V I E L U X E
LP Gas Barbecue
Owners Guide
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your
gas supplier or your fire department.
Leaking gas may cause a fire or
explosion which can cause serious
bodily injury or death, or damage to
property.
WARNING
1. Do not store spare liquid propane
cylinder within 10 feet (3m of this
appliance.)
2. Do not store or use gasoline or other
flammable liquids or vapors within 25
feet (8m) of this appliance.
WARNING: Follow all leak-check
procedures carefully in this manual prior
to barbecue operation. Do this even if
barbecue was dealer-assembled.
NOTICE TO INSTALLER: These
instructions must be left with the owner
and the owner should keep them for
future use.
THIS GAS APPLIANCE IS DESIGNED
FOR OUTDOOR USE ONLY.
WARNING: Do not try to light this
appliance without reading "Lighting"
instructions section of this manual.
Liquid Propane Gas
Vieluxe 44 inch
Vieluxe 44 inch
Vieluxe 56 inch
Y
OU MUST READ THIS
BEFORE OPERATING YOUR GAS GRILL
™
O
G
WNERS
UIDE
60695
02/05/01
