- Page 1 PT2275SW Touch Screen LCD Monitor USER’S GUIDE www.planartouch.com...
-
Page 2: Important Recycle Instructions
The information contained in this document is subject to change without notice. This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be reproduced,translated to another language or stored in a retrieval system, or transmitted by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission. -
Page 3: Table Of Contents
Going to Sleep......................16 Out of Range ......................16 Product Dimensions ....................17 Compatibility Modes ....................18 Touch Screen Driver Installation .................19 Driver Installation Process ..................19 PT2275SW Driver Install Instructions ................19 PT2275SW Optional Calibration Tool Install ..............20 Product Registration and Technical Support ..............21... -
Page 4: Usage Notice
Usage Notice Warning - To prevent the risk of fi re or shock hazards, do not expose this product to rain or moisture. Warning - Please do not open or disassemble the product as this may cause electric shock. Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit. -
Page 5: Introduction
Introduction About PT2275SW The PT2275SW is a 22" fl at panel screen with an active matrix, thin-fi lm transistor (TFT) liquid crystal display (LCD). Features include: • Direct Analog signal input • Direct Digital signal input • Active matrix TFT LCD technology •... -
Page 6: Package Overview
Package Overview LCD Display Power Cord VGA Signal Cable USB Cable ( A to B) Audio-in Cable RS-232 Cable Cable Cover DVI-D Cable USB Cable (A to A) (Option for MSR) User’s Guide Landing Strip Screw Touch Screen Driver Installation CD-ROM... -
Page 7: Installation
Installation Product Overview • Front View • Bottom View Audio DVI IN AC IN VGA IN RS-232... -
Page 8: Kensington Security Slot
Kensington Security Slot The monitor can be secured to your desk or any other fi xed object with Kensington lock security products. The Kensington lock is not included. -
Page 9: Vesa Mount Your Monitor
VESA Mount Your Monitor This monitor conforms to the VESA Flat Panel Mounting Physical Mounting Interface standard which defi nes a physical mounting interface for fl at panel monitors, and corresponding with the standards of fl at panel monitor mounting devices, such as wall and table arms. -
Page 10: Start Your Installation
Start Your Installation 1. Lay the LCD fl at on an even surface. 2. Remove the stand back cover by pulling in the direction of the arrow as seen in step 2 diagram. 3. Move the stand into position as seen in step 3 diagram. 4. - Page 11 5. Take the optional cable cover and screw from the accessory box. Position all cables under the cover lip as seen in the step 5 diagram. 6. Using a Philips Head screwdriver, insert the screw (CBM M3x6) into the cable cover and monitor as seen in the step 6 diagram.
-
Page 12: Remove The Deskstand
Remove the Deskstand Remove stand back cover. Remove hinge cover. Remove 4 screws and then remove hinge. -
Page 13: Connecting The Display (Figure 11.1)
Connecting the Display (Figure 11.1) To setup this display, please refer to the following fi gure and procedures. 1. Be sure all equipment is turned off. 2. Connect the AC power cord to the power connector on the monitor and the other end into an electrical outlet (11.1). -
Page 14: (Figure 11.1)
(Figure 11.1) -
Page 15: User Controls
User Controls Side Panel Controls Icon key Name Menu Down Enter Power Menu off status Menu on status Menu appear Menu disappear/ return to main item Brightness Main item select up/ Adjust up Mute Main item select down/ Adjust down Enter/Select sub-item function Power On/Off... -
Page 16: How To Use The Osd Menus
How to Use the OSD Menus Icon key Name Menu Down Enter Power 1. Press the “MENU” button to pop up the “on-screen menu” and press “Up” or “Down” button to select among the six functions in the main menu. 2. -
Page 17: On-Screen Display Menus
On-Screen Display Menus Main OSD Menu: MAIN MENU SUB Menu Function Description 0-100 Adjusts the maximum luminance level of the monitor. Contrast 0-100 Adjusts the backlight of the monitor. Brightness The screen is moved horizontally right and left (1 pixel pitch NO / YES Auto Adjust increment). -
Page 18: Appendix Troubleshooting
Appendix Troubleshooting If you are experiencing trouble with the LCD display, refer to the following. If the problem persists, please contact your local dealer or our service center. Problem: No image appears on screen. ► Check that all the I/O and power connectors are correctly and well connected as described in the “Installation”... -
Page 19: Warning Signal
Warning Signal If you see warning messages on your LCD screen, this means that the LCD display cannot receive a clean signal from the computer graphics card. There may be three sources for this problem. Please check the cable connections or contact your local dealer or our service center for more information. -
Page 20: Product Dimensions
Product Dimensions 73.20 538.6 Side View Front View Top View... -
Page 21: Compatibility Modes
Compatibility Modes Mode Resolution H-Frequency (KHz) V-Frequency (Hz) IBM VGA 720 x 400 31.5 IBM VGA 640 x 480 31.5 VESA VGA 640 x 480 37.9 VESA VGA 640 x 480 37.5 VESA SVGA 800 x 600 35.2 VESA SVGA 800 x 600 37.9 VESA SVGA... -
Page 22: Touch Screen Driver Installation
After installation is complete, click “Finish”. PT2275SW Driver Install Instructions: The PT2275SW is available with both RS232 and USB connections. The PT2275SW model is Microsoft® Windows® HID (Human Interface Device) compatible if you use the USB touch screen interface. No additional software driver is required for general operation of the touch screen. -
Page 23: Pt2275Sw Optional Calibration Tool Install
PT2275SW Optional Calibration Tool Install: If you would like to use the Optional Calibration Tool, follow the instructions below. Please note: the calibration tool supports Windows® VISTA, XP, XP Embedded, 2000 and ME operating systems via USB only. Open the CD-ROM. -
Page 24: Product Registration And Technical Support
Product Registration and Technical Support Register Your Planar Products Today Thank you for choosing Planar. To assure you receive all the benefi ts of your Planar product and services, register your Planar product today. Visit our website to register your product at http://www.planar.com/support/product_registration.html. - Page 25 Tel: 1-866-PLANAR1 (866-752-6271) or +1 503-748-5799 outside the United States. Hours: 24 hours a day, 7 days a week © 2009 Planar Systems, Inc. 11/09 Planar is a registered trademark of Planar Systems, Inc. Other brands and names are the property of their respective owners. Technical information in this document is subject to change without notice.
