IN NG SIDE BURNER INSTALLATION/OWNER'S GUIDE ® Summit Built-In NG Side Burner THESE ACCESSORIES MAY BE PURCHASED SEPARATELY. YOU MUST READ THIS OWNERS GUIDE WARNING: Follow all leak-check procedures BEFORE OPERATING YOUR GAS GRILL carefully in this manual prior to barbecue operation.
- Page 2 Do not use a fl ame to check for gas leaks. ® Combustible materials should never be within 24 inches (11 mm) of the top, bottom, back or sides of your Weber Built-In side burner. Do not put a barbecue cover or anything fl ammable on, or in the storage area under the barbecue. Built-In side burner barbecue should never be used by children.
-
Page 3: Warranty
If there are no local codes, you must conform to the lat- accompanying it. est edition of the National Fuel Gas Code: ANSI Z 223.1/NFPA54. Weber may require reasonable proof of your date of purchase. ® •... - Page 4 GAS INSTRUCTIONS LOCATING YOUR BUILT-IN SIDE BURNER When determining a suitable location for your Built-In Side Burner installa- tion, give attention to concerns such as exposure to wind, proximity to traffi c 24 inches Any Surface paths, and keeping any gas supply lines as short as possible. Never locate the Summit ®...
-
Page 5: Test Connections
GAS INSTRUCTIONS BUILT-IN GAS LINE LOCATIONS TEST CONNECTIONS GENERAL CONSTRUCTION DETAILS All connections and joints must be thoroughly tested for leaks in accordance with local codes and all listed procedures in the latest ® • Summit Built-In side burner unit should be on site before construction edition of ANSI Z223.1/NFPA 54. - Page 6 GAS INSTRUCTIONS TYPICAL NATURAL GAS SUPPLY INSTALLATION GAS LINE PIPING • Refer to the piping chart at the bottom of previous page. We recommend that this installation be done by a LICENSED professional. • The corrugated gas line from the manifold is 58 inches long. Do not extend the gas line.
- Page 7 You will need: a soap and water solution, and a rag or brush to apply it. Turn on gas supply. Note: You must connect your side burner to a Weber ® approved regulator Check for leaks by wetting the connections with the soap and water solution (part number #62434) located at main gas supply.
-
Page 8: Lighting The Side Burner
GAS INSTRUCTIONS SIDE BURNER LIGHTING INSTRUCTIONS Check: Corrugated gas line-to-Accessory “T” Connection. Main gas Supply to regulator DANGER WARNING: If there is a leak a connection(1), retighten Failure to open the lid while igniting the side the fi tting with a wrench and recheck for leaks with burner, or not waiting 5 minutes to allow the soap and water solution. -
Page 9: Operating / Maintenance
Customer may result in an explosive fl ame-up which can Service Representative in your area using the contact information on our web site. Log onto www.weber.com ® cause serious bodily injury or death. -
Page 10: Side Burner Troubleshooting
If match lights burner, check igniter (see below). If problems cannot be corrected by using these methods, please contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com ® SIDE BURNER MAINTENANCE... - Page 11 ATTENTION: This product has been safety tested and is only certifi ed for use in a specifi c country. Refer to coun- try designation located on outer carton. These parts may be gas carrying or gas burning components. Please contact Weber-Stephen Products Co., Customer Service Department for genuine Weber-Stephen Products Co. replacement part(s) information.
- Page 12 WEBER-STEPHEN PRODUCTS CO. ® www.weber.com ©2003 The following trademarks are registered in the name of Weber-Stephen Products Co., an Illinois corporation, located at 200 East Daniels Road, Palatine, Illinois 60067 U.S.A. Australia; Smokey Joe, Weber, Kettle Silhouette , Genesis, Austria; Kettle Silhouette , Smokey Joe, Weber, Benelux;...
