PERFORMER
TOUCH-N-GO
IGNITION
™
Owner's Manual
WARNING: Follow all leak check
procedures carefully in this manual prior
to barbecue operation. Do this even if
barbecue was dealer assembled.
NOTICE TO INSTALLER: These
instructions must be left with the owner
and the owner should keep them for
future use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not try to light this
appliance without reading "Lighting"
instructions section of this manual.
™
Serial Number
Please use this number in
registering your warranty and any
correspondence with the factory.
FOR YOUR SAFETY
1. Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
2. An LP tank not connected for use shall
not be stored in the vicinity of this or
any other appliance.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, immediately call
your gas supplier or your fire
department.
3994601
11/96

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Burner and is the answer not in the manual?

Questions and answers

Related Manuals for Weber Burner

Summary of Contents for Weber Burner

  • Page 1 PERFORMER TOUCH-N-GO IGNITION ™ Owner’s Manual WARNING: Follow all leak check procedures carefully in this manual prior to barbecue operation. Do this even if barbecue was dealer assembled. NOTICE TO INSTALLER: These instructions must be left with the owner and the owner should keep them for future use.

  • Page 2: Warnings

    Do not use a flame to check for gas leaks. Should the burner go out at any time during operation, turn tank valve off. Remove lid and wait five minutes before attempting to relight, using the lighting instructions in this manual.

  • Page 3: Warranty & Patents

    Weber is not liable for any special, indirect or consequential damages. Some states do not allow the exclusion or limitation of incidental or consequential damages, so this limitation or exclusion may not apply to you.

  • Page 4: Patents And Trademarks

    © 1996 Weber. Weber, , the kettle configuration, One-Touch and Performer are registered U.S. trademarks; Char-Basket, CharBin, Touch-N-Go and Tuck-Away are U.S. trademarks of Weber- Stephen Products Co., 200 East Daniels Road, Palatine, IL 60067-6266. U.S.A. The Performer is covered under the following patent nos.: U.S.A.: #RE33,091;...

  • Page 5: Table Of Contents

    Exclusive Touch-N-Go™ Gas Ignition System takes the hassle out of lighting charcoal briquets. Simply push a button and the system's gas burner ignites, starting the charcoal for you. No dangerous liquid starters to use or store, and no more liquid starter aftertaste.

  • Page 6: General Instructions

    Performer Grill, the appliance and LP tank must be kept outdoors in a well-ventilated space. Check that the areas around the tank, hose and burner assembly are free from debris that might obstruct the air flow of gas or air. Operating area WARNING: Only use this barbecue outdoors in a well-ventilated area.
  • Page 7 While we give much attention to our products, unfortunately an occasional error may occur. If a part is missing, do not go back to the store. Call the Weber Customer Service Center toll free 1-800-446-1071 to receive immediate assistance. Have your owner’s manual and serial number available for reference.
  • Page 8 The following items will be found in the bottom carton. Wheel frame Two bottom connectors Front panel Caster frame assembly Top frame assembly Tank holder assembly Control panel Bowl panel Charcoal grate Hinged cooking grate Burner cleaning tool/ match holder Two wheels Axle...
  • Page 9 Place one end of the axle on the block of wood (or other protected surface). Tap on one hubcap. Put one wheel on the axle, WEBER side toward the hubcap. Slide the axle through the frame. Add the other wheel, WEBER side out. Tap on the hubcap. Figure 1.
  • Page 10 Step 2 Remove protective packaging Protective cardboard inserts must be removed from the bowl before assembly. Figure 2. DO NOT FORCEFULLY REMOVE THE INSERTS. a) Remove cardboard insert from ash catcher ring. Be careful when removing the cardboard not to bend the ash catcher ring.

  • Page 11: Assembly

    Place front panel along inside edge of frame assembly with Weber logo on the side closest to the wheel frame and facing out. Slip washers on bolts, insert bolts through the front panel and screw into the frame assembly.
  • Page 12 Step 6 Uncover CharBin lid Remove protective plastic covering from CharBin lid. Figure 6. Figure 6 Step 7 Install bowl assembly You will need: bowl assembly, four 1 3/4 inch bolts, eight nylon washers, four aluminum washers, four acorn nuts, 7/16 inch open-end or adjustable wrench and pliers.
  • Page 13 There is no need to disconnect for installation. Figure 8 (a). The igniter assembly is taped to the burner assembly. Remove the tape and insert top part of igniter through the large part of the keyhole.
  • Page 14 Step 10 Install and connect filled LP tank WARNING: Make sure that the LP tank valve is closed. Close by turning clockwise. Hook LP tank onto tank holder assembly. The square hole on the tank collar fits over the top lip of the tank holder assembly.
  • Page 15 Step 11 Check for gas leaks DANGER Do not use an open flame to check for gas leaks. Be sure there are no sparks or open flames in the area while you check for leaks. This will result in a fire or explosion which can cause serious bodily injury or death and damage to property.
  • Page 16 Step 12 Add bowl panel, tool holders and CharBin Storage Container You will need: bowl panel, three tool holders and CharBin Storage Container. Remove protective plastic covering from bowl panel. Slide the ends of bowl panel under bowl mounting brackets so the ends rest on tabs inside frame. Set the panel in place on top of the frame brace.
  • Page 17 Step 13 Install ash catcher, control panel & bottom rack You will need: ash catcher, control panel and bottom rack. Align handle and prongs of ash catcher with their appropriate slots on the ash catcher ring. The handle fits into the larger slot. Figure 15 (a). Lift ash catcher up into slots and rotate to the right.

  • Page 18: Operating Instructions

    CAUTION: Your LP tank connection is equipped with an excess flow device. If it activates it reduces the flow of gas to the burner. If this should occur turn OFF the LP tank and turn the test valve OFF. Wait 5 minutes for the gas to clear. Then turn ON the LP tank and slowly turn the test valve ON and try to ignite again.

  • Page 19: Manual Lighting

    Figure 5. This could result in a fire in and around the burner tube under the bowl panel. It can cause serious damage to your barbecue, rendering it unsafe to operate.

  • Page 20: Cooking Methods

    For additional information and cooking times, consult the Weber Owner's Guide. A few wood chunks or a handful of cooking woodchips may be added to hot coals for a mild smoke flavor in your foods.

  • Page 21: Cleaning

    CAUTION: Be sure that burner is OFF and barbecue is cool before cleaning. Do not enlarge burner slots when cleaning. To clean burner: Brush the outside of the burner tube and the burner slot section with a brass wire brush. Figure 8.

  • Page 22: Connecting The Lp Tank

    The phone number is on the warning decal which is permanently attached to the tank. If the tank manufacturer has not resolved the issue to your satisfaction, then call Weber-Stephen Products Co., Customer Service Center. Test valve in OPEN position Figure 11...

  • Page 23: Safe Handling Tips For Lp Gas

    Only Weber 5 lb replacement LP cylinders will fit on your Performer Grill. Order from Weber-Stephen Products Co., Customer Service Center. Note - 5 lb LP tanks made by other manufactures will not fit on the Weber Performer Grill. Do not attempt to use them.

  • Page 24: Troubleshooting And Maintenance

    Troubleshooting Problem Burner burns with a yellow or orange flame, in conjunction with the smell of gas. Burner does not light, or flame is low. Burner flame pattern is erratic. Inside of lid appears to be “peeling.” (Resembles paint peeling.) CharBin slides out of the frame brace.

  • Page 25: Maintenance

    INSPECTING AND CLEANING THE BURNER 1. Turn OFF gas at the tank. 2. Remove the CharBin Storage Container. 3. Remove orifice clip and hose fitting from the burner tube. Figure 12. 4. Look inside the burner with a flashlight. 5. Use the burner cleaning tool provided to clean the air shutter area, the venturi section, and the burner slots on the inside of the bowl.
  • Page 26 PERIODIC QUICK CLEANING We recommend that you periodically brush the outside of the burner slots with a brass wire brush and clean the burner tube through the air shutter with the tool we have provided. This can be done by locating the burner air shutter underneath the bowl panel and inserting the tool through each air shutter, rotating the tool.
  • Page 28 12-13 14-16 18, 15-16 19-20, 15 29,20 19-20 40, 15-16 41-42 47-48 49-52...

  • Page 29: Parts Listing

    Parts can be ordered directly from Weber-Stephen Products Company by phone or mail. Note - Do not return parts to Weber-Stephen Products Co. without first contacting the Customer service Center by phone or mail. Returning the part may not be necessary.
  • Page 30 INAL hank you for choosing a Weber Barbecue. Our family here at Weber has worked hard to produce the highest quality products for your satisfaction. While we give much attention to our products, an occasional error may occur. Our knowledgeable Customer Service staff is prepared to help you with any problems with parts or assembly.
